Section 10 - Testing and Troubleshooting

10.1 One Man Walk Test - TEST ZONES

The one-man walk test feature is intended to allow a single service person the ability to test
each device without having to reset the panel each time a device is activated. While in test
mode, the panel will automatically reset after 3 seconds following any device activation.
This allows a service person to activate a device, verify the panel responds by sounding the
audible and visual notification appliances, then move on to the next device without going
back to the main panel to reset. The Test Zone feature will only activate outputs & devices
that are assigned to General Alarm Mode based on the options enabled as described
below.
One-man walk test mode is implemented by selecting the TEST ZONES option from the
Access Level 2 Main Menu.
Follow these steps to implement a one-man walk test using the TEST ZONES option:
1. Enter Access Level 2 operating mode as described in Section 7.3.1
2. Press the right navigational arrow key to access the Main Menu.
3. Scroll down to highlight the TEST ZONES option.
4. Press the right arrow key to select TEST ZONES.
5. From the Test Zones Menu use the up/down arrow keys to select which zone to test.
6. Press the right navigational arrow key to display the test options.
Local NAC ON - OFF
Use the up/down arrow keys to select ON or OFF. Setting this option to ON will make all
of the audible and visual notification circuits (NAC 1-4) activate for the 3-second duration
of each device tested. Setting this option to OFF disables the audible and visual
notification appliance outputs during test mode.
Panel Outputs ON-OFF
Use the up/down arrow keys to select ON or OFF. Setting this option to ON will make all
panel relay and voltage outputs function as they have been configured. Setting this
option to OFF disables the panel relay and voltage outputs during test mode.
Loop Outputs ON-OFF
Use the up/down arrow keys to select ON or OFF. Setting this option to ON will activate
SLC loop output devices such as SOM modules for audible and visual devices, but will
not activate R2M modules. Turning this option to OFF disables the SOM modules during
test mode.
