Page 1: User Manual
User Manual Please read this Manual assiduous before start working with the effect light!!! -
Page 2: Packing List
Packing List 1 pcs. Stairville maTRIXX TLB-20 DMX 1 pcs. Power cord 1 pcs. Owners manual 2 pcs. Lighting Hangers Product Introduction： This product adopts the latest appearance, with small volume, light heaviness, nice appearance and good heat scattering. - Page 3 Technical Parameters: Rated voltage: AC110V /230V ±10% Rated frequency: 50Hz∼60Hz±10％ Power consumption: Beads quantity: 192 super bright light pearls (red: 72pcs, green: 72pcs, blue: 48pcs) Pictures quantity: Channels: 10 channels Control signal: DMX-512 international standard signal Control mode: DMX-512、automatic、music、master & slave Operating environment: indoor ...
- Page 4 DMX-512 Function: CHANNEL DMX-512 VALUE CONTROL 0∼41 LED light switch off 42∼83 Effect Editing Control Automatic control 84∼125 Insetting Effect Control 126∼167 Run insetting program 168∼209 Effect Edition Control Music control 210∼251 Insetting Effect Control 252∼255 Run insetting program Pictures choice 0∼255 85 pictures selection...
- Page 5 Signal Connection This product is assembled with DMX input and output 3 pins XLR socket, while all connection is that Pin 1 is connected to the ground, Pin 2 is connected the negative pole signal, Pin 3 is connected the Positive pole signal.
- Page 6 DMX-512 address code set: This unit is equipped with 10 channels, while the address code of the first light is 1, the second 10+1=11, the third 10+11=21, and so on. Detailed DMX-512 address code set as following: Light NO. Original address Binary Code Dialing（ON）...
- Page 7 Safety Marks: 1. Please make sure to switch off the power before installation or maintenance. 2. Please keep the fan expedite and environment ventilated. 3. This laser projector is designed for the indoor, so while using, please avoid any dripping. If you want to use outdoor, please do enough waterproof measure.
