  • Page 1 Table of Contents - Predator PO5-610 User’s Guide...
  • Page 2 © 2018. All Rights Reserved. Desktop Computer Covers: Tower models This revision: November 2018 V1.00 Important This manual contains proprietary information that is protected by copyright laws. The information contained in this manual is subject to change without notice. Images provided herein are for reference only and may contain information or features that do not apply to your computer.

  • Page 3: Table Of Contents

    Table of Contents - Table of Contents Removing a memory module ....16 UPGRADING YOUR COMPUTER ....5 Installing a memory module ....18 Installation precautions ......5 Graphic board ..........21 ESD precautions .......... 5 Removing the Graphic board ....21 Required tools..........
  • Page 4 - Upgrading your Computer Upgrading your Computer In this section, you will find: • Instructions on how to replace a hardware component...

  • Page 5: Upgrading Your Computer

    Upgrading your Computer - 1. UPGRADING YOUR COMPUTER Installation precautions Before you install any computer component, we recommend that you read the following sections. These sections contain important ESD precautions along with pre-installation and post-installation instructions. ESD precautions Electrostatic discharge (ESD) can damage your processor, disk drives, expansion boards, and other components.

  • Page 6: Pre-Installation Instructions

    - Upgrading your Computer Pre-installation instructions Always observe the following before you install any component: Make sure that the ODD and card reader slot is empty. Turn off the power to the computer and all peripherals. Unplug the power cord from the computer. Unplug the network cable and all connected peripheral devices from the computer.

  • Page 7: System Upgrade

    Upgrading your Computer - System Upgrade Removing the left side system cover Before you proceed, make sure that you have turned off your computer and all peripherals connected to it. Read the Pre- installation instructions on page 6. Remove the two screws that secure the system cover to the computer.

  • Page 8: Installing The Left Side System Cover

    - Upgrading your Computer Installing the left side system cover Align the cover to the sides of the computer and slide the cover toward the front of the computer. Secure the cover with two screws. Observe the Post-installation instructions on page 6.

  • Page 9: Removing The Right Side System Cover

    Upgrading your Computer - Removing the Right side system cover Before you proceed, make sure that you have turned off your computer and all peripherals connected to it. Read the Pre- installation instructions on page 6. Remove the two screws that secure the system cover to the computer.

  • Page 10: Installing The Right Side System Cover

    - Upgrading your Computer Installing the Right side system cover Align the cover to the sides of the computer and slide the cover toward the front of the computer. Secure the cover with two screws. Observe the Post-installation instructions on page 6.

  • Page 11: Hard Drives

    Upgrading your Computer - 11 Hard drives The computer supports installation of one 3.5-inch SATA hard drives in the internal HDD cage. Removing the 3.5-inch hard drives Perform Pre-installation instructions on page 6. Disconnect the power and data cables from the hard drives.
  • Page 12 - Upgrading your Computer Remove the one screws that secure the hard drives to the bracket Remove the hard drives from the bracket.

  • Page 13: Installing The 3.5-Inch Hard Drives

    Upgrading your Computer - 13 Installing the 3.5-inch hard drives Remove the new hard drive from their packaging. Insert the new hard drive into the bracket. Secure the new hard drive with one screw.
  • Page 14 - Upgrading your Computer Connect the power and data cables to the hard drive. Observe the Post-installation instructions on page 6...

  • Page 15: Memory

    Upgrading your Computer - 15 Memory The computer has four DDR4 U-DIMM slots that support up to 64 GB maximum system memory. DIMM4 DIMM2 DIMM3 DIMM1 Memory configuration guidelines  To ensure data integrity, use only Acer-approved DDR4 2400 MHz or DDR4 2666 MHZ type memory modules.

  • Page 16: Removing A Memory Module

    - Upgrading your Computer Removing a memory module 1. Perform Pre-installation instructions on page 6. 2. Disconnect the thermal fan cable from the mainboard. 3. Use a long screw driver to loosen the four captive screws securing the thermal module to the mainboard.
  • Page 17 Upgrading your Computer - 17 4. Remove the thermal module from the chassis. 5. Press outward the holding clips on both sides of the DIMM slot outward to release the memory module (1). 6. Gently pull the memory module upward to remove it from the DIMM slot (2).

  • Page 18: Installing A Memory Module

    - Upgrading your Computer Installing a memory module Note DIMM slots on the mainboard must be installed only in certain configurations. Numbers next to DIMM slots correspond to installation sequence. Be sure to install the memory module in DIMM1 slot followed by DIMM2 slot. Select an empty DIMM slot.
  • Page 19 Upgrading your Computer - 19 Place the thermal module into the chassis. Use a long screw driver to tighten the four captive screws and secure the thermal module to the mainboard.
  • Page 20 - Upgrading your Computer Connect the thermal fan cable to the mainboard. Observe the Post-installation instructions on page 6.

  • Page 21: Graphic Board

    Upgrading your Computer - 21 Graphic board The computer contains one or two Graphic boards installed in the PCIe x16 slots. The detail configuration will be differed by different models. Removing the Graphic board Perform Pre-installation instructions on page 6. Disconnect the power cables from the Graphic board.
  • Page 22 - Upgrading your Computer Remove the screw that secure the Graphic boards to the chassis.
  • Page 23 Upgrading your Computer - 23 Release the latch that secures the graphic board to the mainboard. Detach the Graphic board from the PCIe x16 slot.

  • Page 24: Installing The Graphic Board

    - Upgrading your Computer Installing the Graphic board Remove the new graphic board from its packaging. Insert the Graphic boards into the PCIe x16 slot and press it down until it latches into place. [Note] For replace/upgrade graphic board, please check the specification of graphic board &...
  • Page 25 Upgrading your Computer - 25 Connect the bridge from the graphic board. Connect the power cables to the Graphic boards. Observe the Post-installation instructions on page 6...

  • Page 26: M.2 Ssd Module

    - Upgrading your Computer M.2 SSD module The computer contains one M.2 SSD module installed in the M.2 PCIe slot. Removing the M.2 SSD module Perform Pre-installation instructions on page 6. Remove the Graphic board. See Removing the Graphic board. Remove the screws that secures the thermal heat-sink module from the mainboard Remove the thermal heat-sink module from the...
  • Page 27 Upgrading your Computer - 27 Detach the M.2 SSD module from the mainboard.

  • Page 28: Installing The M.2 Ssd Module

    - Upgrading your Computer Installing the M.2 SSD module Remove the new M.2 SSD module from its packaging. Insert the M.2 SSD module into its slot in the mainboard. Insert the thermal heat-sink module to the mainboard.
  • Page 29 Upgrading your Computer - 29 Secure the M.2 SSD and thermal module with screws. Replace the Graphic board. See Installing the Graphic board. Observe the Post-installation instructions on page 6.

  • Page 30: Odd Drives

    - Upgrading your Computer ODD drives The computer supports installation of one ODD drives. Open ODD door. Perform Pre-installation instructions on page 6. Push triangle icon for opening.
  • Page 31 PredatorSense - 31 PredatorSense In this section, you will find: • Introduction to the PredatorSense utility • How to use PredatorSense...

  • Page 32: Predatorsense

    - PredatorSense 2 PREDATORSENSE PredatorSense (DT) is an Acer proprietary utility to enhance the user experience of Gaming products on Microsoft Windows 10. The central idea of this utility is to provide a user interface to easily control fan speed, OverClocking and also display system information.
  • Page 33 Max frequency. Overclocking  Switch OC level in Normal level or Turbo level by Predator Sense. Provide Fan speed control in Auto, Gaming and Custom mode for fans including, Front fan and Back fan. And show the fan speed for fans. On the Custom fan speed, Fan control user can adjust the fan speed in percentage.
