  • Page 1 G1-710 Predator User’s Guide...
  • Page 2 © 2016. All Rights Reserved. Desktop Computer Covers: Tower models This revision: April 2016 V1.01 Important This manual contains proprietary information that is protected by copyright laws. The information contained in this manual is subject to change without notice. Images provided herein are for reference only and may contain information or features that do not apply to your computer.

  • Page 3: Table Of Contents

    Table of contents - 3 A B L E O F C O N T E N T S Information for your  Turning off your computer...... 38 Using a USB device....... 39 safety and comfort Safety instructions ........5 Connecting a USB storage device ....
  • Page 4 4 - Table of contents Potentially explosive environments ..86 USA — FCC and FAA....... 89 FCC radio frequency interference Disposal instructions......87 requirements ..........90 ENERGY STAR........87 Canada — Industry Canada (IC) ....92 Wireless adapter regulatory information 88 European Union ........

  • Page 5: Information For Your

    Information for your safety and comfort - 5 N F O R M A T I O N F O R Y O U R S A F E T Y A N D C O M F O R T Safety instructions Turning the product off before cleaning Unplug this product from the wall outlet before cleaning.

  • Page 6: Product Servicing

    6 - Information for your safety and comfort • If an extension cord is used with this product, make sure that the total ampere rating of the equipment plugged into the extension cord does not exceed the extension cord ampere rating. Also, make sure that the total rating of all products plugged into the wall outlet does not exceed the fuse rating.

  • Page 7: Disposal Instructions

    Information for your safety and comfort - 7 Disposal instructions Do not throw this electronic device into the trash when discarding. To minimize pollution and ensure utmost protection of the global environment, please recycle. For more information on the Waste from Electrical and Electronics Equipment (WEEE) regulations, visit ...

  • Page 8: Tips And Information For Comfortable Use

    8 - Information for your safety and comfort Tips and information for comfortable use Computer users may complain of eyestrain and headaches after prolonged use. Users are also at risk of physical injury after long hours of working in front of a computer. Long work periods, bad posture, poor work habits, stress, inadequate working conditions, personal health, and other factors greatly increase the risk of physical injury.

  • Page 9: Taking Care Of Your Vision

    Information for your safety and comfort - 9 • install the external display, keyboard and mouse properly and within comfortable reach • if you view your monitor more than your documents, place the display at the center of your desk to minimize neck strain Taking care of your vision Long viewing hours, wearing incorrect glasses or contact lenses, glare, excessive room lighting, poorly focused screens, very small...

  • Page 10: Developing Good Work Habits

    10 - Information for your safety and comfort Developing good work habits Develop the following work habits to make your computer use more relaxing and productive: • Take short breaks regularly and often. • Perform some stretching exercises. • Breathe fresh air as often as possible. •...
  • Page 11 - 11 1 First things first In this section you will find: • List of package content • Useful information on caring for your computer • System specifications...

  • Page 12: 12 - 1 First Things First

    Package contents Carefully unpack the carton and remove the contents. If any of the following items are missing or damaged, contact your dealer immediately: • Predator G1-710 • USB Keyboard • USB Mouse • Two 230W adapters • Adapter holder Note USB Keyboard and Mouse may vary by configuration.

  • Page 13: Basic Care And Tips For Using Your Computer

    1 First things first - 13 Basic care and tips for using your computer Turning your computer on and off To turn the computer on, see Turning on your computer on page To turn the computer off, do any of the following: •...

  • Page 14: Power Cord Information

    14 - 1 First things first • Do not subject the computer to heavy shock or vibration. • Do not expose the computer to dust or dirt. • Never place objects on top of the computer. • Do not slam the computer display when you close it. •...

  • Page 15: Specifications

    1 First things first - 15 Specifications Category Description • Genuine Windows 10 Professional 64-bit Operating system • Genuine Windows 10 Home 64-bit ® • 6th Generation Intel Core i7 processors ™ Processor ® • 6th Generation Intel Core i5 processors ™...
  • Page 16 16 - 1 First things first Category Description • One PCIe x16 slot for graphic interface • One M.2 slot for WLAN Expansion options • One M.2 slot for SSD • Three SATA 3.0 connectors • Wired LAN: Onboard Killer Doubleshot Pro ™...

  • Page 17: System Tour

    - 17 2 System tour In this section you will find: • Hardware features of your computer...

  • Page 18: 18 - 2 System Tour

    18 - 2 System tour Y S T E M T O U R External components Front view Item Icon Component Power button/Power status indicator Earphone/Headset holders Optical media drive...
  • Page 19 2 System tour - 19 Item Icon Component SD car reader USB 3.1 type C port (support fast charging) One USB 3.0 port (support fast charging) Headphone/speakers jack Microphone jack...

  • Page 20: Rear View

    20 - 2 System tour Rear view Item Icon Component Audio jacks Ethernet (RJ45) jack Kensington lock slot Expansion card (graphics board) DC-In jack 2 (graphics card power connector) DC-In jack 1 (system power connector) USB 3.0 ports...

  • Page 21: Status Indicators

    2 System tour - 21 Status indicators The computer has two status indicators that provide information on computer operating status and Ethernet (RJ45) jack activity. Icon Indicator Status Description Solid  Power Power on status Blinking S3 standby/sleep mode Power off Ethernet ...

  • Page 22: Internal Components

    22 - 2 System tour Internal components Inside the system Item Component System fan Thermal module Memory modules HDD/ODD assembly 2.5-inch hard drive Expansion card (graphics board) Mainboard...

  • Page 23: Mainboard

    2 System tour - 23 Mainboard Item Code Component ROM_RECOVERY ROM recovery jumper SYS_FAN System fan connector CPU socket LED_BAR LED bar connector DIMM1/2/3/4 DDR4 DIMM slots F_PANEL Power button connector M.2_WIFI/BT M.2 WIFI connector M.2_SSD M.2 SSD connector FDO jumper FIO_PWR FIO power connector FRONT_IO...
  • Page 24 24 - 2 System tour Item Code Component SATA1/2/3 SATA connectors SATA_PWR SATA power connector CPU_FAN CPU fan connector PCIE x 16 PCI Express x16 slot System power connector GFX power connector AUXPWR_6P AUX power 6-pin connector AUXPWR_8P AUX power 8-pin connector LAN_USB LAN + USB 3.0 connectors SS_USB...

  • Page 25: Setting Up Your Computer

    - 25 3 Setting up your computer In this section you will find: • How to arrange a comfortable work area for your computer • How to position your computer, monitor, keyboard and mouse • How to connect your computers to peripheral devices...

  • Page 26: 26 - 3 Setting Up Your Computer

    26 - 3 Setting up your computer E T T I N G U P Y O U R C O M P U T E R Arranging a comfortable work area Selecting a location Before unpacking and installing the computer, select a suitable site for the system for maximum efficiency.

  • Page 27: Positioning Your Computer

    3 Setting up your computer - 27 Positioning your computer Take note of the following when selecting a location for your computer: • Do not plug your computer near any equipment that might cause electromagnetic or radio frequency interference, such as radio transmitters, televisions, copy machines or heating and air- conditioning equipment.

  • Page 28: Positioning Your Keyboard

    28 - 3 Setting up your computer Positioning your keyboard The location of the keyboard is a very important factor for your posture. Placing it too far away will make your body lean forward, forcing you to sit in an unnatural position. Placing it too high will add tension to your shoulder muscles.

  • Page 29: Connecting The Computer

    3 Setting up your computer - 29 Connecting the computer Note The peripheral devices shown in the following images are for your reference only. Actual device models may vary in select countries. Connecting a USB mouse Attach the mouse cable to any USB port on your computer. Information on USB 3.0 •...

  • Page 30: Connecting A Usb Keyboard

    30 - 3 Setting up your computer Connecting a USB keyboard Attach the keyboard cable to any USB port on your computer.

  • Page 31: Connecting An External Monitor

    3 Setting up your computer - 31 Connecting an external monitor You can connect an external monitor using the HDMI connector or DVI-D connector. HDMI output 1. Connect the video cable from the monitor to the HDMI connector on your computer.
  • Page 32 32 - 3 Setting up your computer DVI-D output 1. Connect the DVI-D cable from the monitor to the DVI-D connector of the computer. 2. Secure the connection using the cable screws.

  • Page 33: Connecting Audio Devices

    3 Setting up your computer - 33 Connecting audio devices The computer’s audio jacks (headphone/speakers, microphone, line- in, or line-out jack) allows you to connect audio devices such as a headphone, headset, microphone, or speakers. Connect the audio device’s cable to any of the audio I/O ports located on the front or rear panel of the computer.

  • Page 34: Connecting To Power

    34 - 3 Setting up your computer Connecting to power 1. Insert the adapter cables (1) and place the power adapters into the power adapter holder (2). 2. Plug the power cords into the DC-in jack 1 and 2 power connectors, then into an electrical outlet.

  • Page 35: Connecting To A Network

    3 Setting up your computer - 35 Connecting to a network Your computer’s built-in network features make it easy for you to connect your computer to the internet using a cable or a wireless connection. First though, in order to connect to the internet, you’ll need to sign up for internet services from an Internet Service Provider (ISP) —...

  • Page 36: Connecting To A Wireless Network

    36 - 3 Setting up your computer Connecting to a wireless network This computer is equipped with a wireless communication feature. This feature allows you to connect to a wireless Ethernet-based network and communicate with other wireless communication devices. Your computer's wireless connection is turned on by default and Windows will detect and display a list of available networks during setup.

  • Page 37: Connecting To A Wireless Network

    3 Setting up your computer - 37 Connecting to a wireless network Note Ensure you have a wireless router or access point and current internet connection through the ISP of your choice. Make a note of the wireless network’s name and password (if necessary). If you are trying to connect to a public network (such as at a coffee shop), make sure you have the wireless ...

  • Page 38: Turning On Your Computer

    38 - 3 Setting up your computer Turning on your computer After making sure you have properly set up your computer, applied power and connected all necessary peripherals, you can now power on the system. 1. Turn your monitor on. 2.

  • Page 39: Using A Usb Device

    3 Setting up your computer - 39 Using a USB device Your computer has six USB 3.0 ports located on the front and rear panels. You can connect USB devices such as keyboards, mouse, storage devices, power banks, smartphones, or digital cameras to these ports.

  • Page 40: Disconnecting A Usb Device

    40 - 3 Setting up your computer Disconnecting a USB device To disconnect a USB device from your computer, click on the Safely Remove Hardware icon on the taskbar and click on the device. When the device can be safely removed, disconnect the device from the computer.

  • Page 41: Using The Optical Disc Drive

    3 Setting up your computer - 41 Using the optical disc drive To insert an optical disc: 1. While the computer is on, press the ODD eject button. 2. When the disk tray slides open, place the disc gently on the tray. Make sure that the label or title side of the disk is facing outward.
  • Page 42 42 - 4 PredatorSense In this section you will find: • Introduction to the PredatorSense utility • How to use PredatorSense...

  • Page 43: Predatorsense

    4 PredatorSense - 43 R E D A T O R E N S E PredatorSense (DT) V1.0 is an Acer proprietary utility to enhance the user experience of Gaming products on Microsoft Windows 10. The central idea of this utility is to provide a user interface to easily control fan speed, RGB chassis and also display system information.
  • Page 44 44 - 4 PredatorSense Category Description CPU frequency Shows CPU frequency information in MHz. • Shows CPU and System temperature. Temperature • Options: C or Shows CPU temperature information. System Shows System temperature information. • Shows CPU and System fan speed in RPM. •...

  • Page 45: Logo Led

    4 PredatorSense - 45 Logo LED Category Description Basic colors Choose the basic color of your lighting effects. Shows the 5 most recent colors the user has Recent colors created using the More Colors button. More colors Select to get more color options. •...

  • Page 46: Badge Led

    46 - 4 PredatorSense V Badge LED Category Description Basic colors Choose the basic color of your lighting effects. Shows the 5 most recent colors the user has Recent colors created using the More Colors button. More colors Select to get more color options. •...

  • Page 47: Highlights Led

    4 PredatorSense - 47 Highlights LED Category Description Basic colors Choose the basic color of your lighting effects. Shows the 5 most recent colors the user has Recent colors created using the More Colors button. More colors Select to get more color options. •...
  • Page 48 48 - 5 Killer network In this section you will find: • Introduction to the Killer Network solution • How to use Killer Network Manager...

  • Page 49: Killer Network

    5 Killer network - 49 IL LE R N E T W O R K Your computer is equipped with an onboard Killer E2400 Gigabit ™ Ethernet LAN and Killer™ Wireless-AC 1535. E2400 Gigabit Ethernet LAN is an ultra-high performance, Killer ™...

  • Page 50: Killer Network Manager

    50 - 5 Killer network Killer network manager To set up the Killer Network application (Windows 10): 1. From the Start menu, select All apps. 2. Select Killer Networking. 3. Select Killer Networking Manager. Alternatively, you can double-click the Killer Networking Manager desktop shortcut to run the application.

  • Page 51: Applications

    5 Killer network - 51 Applications Select the Applications tile to configure applications that are using network connections. You can block or set the priority of network connections of each application on this page. Category Description Sort applications that are using network Sort By Name connection by alphabetical order.

  • Page 52: Settings

    52 - 5 Killer network Settings Select the Settings tile to configure Killer Network settings. Category Description Set the upload speed of your network Upload Speed connection. Set the download speed of your network Download Speed connection. Enable Advanced Enable or disable the Advanced Stream Stream Detect Detect feature of Killer network.

  • Page 53: Performance

    5 Killer network - 53 Performance Select the Performance tile to get an overview of your system network traffic. Category Description Shows the top 5 applications by total traffic Top 5 Applications history. Shows the incoming traffic in Megabits over Usage - Download the past two minutes.

  • Page 54: Killer Wireless

    54 - 5 Killer network Killer Wireless Select the Killer Wireless tile to see your wireless network information. Killer Ethernet Select the Killer Ethernet tile to see your LAN information.

  • Page 55: Wifi Manager

    5 Killer network - 55 Wifi Manager Select the Wifi Manager tile to see all available wireless network connection.
  • Page 56 56 - 6 Upgrading your computer In this section you will find: • Instructions on how to replace a hardware component...

  • Page 57: Upgrading Your Computer

    6 Upgrading your computer - 57 P G R A D I N G Y O U R C O M P U T E R Installation precautions Before you install any computer component, we recommend that you read the following sections. These sections contain important ESD precautions along with...

  • Page 58: Pre-Installation Instructions

    58 - 6 Upgrading your computer Pre-installation instructions Always observe the following before you install any component: 1. Make sure that the ODD and card reader slot is empty. 2. Turn off the power to the computer and all peripherals. 3.

  • Page 59: System Covers

    6 Upgrading your computer - 59 System covers Removing the left side system cover 1. Before you proceed, make sure that you have turned off your computer and all peripherals connected to it. Read the Pre- installation instructions on page 2.

  • Page 60: Installing The Left Side System Cover

    60 - 6 Upgrading your computer Installing the left side system cover 1. Align the cover to the sides of the computer and slide the cover toward the front of the computer (1). 2. Secure the cover with two screws (2). 3.

  • Page 61: Removing The Right Side System Cover

    6 Upgrading your computer - 61 Removing the right side system cover 1. Before you proceed, make sure that you have turned off your computer and all peripherals connected to it. Read the Pre- installation instructions on page 2. Remove the two screws that secure the system cover to the  computer (1).

  • Page 62: Installing The Right Side System Cover

    62 - 6 Upgrading your computer Installing the right side system cover 1. Align the cover to the sides of the computer and slide the cover toward the front of the computer (1). 2. Secure the cover with two screws (2). 3.

  • Page 63: Removing The Rear Input/Output (I/O) Bezel

    6 Upgrading your computer - 63 Removing the rear input/output (I/O) bezel 1. Before you proceed, make sure that you have turned off your computer and all peripherals connected to it. Read the Pre- installation instructions on page 2. Remove the right side system cover. See Removing the right side system cover on page 3.
  • Page 64 64 - 6 Upgrading your computer 4. Detach the rear I/O bezel. 5. Set the rear I/O bezel aside for re-installation later.

  • Page 65: Installing The Rear Input/Output (I/O) Bezel

    6 Upgrading your computer - 65 Installing the rear input/output (I/O) bezel 1. Place the rear I/O bezel into the chassis and push until all the latches lock into place. 2. Observe the Post-installation instructions on page...

  • Page 66: Hard Drive

    66 - 6 Upgrading your computer Hard drive The computer supports installation of one 2.5-inch SATA hard drive and one 3.5-inch SATA hard drive. Removing the 2.5-inch hard drive 1. Perform Pre-installation instructions on page 2. Remove the four screws that secure the HDD bracket to the graphics card cover.
  • Page 67 6 Upgrading your computer - 67 3. Lift the HDD bracket from the graphics card cover. 4. Remove the two screws that secure the HDD cable to the bracket.
  • Page 68 68 - 6 Upgrading your computer 5. Disconnect the cable from the hard drive. 6. Remove the four screws that secure the hard drive to the bracket.
  • Page 69 6 Upgrading your computer - 69 7. Remove the hard drive from the bracket.

  • Page 70: Installing The 2.5-Inch Hard Drive

    70 - 6 Upgrading your computer Installing the 2.5-inch hard drive 1. Remove the new hard drive from its packaging. 2. Insert the new hard drive into the bracket. 3. Secure the new hard drive with four screws.
  • Page 71 6 Upgrading your computer - 71 4. Connect the cable to the new hard drive. 5. Secure the HDD cable with two screws.
  • Page 72 72 - 6 Upgrading your computer 6. Place the HDD bracket into the graphics card cover. 7. Secure the HDD bracket with four screws. 8. Observe the Post-installation instructions on page...

  • Page 73: Memory

    6 Upgrading your computer - 73 Memory The computer has four DDR4 U-DIMM slots that support up to 64 GB maximum system memory. Memory configuration guidelines • To ensure data integrity, use only Acer-approved DDR4 2133 MHz type memory modules. •...

  • Page 74: Removing A Memory

    74 - 6 Upgrading your computer Removing a memory 1. Perform Pre-installation instructions on page 2. Press outward the holding clips on both sides of the DIMM slot outward to release the memory module (1). 3. Gently pull the memory module upward to remove it from the DIMM slot (2).

  • Page 75: Installing A Memory

    6 Upgrading your computer - 75 Installing a memory Note DIMM slots on the mainboard must be installed only in certain configurations.  Numbers next to DIMM slots correspond to installation sequence.  Be sure to install the memory module in DIMM1 slot followed by DIMM2 slot. 1.

  • Page 76: Graphics Board

    76 - 6 Upgrading your computer Graphics board The computer contains one graphics board installed in the PCIe x16 slot. Removing the graphics board 1. Perform Pre-installation instructions on page 2. Remove the right side system cover. See Removing the right side system cover on page 3.
  • Page 77 6 Upgrading your computer - 77 5. Release the latch that secures the graphics board to the mainboard. 6. Detach the graphics board from the PCIe x16 slot.
  • Page 78 78 - 6 Upgrading your computer 7. Disconnect the power cables from the graphics board. 8. Release the latch that secures the graphics board to the bracket.
  • Page 79 6 Upgrading your computer - 79 9. Remove the graphics board from the bracket. 10. If you intend to install a new I/O expansion board, proceed to the next section for related procedure, then observe the Post- installation instructions on page...

  • Page 80: Installing The Graphics Board

    80 - 6 Upgrading your computer Installing the graphics board 1. Insert the graphics board into the bracket. 2. Push the retention latch to secure the graphics board to the bracket.
  • Page 81 6 Upgrading your computer - 81 3. Connect the power cables to the graphics board. 4. Insert the graphics board into the PCIe x16 slot.
  • Page 82 82 - 6 Upgrading your computer 5. Push the retention latch to secure the graphics board to the bracket. 6. Secure the graphics board with three screws.
  • Page 83 6 Upgrading your computer - 83 7. Replace the rear input/output (I/O) bezel. See Installing the rear input/output (I/O) bezel on page 8. Observe the Post-installation instructions on page...

  • Page 84: 84 - Warnings And Regulatory Information

    84 - Warnings and regulatory information A R N I N G S A N D R E G U L A T O R Y I N F O R M A T I O N Optical drives CAUTION: This appliance contains a laser system and is classified as a "CLASS 1 LASER PRODUCT."...

  • Page 85: Telephone Line Safety

    Warnings and regulatory information - 85 Telephone line safety • Disconnect all telephone lines from the equipment when not in use and/or before servicing. • To avoid the remote risk of electric shock from lightning, do not connect the telephone line to this equipment during lightning or thunderstorms.

  • Page 86: Vehicles

    86 - Warnings and regulatory information Hearing aids. Some digital wireless devices may interfere with some hearing aids. If interference occurs, consult your service provider. Vehicles RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles such as electronic fuel injection systems, electronic antiskid (anti-lock) braking systems, electronic speed control systems, and air bag systems.

  • Page 87: Disposal Instructions

    Warnings and regulatory information - 87 device at refueling points such as near gas pumps at service stations. Observe restrictions on the use of radio equipment in fuel depots, storage, and distribution areas; chemical plants; or where blasting operations are in progress. Areas with a potentially explosive atmosphere are often, but not always, clearly marked.

  • Page 88: Wireless Adapter Regulatory Information

    88 - Warnings and regulatory information Note Information in this section may not apply to your computer. Acer ENERGY STAR qualified products: • Produce less heat and reduce cooling loads, and warmer climates. • Automatically go into "display sleep" and "computer sleep" mode after 10 and 30 minutes of inactivity respectively.

  • Page 89: Use On Aircraft

    Warnings and regulatory information - 89 Use on aircraft Warning FCC and FAA regulations may prohibit airborne operation of radio- frequency wireless devices (wireless adapters) because their signals could interfere with critical aircraft instruments. Ask the cabin crew before turning on your device’s wireless adapter whilst on board. The wireless adapter and your health The wireless adapter, like other radio devices, emits radio frequency electromagnetic energy.

  • Page 90: Fcc Radio Frequency Interference Requirements

    90 - Warnings and regulatory information supplement C, 2001, and ANSI/IEEE C95.1, 1992. Proper operation of this radio according to the instructions found in this manual will result in exposure substantially below the FCC’s recommended limits. • The following safety precautions should be observed: Do not touch or move antenna while the unit is transmitting or receiving.
  • Page 91 Warnings and regulatory information - 91 USA — Federal Communications Commission (FCC) Note The radiated output power of the adapter is far below the FCC radio frequency exposure limits. Nevertheless, the adapter should be used in such a manner that the potential for human contact during normal operation is minimized.

  • Page 92: Canada - Industry Canada (Ic)

    92 - Warnings and regulatory information • Connect the computer with the wireless adapter to an outlet on a circuit different from that to which the equipment experiencing the interference is connected. • Consult the dealer or an experienced radio/TV technician for help. Canada —...
  • Page 93 Warnings and regulatory information - 93 ISO 3166  ISO 3166  Country Country 2 letter code 2 letter code Lithuania Romania Luxembourg Turkey Specific absorption rate information This device meets the EU requirements on the limitation of exposure of the general public to electromagnetic fields by way of health protection.
  • Page 94 94 - Warnings and regulatory information Hiermit erklärt ACER INC., dass sich das Gerät Deutsch Radiolan in Übereinstimmung mit den grundlegenden [German] Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet. Käesolevaga kinnitab ACER INC. seadme vastavust Eesti direktiivi 1999/5/EÜ põhinõuetele ja nimetatud [Estonian] direktiivist tulenevatele teistele asjakohastele sätetele.
  • Page 95 Warnings and regulatory information - 95 Hawnhekk, ACER INC., jiddikjara li dan jikkonforma Malti mal- ti ijiet essenzjali u ma provvedimenti o rajn [Maltese] relevanti li he mm fid-Dirrettiva 1999/5/EC. Alulírott, ACER INC. nyilatkozom, hogy a készülék Magyar megfelel a vonatkozó alapveto követelményeknek és [Hungarian] az 1999/5/EC irányelv egyéb eloírásainak.
  • Page 96 96 - Warnings and regulatory information France Pour la France métropolitaine : 2,400 - 2,4835 GHz (Canaux 1à 13) autorisé en usage intérieur 2,400 - 2,454 GHz (canaux 1 à 7) autorisé en usage extérieur Pour la Guyane et la Réunion : 2,400 - 2,4835 GHz (Canaux 1à...
  • Page 97 Warnings and regulatory information - 97 Belgium Dans le cas d'une utilisation privée, à l'extérieur d'un bâtiment, au- dessus d'un espace public, aucun enregistrement n'est nécessaire pour une distance de moins de 300 m. Pour une distance supérieure à 300 m un enregistrement auprès de l'IBPT est requise. Pour les enregistrements et licences, veuillez contacter l'IBPT.

  • Page 98: Compliant With Russian Regulatory Certification

    98 - Warnings and regulatory information Taiwan 第十二條 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均 不得擅自變更頻率、加大功率或變更原設計之特性及功能。 第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通信 ; 經發現有干 擾現象時，應立即停用，並改善至無干擾時方得繼續使用。 前項合法通信，指依電信法規定作業之無線通信。 低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機 設備之干擾。 Modifications to the product Acer cannot be held responsible for unauthorized modifications made by the user and the consequences thereof, which may alter the conformity of the product.
