- Page 1 ZENMUSE X5S User Manual V1.2 2017.01...
-
Page 2: Read Before The First Flight
Zenmuse X5S. Refer to this Zenmuse User Manual for detailed information. Getting more information Visit the following webpage for more information about the Zenmuse X5S. http://www.dji.com/zenmuse-x5s/info#video © 2017 DJI All Rights Reserved. -
Page 3: Table Of Contents
Overview Getting Started Read the information below before setting up your Zenmuse X5S Supported Devices Supported Lenses for the DJI Inspire 2 Required Lens Accessories Installing the Camera Lens Mounting the Zenmuse X5S to the aircraft Mounting the Zenmuse X5S to the Inspire 2... -
Page 4: Product Profile
Burst and AEB is available, with up to 14 stills. When the DJI™ CINESSD™ is in use, the Zenmuse X5S is able to record lossless videos with a bitrate of 5.2 Gbps in the CinemaDNG format or capture DNG stills at 20fps continuously. -
Page 5: Overview
Getting Started Read the information below before setting up your Zenmuse X5S Supported Devices The Zenmuse X5S can be attached to the following device, and will be compatible with other DJI devices in the future. DJI Inspire 2 Supported Lenses for the DJI Inspire 2 The Zenmuse X5S currently supports the following lenses, and will support additional lenses in the future. -
Page 6: Required Lens Accessories
Required Lens Accessories The performance of the gimbal is affected by the weight of the camera. The following table shows the recommended DJI Balancing Ring, Balancing Cap, filter and lens hood required for each lens model. Details are shown as below. -
Page 7: Installing The Camera Lens
ZENMUSE X5S User Manual Installing the Camera Lens The following steps use the DJI MFT 15mm f/1.7-16 ASPH to demonstrate mounting a camera lens to the camera body. Be sure to power off the battery before installation. 1. Remove the camera body cap. -
Page 8: Mounting The Zenmuse X5S To The Aircraft
ZENMUSE X5S User Manual Always power off the battery during installation or removal. It is recommended to wrap a dust cover around the lens to prevent contamination. DJI produces dedicated dust covers for the DJI MFT 15mm f/1.7 ASPH and the Panasonic Lumix 15mm f/1.7 . -
Page 9: Mechanical Range
FPV camera. 6. C2 Button 2. Recording Button Set in DJI GO 4 app. Press once to start video recording. Press 7. C1 Button again to stop recording. Set in DJI GO 4 app. -
Page 10: Dji Go 4 App
1. Power on the remote controller and the aircraft. 2. Connect the remote controller and your mobile device via a USB cable. 3. Launching DJI GO 4 app after successful connection, and the live HD video stream will begin. Camera Operation Touch Interface The touch interface can be used for capturing photos, recording videos and playback. -
Page 11: Basic Shooting
Tap the Shutter/Record Switch to select Shutter. Tap the button to take photos. Single shooting is set by default. Choose from one of the shooting modes via the DJI GO 4 app. Tap -> -> Video / Photo Setting -> Photo Or tap the Current Camera Settings to quick set. -
Page 12: Photo Styles
2. Sunny / Cloudy / Incandescent / Neon Choose one of these modes if natural-looking colors cannot be achieved through photo styles. 3. Custom Set a value to compensate for a specific light source. © 2017 DJI All Rights Reserved. -
Page 13: List Of Settings
4096×2160, 3840×2160 50/59.94p, up to 4.0Gbps ProRes 5.2K: 5280×2160 23.976/24/25/29.97p, 422 HQ @1.3Gbps 4K: 3840×2160 23.976/24/25/29.97p, 422 HQ @900Mbps 4K: 3840×2160 23.976/24/25/29.97p, 4444 XQ @2.0Gbps Micro SD: MP4/MOV (H.264, H.265) Video Format SSD: CinemaDNG (JEPG Lossless) ProRes (422HQ、4444XQ) © 2017 DJI All Rights Reserved. -
Page 14: Managing Your Photos And Videos
* Manual lens calibration is required when used for the first time. Incorrect calibration will result in an inability to focus to infinite. Calibrate camera in the camera setting page in the DJI GO 4 app. Managing your Photos and Videos... -
Page 15: Update Firmware
1. Power on the Intelligent Flight Battery, and toggle the USB Mode Switch up. 2. Connect the aircraft and your mobile device via an appropriate USB cable. 3. Follow the on-screen instructions in the DJI GO 4 app to upgrade. Ensure to connect to the Internet when downloading the firmware. -
Page 16: Appendix
Video: 100-6400 Electronic Shutter Photo: 8 s -1/8000 s Speed Video: 1/24 s -1/8000 s Field of View DJI MFT 15mm F1.7 ASPH 72° Micro SD: Single Shot, Multiple(3/5/7/10/14frames), Still Photography AEB(3/5bracketed frames at 0.7EV bias), Timed Modes Shot(2/3/5/7/10/15/20/30/60s) SSD: RAW Burst (3/5/7/10/14/ ∞frames) ©... - Page 17 Sandisk Extreme 64GB UHS-3 MICROSDXC aircraft) Panasonic 32GB UHS-3 MicroSDHC Panasonic 64GB UHS-3 MicroSDXC Samsung PRO 32GB UHS-3 MicroSDHC Samsung PRO 64GB UHS-3 MicroSDXC Samsung PRO 128GB UHS-3 MicroSDXC Default Lens Name DJI MFT 15mm F1.7 ASPH © 2017 DJI All Rights Reserved.
- Page 18 Pitch: -130°to +40°; Pan: ±320°; Roll: ±20° Max Controllable Speed Pitch: 180°/s; Pan:270°/s; Roll:180°/s Zenmuse X5S does not support file storage. Please save your photos and videos in the Micro SD/SSD cards inserted in the aircraft. © 2017 DJI All Rights Reserved.
-
Page 19: 2017 Dji All Rights Reserved
DJI Support http://www.dji.com/support This content is subject to change. Download the latest version from http://www.dji.com/zenmuse-x5s If you have any questions about this document, please contact DJI by sending a message to DocSupport@dji.com. Copyright © 2017 DJI All Rights Reserved.
