- Page 1 DEH-4568 ® EntelliGuard Digital Test Kit User’s Guide imagination at work Courtesy of NationalSwitchgear.com...
- Page 2 While efforts have been made to ensure accuracy, the information contained herein does not cover all details or variations Ground Fault function of EntelliGuard Trip Units, the ground fault in hardware and software, nor does it provide for every possible protection of the trip unit will not be active.
- Page 3 • 24VDC power supply – CUI Inc., Part Number EMS 240075- P5P-SZ or equivalent. Voltage polarity is as follows: CAUTION: With the Test Mode enabled, the EntelliGuard trip unit will not provide correct protection to the system, which may • Serial Communication Test Kit cable (6 ft DB9 (male)/DB9 result in a trip below desired levels.
- Page 4 Cables: The Test Kit is provided with a 15-pin trip unit cable racked out). This test is used when performing primary injection that connects to the side (EntelliGuard trip unit port) of the testing of overcurrent or short circuit protection features on 1 test kit and to the front of the trip unit.
