Clas Ohlson 32-4880 User Manual

Satellite Finder • Art. no. 32-4880
Please read the entire instruction manual before using and save it
for future use. We apologise for any text or photo errors and any
changes of technical data. If you have any questions concerning
technical problems please contact our Customer Service Department
Operation
1. Connect a jumper cable from the LNBF to the "FROM LNB" jack
on the satellite finder.
CAUTION: Most satellite receivers send +13 to +18 VDC
up the center conductor of the LNB coax even when they are
turned OFF. Make sure to unplug the receiver when connecting/
disconnecting coax cable between the receiver and the LNB.
2. Unplug the satellite receiver. Connect the coax cable from the
receiver to the "TO RCVR" jack on the satellite finder.
3. Plug in the satellite receiver and turn ON. The reading should be
between 0 and 1.
4. Make coarse antenna alignment by setting Azimuth and
Inclination to settings indicated by receiver or manual.
5. Adjust the signal strength to approximately 5 using the LEVEL
ADJ control knob.
6. Adjust the antenna position and LNB position (if adjustable) for
the highest reading. If full scale, lower the reading by turning the
LEVEL ADJ counterclockwise.
7. To activate the receiver, send +13V to +18V with 22KHz tone.
The 22KHz led on the front will be light ON, by means of 22KHz
for align the antenna position and LNB position.
8. Turn the receiver Off and unplug.
9. Remove coax jumper from the LNB. Connect the coax cable
from the receiver to the LNB.
GREAT BRITAIN For consumer contact, please visit www.clasohlson.co.uk and click on customer service.
ENGLISH

Specifications

Frequency Range 950-2300 MHz
Impedance 75 ohm
Input Level -25 to –75 dBm
Power Required +13 ~ +18 VDC
Important
1. When using this unit to install C band dish, you do place the
satellite finder in front of the dish to avoid always full-scale.
2. When using high gain LNB, gain that is higher than 60dB, insert
a 6dB attenuator in between the LNB and satellite finder, or
replace the jumper cable to be a 20ft RG-59U.
3. If the read-out is jumping, the sensitivity is too high. Lower
the sensitivity by adjusting S.A. on the back of Satellite Finder
to " L " clockwise. On the other hand, adjust the S.A. counter
clockwise to increase the sensitivity to " H ".
Disposal
Follow local ordinances when disposing of this product. If you
are unsure about how to dispose of this product contact your
municipality.
