UNDER THE COUNTER 9" TV,
AM/FM RADIO, TELEPHONE &
OWNER'S and INSTALL MANUAL
•
Slot-in DVD Player & 9" TFT LCD Monitor
•
Multi-function Remote Control
•
Built-in Hands Free Speaker Phone
•
Cable Ready 125 Channel TV Tuner
•
AM/FM Radio
•
2 A/V Inputs
•
Intercom Ready
•
Internal Stereo Speakers
•
Under Cabinet / Table Top Mounting
VE926

DVD PLAYER

0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VE926 and is the answer not in the manual?

Questions and answers

Related Manuals for Audiovox VE926

Summary of Contents for Audiovox VE926

  • Page 1: Dvd Player

    VE926 UNDER THE COUNTER 9” TV, AM/FM RADIO, TELEPHONE & DVD PLAYER OWNER’S and INSTALL MANUAL • Slot-in DVD Player & 9” TFT LCD Monitor • Multi-function Remote Control • Built-in Hands Free Speaker Phone • Cable Ready 125 Channel TV Tuner •...
  • Page 2 WARNING – To prevent fire or shock hazard, do not expose this unit to moisture. CAUTION CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL This symbol alerts the user to the fact that exposed “dangerous voltages”...
  • Page 3 - Consult with the dealer or an experienced radio/TV technician for help NOTE: Record your unit’s Model Number and Serial Number in the space provided below. Refer to these numbers if you need to call your AUDIOVOX dealer regarding this product. MODEL No. _____________________ SERIAL No.

  • Page 4: Important Safety Information

    IMPORTANT SAFETY INFORMATION Read Instructions – All the safety and operating instructions should be read before the product is operated. Retain Instructions – The safety and operating instructions should be retained for future reference. Heed Warnings – All warnings on the product and in the operating instructions should be adhered to.
  • Page 5 13. Power-Cord Protection – Route the power supply cord in a manner that protects it from being stepped on or pinched by items placed on it. Pay particular attention to the power cord’s plug, and the point where the power cord exits from the product. 14.
  • Page 6 21. Replacement Parts – When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or that have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock or other hazards. 22.

  • Page 7: Table Of Contents

    Setting the Air TV Mode Setting the Speaker Mode Setting the Intercom Mode Setting the Presets (In FM, AM or TV Modes) 19 Using the DVD Player Inserting and Ejecting the Disc Playback and Stop Searching for a Specific Scene/Song...

  • Page 8: Contents Of Package

    CONTENTS OF PACKAGE 1. VE926 2. Hardwa re bag A. 2” Mountin g screws (4) B. 2-1/2” Mounting screws C. 3”Mounting screws (4) D. Foot (4) E. Hole cap 3. Re mote Control 4. Multi Height Spac er (4) 5. Battery (AAA) 6.

  • Page 9: Under Cabinet Installation

    TV antenna or cable connection and telephone jack will facilitate a neat, easy installation. Do not mount the VE926 above a range or oven. Be sure that the location chosen will provide adequate access to the electrical connections on the rear of the unit before continuing.

  • Page 10: Countertop/Desktop Installation

    COUNTERTOP/DESKTOP INSTALLATION NOTE: Use caution to avoid damaging the LCD screen and the main unit when converting this unit from an under-counter unit to a countertop unit. Leave the protective plastic on the screen until this procedure is completed. Place the unit (with the screen facing up) on a soft padded surface. Pivot the screen so that it is perpendicular to the front of the unit and then turn it sideways.

  • Page 11: Front Panel Controls

    FRONT PANEL CONTROLS ON/OFF BUTTON – Power ON/OFF and Standby Condition(Time Display). SET BUTTON – Press this button to set the TIME, ALARM, TV Mode or Speaker Mode. TEL BUTTON – Selects the Hands-free speakerphone function. SOURCE BUTTON – Selects the TV, FM, AM, AV1, AV2 and DVD functional modes. T/F BUTTON –...

  • Page 12: Channel Buttons

    FM ANTENNA – Allows the VE926 to be connected to a 75-Ohm external antenna for the reception of FM broadcast signals. AM ANTENNA - Allows the VE926 to be connected to an external antenna for the reception of AM broadcast signals.

  • Page 13: Lcd Control Functions

    LCD Control Functions 1. MENU Button – When pressed, the LCD control MENU is displayed. 2. SEL Button – Used to enter the picture menu. Highlight the menu ite the UP/DOWN buttons and then press Select to adjust the highlighted item.. UP Button –...

  • Page 14: Battery Installation

    BATTERY INSTALLATION (Rear View, Battery Size AAA)

  • Page 15: Remote Control Functions

    REMOTE CONTROL FUNCTIONS (1) EJECT (2) DVD (3) TV (4) SETUP (5) SEEK DN, SEEKUP (6) MENU (7) FR( ■ (8) STOP( (9) PREV (I (10) Digit 0-9 Select (11) TITLE (12) DISPLAY (13) SUB TITLE (14) AUDIO (15) SCREEN (16) ANGLE (AP) (17) ON/OFF (18) A/V...
  • Page 16 DVD REMOTE FUNCTION (1) EJECT: Press this button to Eject and Load the disc tray. (2) DVD: Press this button to select DVD mode of operation. (4) SETUP: Displays setup menu for initial user settings. (5) SEEK DN/UP (21) CH+/-: For selecting item on menu. (6) MENU: For displaying the menu contained in the disc.
  • Page 17 (5) SEEK DN/UP: Use these buttons to advance to the next higher or lower station. (19) AM/FM: Each time this button is pressed, the VE926 will alternate between AM and FM radio (21) CH +/-: Use these buttons to advance to the next higher or lower channel.

  • Page 18: Operation

    SETTING THE TIME NOTE: All settings (except setting the presets) are performed with the VE926 turned OFF. 1) Press the SET button and the minutes will flash. 2) Use the CH up/down button to set the minutes.

  • Page 19: Setting And Activating The Alarm

    SETTING and ACTIVATING the ALARM NOTE: The VE926 must be turned “OFF” when performing the following procedure. 1) Press the SET button twice to enter the alarm mode, press the P3 button to toggle between the active and deactivated mode.

  • Page 20: Setting The Cable Tv Mode

    SETTING THE CABLE TV MODE 1) Press the SET button three times to enter the TV/Cable configuration mode. 2) CABLE or AIR will appear on the display. 3) Press the SEEK button to select Cable mode. 4) Press the CH UP/DOWN button(s) to select the desired cable mode (STD/IRC/HRC). 5) When the desired mode is reached, press the ON/OFF button to confirm.

  • Page 21: Searching For A Specific Scene/Song By Selecting The Chapter Number

    PLAY button to begin watching the movie. 4. To eject the disc, press and hold the * Discs playable through DVD player – DVD, CD, CD-RW with MP3. Playback and Stop 1. To temporarily stop playback, press the STOP button once. The player memorizes the exact position where it was stopped, and it will resume playback again from that position.

  • Page 22: Repetitive Playback

    Repetitive Playback –To Repeat a Specific Section 1. Press the REPEAT button once to enable the REPEAT selection screen, follow by pressing the REPEAT button till REPEAT CHAPTER is displayed, the current chapter or track will be replayed repetitively (CHPTER REPEAT ON). 2.

  • Page 23: Viewing Different Angles

    Viewing Different Angles Angle indicator appears on the upper part of the LCD display. When the Angle indicator appears, press the ANGLE button to view the screen from various angles. * This function may not be incorporated in some titles. Viewing the Main Disc Menu A DVD is divided into sections called titles and chapters.
  • Page 24 During playback press DISPLAY to display the current disc playback information. Press display again to remove the display. 1. The type of disc. 2. The number of current title. 3. The number of total titles. 4. The number of current chapter. 5.

  • Page 25: Playing Audio Cds

    PLAYING AUDIO CDS When playing an audio CD the display will automatically display the disc playback information. The options below show you what information is displayed. Press the ‘DISPLAY’ button to remove the display. 1. The current track. 2. The number of total tracks. 3.
  • Page 26 1. Press the button screen. 2. Press ENTER to select the highlighted folder. All songs available under the selected will be lis ted. 3. Use button to choose a song from the list, then press ENTER to play the selected song.

  • Page 27: Playing A Jpeg File

    YING A JPEG FILE 1. Insert the JPEG Disc into tray. 2. Select JPEG fil e by pressing the “UP/DOWN” button. 3. You can preview the JPEG file b 4. Pressing the left or right button will rotate the JPEG in 5.
  • Page 28 2. Press ENTER, the following screen will appear. 3. Use the buttons to highlight the desired menu item. 4. Press ENTER button to display the sub-menu. 5. Each sub-menu item provides a number of option items to its right. Use the to highlight the desired option item for selection.
  • Page 29 VIDEO Menu 1. Press the SETUP button to display the main menu (see sample screen under LANGUAGE Menu) 2. Press the button to highlight Video and press ENTER one time. Use the following screen to select screen aspect ratio. * 4:3 PS : When the player is connected to a normal TV, and a wide picture is shown on the full scree * 4:3 LB : When the player is connected to a normal TV, and a wide picture is shown on the scree...
  • Page 30 Rating Menu Press the SETUP button to display the main menu (see sample screen under LANGUAGE Menu). Use to select parental Rating: Kid Safe. CHANGE PASSWORD & RATING 1. Select Rating by 2. Enter the current password and press ENTER button (unlock). 3.

  • Page 31: Technical Specifications

    TECHNICAL SPECIFICATIONS GENERAL Power Supply Operating Temperature Operating Humidity Body Size Weight DISPLAY LCD Illumination Backlighting Life Expectancy Resolution Screen MISC TV Channels TV System Radio Frequency Range Audio output : AC100-240V ~50/60Hz 40watts : 0°~40°C / 32°~104°F : 10% ~ 75% : 400 X 280 X 56mm / 15.8”...

  • Page 32: Troubleshooting Check List

    TROUBLESHOOTING CHECK LIST Problem Power does not turn on Disc fails to play Camera angles cannot be changed Subtitles cannot be changed Vocal languages (AUDIO) cannot be changed No sound output Remote control doesn’t work Setup menu does not operate TV MODE functions do not work •...

  • Page 33: 90-Day Limited Warranty

    Applies to Audiovox Video Products AUDIOVOX ELECTRONICS CORP. (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within ninety (90) days from the date of original purchase, such defect(s) will be repaired or replaced with reconditioned product (at the Company's option) without charge for parts and repair labor.
