Generac Power Systems 004812-0 Owner's Manual page 90

FS
GP GP GP
GND
LFP
HTS
WLS
0
1
12V BAT
LEGEND:
ALT: ALTERNATOR - DC
BAT: BATTERY
BC: BATTERY CHARGER
CC: CONTACTOR - CONTROL
EC1: CONNECTOR - ENGINE 1(BLACK)
EC2: CONNECTOR - ENGINE 2(GRAY)
EC3: CONNECTOR - ENGINE 3(BASETANK)
EH: ENGINE HEATER
FLS: SENDER - FUEL LEVEL
FS: SOLENOID - FUEL
GFB: SWITCH - GENERATOR FLUID BASIN
GND: GROUND
GP: GLOW PLUG
HTS: SWITCH - COOLANT HIGH TEMP.
LFP: SWITCH - LOW FUEL PRESSURE
MP: MAGNETIC PICKUP
OPS: SENDER - OIL PRESSURE
PHC: CONTACTOR - PRE-HEAT
RB: SWITCH - RUPTURE BASIN FLOAT
SC: CONTACTOR - STARTER
SM: STARTER MOTOR
WLS: SENSOR - WATER LEVEL
WTS: SENDER - WATER TEMP.
1
16
2
219
3
0 0
GND
GP
MP
601
OPS
WTS
85
0 0 ALT
2
) ( +
(-)
(-) ) ( +
BLACK
SM
SC
0 0
PHC C
0 0
PHC
218
157
2
0/BLACK
1
0/BARE
79/CLEAR
69
68
49
218
RED D
SC
218
16
FLS
590
575
CC
218
0
0/BLACK
218
79/CLEAR 7
218
0
0
218
CC
GND
591
N.C.
GFB
N.O.
RB
218 1
56 3
150 4
0 6
0 7
219 8
49 10
1
0/BARE 2
0 3
0 6
601 7
69 8
68 9
85 11
12
BLACK
BC WHITE EH
GREEN
120VAC
UTILITY
SUPPLY
591 1
0 0 2
0 0 3
447 4
567 6
575 7
590 8
