KD-R680S / KD-R480
CD RECEIVER
INSTRUCTION MANUAL
RÉCEPTEUR CD
MANUEL D'INSTRUCTIONS
RECEPTOR CON CD
MANUAL DE INSTRUCCIONES
JS_JVC_KD_R680S_KD_R480_K_C.indd 1
For customer Use:
Enter below the Model No. and Serial No. which are
located on the top or bottom of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
ENGLISH
FRANÇAIS
ESPAÑOL
B5A-1346-00 [K]
21/7/2016 5:13:26 PM
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for JVC KD-R680S
Summary of Contents for JVC KD-R680S
-
Page 1: Instruction Manual
ENGLISH FRANÇAIS ESPAÑOL KD-R680S / KD-R480 CD RECEIVER INSTRUCTION MANUAL RÉCEPTEUR CD MANUEL D’INSTRUCTIONS RECEPTOR CON CD MANUAL DE INSTRUCCIONES For customer Use: Enter below the Model No. and Serial No. which are located on the top or bottom of the cabinet. Retain this information for future reference. -
Page 2: Table Of Contents
CONNECTION How to read this manual • Operations are explained mainly using buttons on the faceplate of KD-R680S. • English indications are used for the purpose of explanation. You can select the display language from the menu. ( 5) • [XX] indicates the selected items. -
Page 3: Basics
BASICS Faceplate Remote control (RM-RK52) Volume knob Loading slot Display window Remote sensor (Do not expose to bright sunlight.) KD-R480 Pull out the insulation sheet when using for the first time. Detach button Attach Detach How to reset How to replace the battery Your preset adjustments will be erased except stored radio stations. -
Page 4: Getting Started
ON: Enables AM in source selection. ; OFF: Disables. ( 5) Set the clock and date PANDORA SRC * (For KD-R680S) ON: Enables PANDORA in source selection. ; OFF: Disables. ( 9) Press and hold Turn the volume knob to select [CLOCK], then press the knob. -
Page 5: Radio
RADIO GETTING STARTED CLOCK TIME SYNC ON: The clock time is automatically set using the Clock Time (CT) data in FM Radio Broadcast Data System signal. ; OFF: Cancels. CLOCK DISPLAY ON: The clock time is shown on the display even when the unit is turned off. ; OFF: Cancels. “ST”... - Page 6 If there is a station broadcasting a program of the same PTY code as you To return to the previous setting item, press have selected, that station is tuned in. For KD-R680S: Selectable only when SiriusXM Vehicle Tuner is connected. ( 11) Default: XX Selectable only when [ONCE] or [WEEKLY] is selected in step TUNER SETTING Only for FM source.
-
Page 7: Cd/Usb/Ipod/Android
ANDROID When connecting an Android device, “Press [VIEW] to install JVC MUSIC PLAY APP” is shown. Follow the instructions to install the application. You can also install the latest version of JVC MUSIC PLAY application on your Android device before connecting. For more information, visit <http://www.jvc.net/cs/car/>. - Page 8 Turn the volume knob to select a file, then press the knob. While in ANDROID source, press repeatedly. AUTO MODE : Control Android device from this unit via JVC MUSIC PLAY Quick Search (applicable only for CD, USB, and ANDROID source) application installed in the Android device.
-
Page 9: Pandora® (For Kd-R680S)
Pandora® (for KD-R680S) Preparation: Create and store a new station Install the latest version of the Pandora application on your device (iPhone/iPod touch), then create an account and log in to Pandora. Press • Select [ON] for [PANDORA SRC] in [SOURCE SELECT]. ( 4) Turn the volume knob to select [NEW STATION], then press the knob. -
Page 10: Iheartradio® (For Kd-R680S)
(for KD-R680S) Preparation: Search for a station Install the latest version of iHeart Link for JVC application on your device (iPhone/iPod touch), then create an account and log in to iHeartRadio. Press • Select [ON] for [IHEART SRC] in [SOURCE SELECT]. ( 4) Turn the volume knob to select a category, then press the knob. -
Page 11: Siriusxm® Radio (For Kd-R680S)
SiriusXM® Radio (for KD-R680S) Only SiriusXM® brings you more of what you love Start listening to listen to, all in one place. Get over 140 channels, including commercial-free music plus the best sports, Press repeatedly to select SIRIUS XM. news, talk, comedy and entertainment. Welcome to the Press world of satellite radio. - Page 12 SiriusXM® Radio (for KD-R680S) Using SiriusXM tuner models later than SXV200: This unit can SiriusXM Replay™ assign a maximum of 18 SmartFavorites channels. Initially, all preset channels are assigned as SmartFavorites. While listening to a channel..Press the volume knob.
- Page 13 SiriusXM® Radio (for KD-R680S) TuneScan™ CODE SET 1 Press the volume knob to enter [NEW CODE]. 2 Turn the volume knob to select a number. You can get a short preview of the songs that you have missed on each of 3 Press to move to the entry position.
-
Page 14: Aux
AUDIO SETTINGS Use a portable audio player Connect a portable audio player (commercially available). 3.5 mm (1/8") stereo mini plug with “L” shaped connector (commercially available) Portable audio player Select a preset equalizer Press repeatedly. Auxiliary input jack (or) Select [ON] for [BUILT-IN AUX] in [SOURCE SELECT]. ( 4) Press , then turn the volume knob within 5 seconds. - Page 15 AUDIO SETTINGS Default: XX AUDIO CONTROL EQ SETTING BASS BOOST LEVEL +01 to LEVEL +05 (LEVEL +01): Selects your preferred bass boost level. ; OFF: Cancels. PRESET EQ Select a preset equalizer suitable to the music genre. • Select [USER] to use the settings made in [EASY EQ] or [PRO EQ]. LOUDNESS LEVEL 01 /LEVEL 02: Boosts low or high frequencies to produce a FLAT/DRVN 3/DRVN 2/DRVN 1/HARD ROCK/HIP HOP/JAZZ/POP/R&B/...
- Page 16 (Mute) Connection via lineout terminals For connections through an external amplifier. ( 25) If [SUB.W/SUB.W] is selected: (For KD-R680S) – [FRQ 120HZ] is selected in [SUBWOOFER LPF] and [FRQ THROUGH] is not available. Audio signal through lineout terminal Setting on –...
-
Page 17: Display Settings
DISPLAY SETTINGS TEXT SCROLL * SCROLL ONCE: Scrolls the display information once. ; SCROLL AUTO: Repeats scrolling at 5-second intervals. ; SCROLL OFF: Cancels. COLOR (for KD-R680S) PRESET Select a color for buttons illumination. • COLOR 01 to COLOR 49 [COLOR 08] • USER: The color you have created for [DAY COLOR] or [NIGHT COLOR] Press and hold is shown. -
Page 18: References
• This unit cannot recognize a USB device whose rating is other than 5 V and exceeds 1 A. For: – Latest firmware updates and latest compatible item list – Any other latest information About iPod/iPhone Visit <http://www.jvc.net/cs/car/>. Made for - iPod touch (2nd, 3rd, 4th, 5th, and 6th generation) General - iPod classic •... - Page 19 REFERENCES About Android device Change the display information • This unit supports Android OS 4.1 and above. Each time you press , the display information changes. • Some Android devices (with OS 4.1 and above) may not fully support Android Open Accessory •...
-
Page 20: Troubleshooting
“IN DISC” appears. Make sure nothing is blocking the loading slot when you eject the disc. Cannot playback at [AUTO • Make sure JVC MUSIC PLAY APP is installed on the Android device. ( 7) MODE]. “PLEASE EJECT” appears. Press , then insert the disc correctly. - Page 21 “CHK DEVICE” Check the Pandora application on your device. “UPDATE APP” Make sure you have installed the latest version of the iHeart Link for JVC application on your device. “NO SKIPS” The skip limit has been reached. “PLS LOGIN” You haven’t log in. Log in again.
-
Page 22: Specifications
Reset the unit ( 3) Usable Sensitivity (S/N = 20 dB) 29 dBμ (28.2 μV) Contact (USA only) Laser Diode GaAIAs Call: 1-800-252-5722 ( or ) visit: <http://www.jvc.com> Digital Filter (D/A) 8 times over sampling Spindle Speed 500 rpm — 200 rpm (CLV) Wow & Flutter Below measurable limit Frequency Response (±1 dB) -
Page 23: Installation/Connection
INSTALLATION/CONNECTION SPECIFICATIONS Warning USB Standard USB 1.1, USB 2.0 (Full speed) • The unit can only be used with a 12 V DC power supply, negative ground. Compatible Devices Mass storage class • Disconnect the battery’s negative terminal before wiring and mounting. File System FAT12/16/32 •... - Page 24 INSTALLATION/CONNECTION Installing the unit (in-dash mounting) Part list for installation (A) Faceplate Do the required wiring. ( 25) Hook on the top side (B) Trim plate Orientate the trim plate as Dashboard of your car illustrated before fitting. Bend the appropriate tabs to (C) Mounting sleeve hold the sleeve firmly in place.
-
Page 25: Wiring Connection
We recommend installing the unit with a commercially available custom (not supplied) wiring harness specific for your car and leave this job to professionals for your safety. Consult your car audio dealer. KD-R680S: Expansion port (12 V 500 mA) Output terminals To the optional SiriusXM Vehicle Tuner... -
Page 26: Caution
• Consult the dealer or an experienced radio/TV technician for help. • Android is trademark of Google Inc. This product contains a CR Coin Cell Lithium Battery which contains Perchlorate Material—special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate © 2016 JVC KENWOOD Corporation 081 DTSMDTJEIN JS_JVC_KD_R680S_KD_R480_K_C.indd 2 9/5/2016 1:55:04 PM...
Need help?
Do you have a question about the KD-R680S and is the answer not in the manual?
Questions and answers
Need a picture of the wire colors coming out of the plug
The wire colors for the JVC KD-R680S plug are:
- Blue/white: To amplifier (Remote, 200 mA max.)
- Orange/white: Illumination
- Yellow: Battery 12 V
- Red: Ignition 12 V (Separate red wire)
- Black: Ground
- Gray: Front speaker (right)
- Gray/black: Front speaker (right, negative)
- White: Front speaker (left)
- White/black: Front speaker (left, negative)
- Purple: Rear speaker (right)
- Purple/black: Rear speaker (right, negative)
- Green: Rear speaker (left)
- Green/black: Rear speaker (left, negative)
- Brown: Not used
*Note: Firmly connect the ground wire of the amplifier to the car’s chassis to avoid damage.
This answer is automatically generated
