Component Replacement
- electrical -
C510
1223-6749 Rev 7
©
Sony Ericsson Mobile Communications AB – Company Internal

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C510 and is the answer not in the manual?

Questions and answers

Related Manuals for Sony Ericsson C510

Summary of Contents for Sony Ericsson C510

  • Page 1 Component Replacement - electrical - C510 1223-6749 Rev 7 © Sony Ericsson Mobile Communications AB – Company Internal...

  • Page 2: Table Of Contents

    3.1 Shield Can Fence Modifications ............7 3.2 Additional Repair Info ................8 Revision History ................10 For general information about electrical repair related issues, refer to 1220-1336: Generic Repair Manual - electrical 1223-6749 Rev 7 © Sony Ericsson Mobile Communications AB – Company Internal 2(2)

  • Page 3: Replaceable Components

    1 (2,3,4, etc.) = Proceed to ‘Additional Repair Info’ for further instructions in the indicated section(s). CALIBRATION C = Calibration of the phone is required after replacing the component Calibration to be done by authorized centers only! 1223-6749 Rev 7 © Sony Ericsson Mobile Communications AB – Company Internal 3(3)
  • Page 4 N4103 IC Driver 1201-8077 P BGA P BGA N4200 Trans N-ch FET RYN901936/1 S2401 Switch side push RMD10116/9R1A S HA/ST Switch side push S HA/ST S2402 RMD10116/9R1A 1223-6749 Rev 7 © Sony Ericsson Mobile Communications AB – Company Internal 4(4)
  • Page 5 Filter 400.0 MHz KNA16400 – W5 1608(1.6x REV50146/1 S HA Z4201 Filter 400.0 MHz KNA16400 – W5 1608(1.6x REV50146/1 S HA Z4202 Filter 400.0 MHz KNA16400 – W5 1608(1.6x REV50146/1 S HA 1223-6749 Rev 7 © Sony Ericsson Mobile Communications AB – Company Internal 5(5)

  • Page 6: Component Placing

    Component Replacement Repair Drawing Additional Soldering Process/ Component Placing To access the Component Placing document, double-click the icon below. Applicable for on-screen viewing only – icon not shown on hard-copies. 1223-6749 Rev 7 © Sony Ericsson Mobile Communications AB – Company Internal 6(6)

  • Page 7: Repair Actions

    • after rework the height of the frame should not be affected • it should not be visible that rework has been carried out when the lid has been mounted Side Primary Side Secondary 1223-6749 Rev 7 © Sony Ericsson Mobile Communications AB – Company Internal 7(7)

  • Page 8: Additional Repair Info

    X2405 Protect the antenna connector with capton tape! X1210,L2401,L2402,L2403,L2404,L2406,L2410,L240 5,V2400,V2401,Z2400 Protect the system connector with capton tape! X1401,N1400,D2404,D2402,N3101,N2402,L2407,V24 20,V2421 Protect the system connector with capton tape! 1223-6749 Rev 7 © Sony Ericsson Mobile Communications AB – Company Internal 8(8)
  • Page 9 Protect the switch and BtB connector with capton tape! N2403, V2202 Protect the BtB connector and system connector with capton tape! V2402 Protect the BtB connector with capton tape! 1223-6749 Rev 7 © Sony Ericsson Mobile Communications AB – Company Internal 9(9)

  • Page 10: Revision History

    2009-03-12 Add comment for tiger 125 2009-07-13 Corrected position with Z4200, Z4201 and Z4202. 2009-09-17 Remove SL5 components N2000,D2000 and XD2000 2009-08-18 Add calibrating N1220 Tiger module 1223-6749 Rev 7 © Sony Ericsson Mobile Communications AB – Company Internal 10(10)
