Important! Switch the machine off when you:
• e.g. carry out cleaning or maintenance work, or convert the machine to
another function
• store it in a suitable room to avoid any unauthorised use of the unit
• leave it standing without supervision
In addition, you should remove the key from the key-switch and prevent the
machine rolling away ( for example, by placing a wedge under the machine).
Store the machine in a dry, dust-free room with a corrosion-free atmosphere.
The temperature must not fall below +10 ° C or exceed +35 ° C. Low
temperatures, damp and dust can significantly reduce the service life of the
electrical components.

Overview

2 2 2 2 1 1 1 1
3 3 3 3
4 4 4 4
5 5 5 5
6 6 6 6
7 7 7 7
8 8 8 8
9 9 9 9
10 10 10 10 11 11 11 11
Operator panel
1
Speed control (drive and reverse)
2
Emergency Stop button
3
Steering and horn
4
Power supply cordfor the internal battery charger
5
Suction hose
6
Running board with safety switch
7
Mounting pedal for squeegee
8
Squeegee
9
Squeegee lock
10
Squeegee holder
11
Manual unlocking of the brake (the button must be held down!)
12
Chargng plug for the external battery charging unit (only for non BMS
13
machines)
Brush unit
14
Adjustment lever for tools
15
Full recovery tank probe
16
Recovery tank
17
38

EU Declaration of Conformity

We
JohnsonDiversey Switzerland
CH-9542 Münchwilen
hereby declare that the product described below both in this basic design and
construction and in the version marketed by us conforms to the relevant safety-
and health-related requirements of the appropriate EU Directive.
This declaration shall cease to be valid if modifications are made to the product
without our approval.
Product: scrubber dryer
Name: swingo XP
Model: CO75XP.2 (24Vdc/1200W)
CO75XP.2X (230-240V~/50-60Hz/1200W)
Applicable EU Directives:
Machinery Directive (98/37/EEC) in version 98/79/EEC
EMC (Electro Magnetic Compatibility) (89/336/EEC)
in version 98/13/EEC
Harmonised standards applied:
EN 60335-1:2002+A11:2004+A1:2004 / EN 60335-1/A12:2006-03/
EN 60335-1/A2:2006-08 / EN 60335-2-72:1998+A1:2001/
EN 50366:2003+A1:2006/
EN 55014-1:200+A1:2001+A2:2002 / EN 55014-2:1997+A1:2001/
EN 61000-3-3:2006 / EN 61000-3-3:1995+A1:2001+A2:2005
It is ensured through internal measures that series-production units conform at
all times to the requirements of current EU Directives and relevant standards
Dipl. Ing. (FH) D.Windmeisser
The signatories act on behalf of company management and with full power of
attorney.
26 26 26 26 25 25 25 25
12 12 12 12 13 13 13 13 14 14 14 14 15 15 15 15
Drainage hose
18
Flex tank with dosing cup
19
Half-full level (red line)
20
Max. filling level (red line)
21
Solution supply pipe and filter
22
Dirt sieve
23
Vacuum air filter
24
Maintenance cap
25
Seal for the tank lid
26
Dipl. Ing. (FH) P. König
24 24 24 24 23 23 23 23 22 22 22 22
16 16 16 16 17 17 17 17 18 18 18 18
21 21 21 21
20 20 20 20
19 19 19 19
