02-33
8627-03
The front air bag system is activated mainly by the signal from the front impact sensor
assembly. The SDM unit assembly compares this signal with its longitudinal/lateral G sensor
values to inflate the front air bag.
1) Mounting Location
Front impact sensor
Front impact sensor
assembly (RH)
assembly (LH)
AIR BAG SYSTEM
korando 2010.10
