1. Setting batch quantities for coin rolls
• Press and hold the "+" button for approximately three seconds until "L" is
shown in the display. This automatically programs each coin denomination
for bank coin roll amounts as follows:
$2
$1
25¢
10¢
5¢
1¢
2. Setting other batch quantities
• Press "Set" until the desired denomination appears on the left part of the
screen.
• To assign a batch quantity for this denomination press the "BAT" button until
a desired batch quantity appears on the display
• (0, 10, 20, 25, 50, 80, 100, 120, 150, 200, 300, 400, 500). Fine adjustments to
batch quantity can by made by pressing "-" or "+" button.
• Repeat this procedure to set the desired batch quantities for other coin
denominations.
The C200 will stop when a desired batch quantity is completed for any of the
denominations. The denomination will be displayed on the left and the total
count for that denomination will be displayed on the right side of the screen.
NOTE: When operating in batch mode, the C200 will keep a running total for
each denomination coin. For example, after four batches of 50 pennies have
been dispensed, the C200 will stop and display:
200 (quantity reporting)
I
C
or
2.00 (value reporting)
I
C
12
25 (Canadian model only)
25
NOTE: Other countries
40
denominations and
50 capacities very by country)
40
50
To resume counting, press the "START/STOP" button.
Pressing the "C" button will reset the count and the machine will start batching
from zero.
The batch quantities you choose will be stored in the C200's internal memory and
will not be reset when the machine is turned off.

2.5 Clearing batch quantities

You may clear all batch quantities by pressing and holding the "-" button for
approximately three seconds. The C200 will then beep and display a "C" message
on the control panel, indicating all batch quantities have been reset to zero.

2.6 Using the coin tube attachments

The C200 coin tube attachments allow you to sort coins directly into preformed
paper bank roll wrappers.
To use the coin tube attachments, perform the following steps:
1. Remove the coin tray(s) for the
denomination coins that will be using
coin tubes.
2. Insert the appropriate pre-formed
paper wrapper in the coin tubes with
the crimped end down. Ensure the top
of the paper wrapper is below the top
lip of the coin tube as shown in Figure 1.
Cassida C200 coin counter/sorter/wrapper
Figure 1: Coin roll inserted into coin tube
13
