ITEM QTY PART NO.
DESCRIPTION
1
1
01692
Threaded Insert
2
1
01694
Corner Bracket
3
1
11060-002
Handle Subassembly
4
1
08014
Pulley Assembly 4.50
5
1
3900-441
Cybex Decal 8.50 Vert. Black
5
1
3900-442
Cybex Decal 8.50 Vert. Silver
6
1
4000Y316
Caution Decal
7
2
4605-501
Grip
8
1
4535-324
Counterweight
9
1
4615-202
Leg Bar
10
2
4700-019
Flange Bearing .62 x .92 x 1.50 L
11
1
4800-252
Top Weight 16-4 x 12
12
1
4800-381
Warning Decal
13
1
4800-554
Weight Plate Decal (12.5-150) (Not Shown)
14
2
4800-531
Weight Stack Guide Rod
15
1
4800-701
Weight Stack Guard
16
1
4800-570
Cable Guard
17
1
4800-580
Pivot Shaft
18
1
4855-002
Weight Stack Cable
19
1
4855-200
Frame
20
1
4855-201
Cam
21
1
4855-317
Adjusting Decal
22
1
4855-598
Placard Decal
23
1
BH030207
Weight Selector Pin
24
2
BR030206
Retaining Ring
25
4
BR030214
Retaining Ring .625
26
2
BR110203
Internal Retainer Cap 17 mm
27
2
PR060005
Weight Bumper
28
1
C-ZA000200 Half Weight 4 x 12
29
2
FB030232
Radial Bearing 17 mm ID (Ext Race)
4855 - Prone Leg Curl
ITEM QTY PART NO.
30
2
HC702817
31
1
HC702826
32
2
HN704901
33
1
HP286819
34
4
HT102214
36
1
JC702824
37
1
JN714200
38
1
JN714400
39
7
PP090000
40
2
PP090210
41
1
4505-331
42 A
1
4800-006
42 B
1
4800-093
43 A
1
4800-009
43 B
1
4800-092
44 A
1
4800-011
44 B
1
4111S060-0 Wear Cover
45
4
HC702830
46
2
HC702834
47
2
3900-445
47
2
3900-446
50
1
4800-382
51
11
4005C062
52
1
4000-328
53
2
11090-374
54
2
11090-376
55
1
51198
56
2
HF449063
57
2
JC620422
58
6
JS347400
DESCRIPTION
SHCS .375-16 x 1.00
SHCS .375-16 x 2.00
Nylon Locknut .375-16
Spiral Pin .188 x 1.12
Tap Screw #10-12 x .625 A (Phil)
SHCS .375-16 x 1.75
Hex Nut .375-24
Jam Nut .375-24
Plastic Insert 1.50 x 2.00 x 11 G
Plastic Insert 2.00 Sq x 10-14 G
Half Sphere Bumper
Leg Bar Cushion w/Wear Cover
Wear Cover
Chest Cushion w/Wear Cover
Wear Cover
Thigh Cushion w/Wear Cover
SHCS .375-16 x 2.50
SHCS .375-16 x 3.00
Cybex Decal 1.00 Horiz. Black
Cybex Decal 1.00 Horiz. Silver
VR Weight Stack Instructions (Not Shown)
Weight Plate 4 x 12 (Not Shown)
Foot Glide Removal Instructions (Not Shown)
End Cap
Handle Grip ring
Strength Warranty Sheet (Not Shown)
Connector Input
BHSCS .250-20 x 1.50
Internal Tooth Lockwasher .375
