Setting Up The Reader For The First Time - Freestyle LIBRE PRO Operator's Manual

Setting up the Reader for the First Time

Before using the System for the first time, the Reader must be set up .
Step
1
Press the Home Button to turn on the Reader .
2
If prompted, use the touchscreen to select your
preferred language for the Reader . Touch OK to
continue .
Note: Use the pad of your finger . Do NOT use
your fingernail or any other object on the screen .
3
Set the Current Date using the arrows on the
Current Date
touchscreen . Touch next to continue .
11 June
2017
back next
12
ART26944_rev-C_manual.indd 12-13
Action
Step Action
4
Set the Current Time . Touch next to continue .
Current Time
CAUTION: It is very important to set the time
12 00
am
and date correctly for correct interpretation
of Sensor data .
back next
5
Set the Target Glucose Range . Touch next to
?
Target Glucose
Range
continue .
Note: The Target Glucose Range is displayed on
80 140
mg
to
dL
the Daily Graph on the Reader once Sensor data
has been downloaded . While the glucose data
are gathered in the System range of 40-500 mg/dL,
back next
the Daily Graph display range is 0-350 mg/dL for
ease of review on screen .
6
The Reader now indicates how to return to the
While using the Reader, press
the Home button to return to
Home Screen from any other screen . Touch done
the Home screen.
to go to the Home Screen .
back done
Note: Charge the Reader if the battery level is low . Only use the USB
cable and power adapter included with the System .
13
9/23/16 9:19 AM
