Configuring Nudge Values; Activating And Using Nudge; Reset Nudge - Raven viper Installation & Operator's Manual

C 15
HAPTER
Refer to the Add Widgets to a Screen Layout section on page 138 to add a widget to a screen layout before
performing the following procedures.
NOTE: The nudge widgets also provide to access to some AB guidance tools. Refer to the Recalibrate AB
Guidance Path section on page 154, the Saving Guidance Paths section on page 154, or the Loading a
Saved Guidance Path section on page 155 for assistance with using these AB guidance tools during
field operations.

CONFIGURING NUDGE VALUES

To configure nudge distance setting for use during field operations:
1. Touch and hold the Nudge widget to access the Nudge and Swath prompt.
2. Tap the Unit Toggle button to the right of the Nudge 1 or Nudge 2 to select the desired measurement for the
nudge distance.
3. Touch the Nudge 1 or Nudge 2 value and use the on-screen keypad to set the nudge distance.

ACTIVATING AND USING NUDGE

To activate a nudge distance and adjust an AB guidance path during a field operation:
Nudge Status
1. Touch and hold the Nudge widget to access the nudge and swath prompt.
2. Tap the Nudge 1 or Nudge 2 button along the left side of the prompt to select the active nudge distance.
3. Touch the Nudge Left or Right button to adjust the displayed guidance path by the active nudge distance.
NOTE: If using the nudge arrow widget, tap the left or right arrows on the widget to adjust the displayed
guidance line by the active nudge distance right from the guidance view or mode.
4. The Status area on the on-screen widget will display the nudge distance and direction applied the guidance
path currently displayed.

RESET NUDGE

To remove any nudge distance applied to the current AB guidance path:
Nudge Status
1. Touch and hold the Nudge widget to access the Nudge and Swath prompt.
2. Select the Reset Nudge button to remove all nudge adjustments currently applied to the displayed guidance
path.
156
Unit Toggle
Nudge Widget
Nudge 1 or Nudge 2
Button
Nudge 1 or Nudge 2
Button
Viper/Viper 4+ Installation & Operation Manual
---
--
Nudge Nudge
Left Right
Reset Nudge
