Installation and Operation Manual
Low Profile Television
6.4" LCD Drop Down Under Counter TV / Video Monitor
ON/OFF
All manuals and user guides at all-guides.com
VE-640
TV
FM/AM
TV
FM/AM
A/V
TEL
AM
PM
FEATURES
Multi-Function Remote Control
Built-In Telephone Mode
Cable Ready 125 Channel Tuner
Internal Stereo Speakers
Under Cabinet Mounting
A/V Input
SEEK
CH 1
SET
CH 2
CH 3
CH 1
CH 2
CH 3
AUDIOVOX
-1-
CH
VOL
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Audiovox VE-640
Summary of Contents for Audiovox VE-640
- Page 1 All manuals and user guides at all-guides.com Installation and Operation Manual VE-640 Low Profile Television 6.4” LCD Drop Down Under Counter TV / Video Monitor SEEK FM/AM CH 1 FM/AM CH 2 ON/OFF CH 3 CH 1 CH 2 CH 3...
- Page 2 6.4” LCD Drop Down Under Counter TV / Video Monitor The purpose of this Addendum is to replace the “SETTING ALARM” procedure found in the Operation section of the VE-640 Operation and Installation Manual (Pg. 13). SETTING and ACTIVATING ALARM NOTE: The VE640 must be turned “OFF”...
-
Page 3: Important Safety Information
1) Unplug the unit before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. 2) Use only Audiovox approved accessories. 3) Do not install this video product where it is likely to be exposed to water. -
Page 4: Included In This Kit
All manuals and user guides at all-guides.com INCLUDED IN THIS KIT 1 VE-640 Television TOOLS REQUIRED 2 Remote Control Unit (PN 136C2037) Philips Head Screwdriver 3 AC Power Cord (PN 136B2038) Centerpunch 4 Mounting template 1/8” Drill Bit 5 Hardware Bag (PN 1501395) Electric Drill 3/4”... -
Page 5: Under Cabinet Installation
Connect your TV antenna or cable system to the antenna connector on the rear of the VE-640. Plug the AC wire into the AC input connector on the rear of the VE-640 and then into the wall. 10) If using the speaker phone feature, plug the VE-640 into a phone jack. -
Page 6: Front Panel Controls
6) CH 1 INDICATOR-When illuminated, 20) AUDIO-VIDEO BUTTON (AV)-Press this the VE-640 is tuned to the preset channel 1. button to view an external A/V source that is 7) CH 2 INDICATOR-When illuminated, the plugged into the rear A/V jacks. -
Page 7: Rear Panel Connections
TV-ANT. AUDIO-IN VIDEO-IN 5) VIDEO INPUT-Connect to the video output from 1) FM ANTENNA- Allows the VE-640 to be external A/V source. connected to an external antenna for the 6) TELEPHONE JACK-Connect to Telco jack for reception of FM broadcast signals. -
Page 8: Remote Control Functions
2. NUMERICAL BUTTONS (1- 9, 0) Use these buttons to make a direct channel selection. The channel number chosen will be displayed on the front panel of the VE-640. Channel selection is carried out using the 0-9 keys. 3. CHANNEL UP/DOWN BUTTONS (CH) Use these buttons to advance to the next higher or lower channel. - Page 9 Pivot the screen forward until a comfortable viewing angle is reached. The screen may also be rotated from side to side. Do not force the screen beyond its rotational limit . The VE-640 is now ready for use. Pressing the power button on the TV or the remote will turn the system on or off. Remember to turn the unit off and pivot the screen to the closed position when not in use.
- Page 10 Verify Tuner setting matches Antenna / Cable broadcast system. Remote control will not function Verify that the sensor on the VE-640 is not obstructed. Verify that the infrared LED on the transmitter is not obstructed. Check the condition of the remote control batteries.
-
Page 11: Technical Specifications
All manuals and user guides at all-guides.com TECHNICAL SPECIFICATIONS Illumination: CCFL Edge Lit Tube Backlighting Life Expectancy: 10,000 Hrs. Pixels: 224, 640 Resolution: 960 x 234 Power Supply: 120 VAC 60 Hz, 22 Watts Operating Temperature: 0° - 40° C Frequency Range: AM 520 kHz-1710 kHz FM 87.5 MHz-108 MHz... -
Page 12: 90-Day Limited Warranty
Applies to Audiovox Video Products AUDIOVOX ELECTRONICS CORP. (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 90 days from the date of original purchase, such defect(s) will be repaired or replaced with reconditioned product (at the Company's option) without charge for parts and repair labor. - Page 13 All manuals and user guides at all-guides.com 128-6124 © Copyright 2001 Audiovox Corp. 150 Marcus Blvd. Hauppauge, NY 11788 -13-...
