Different viewing modes
Pressing this button will cycle you through 3 viewing modes.
1- Photo mode
a. Full colour mode for colour and PC units using a colour monitor.
b. Grey scale mode for black/white units.
2- Reading mode: This mode enhances the foreground / background
contrast. Pictures and text will be displayed in black and white. If the
optional Feature pack was purchased with the unit, the background
and foreground colour combination you have selected with the semi-
colour button (see further) will appear.
3- Inverse reading mode: This mode inverses the chosen background
and foreground colour combinations. This mode also enhances the
foreground / background contrast.
Adjusting brightness & contrast
Press and hold the right side of this button to increase the
contrast and brightness of the onscreen image. Press the left
side to decrease the contrast and brightness.
Brake on the X/Y table
Pull the red lever, at the front of the table, up slightly to lock
the table movement in a stable position. This facilitates handwriting
or painting on the X/Y table. The table can be unlocked by
pulling the lever up again.
Note: When power is off, the brake will automatically be activated
(locked position). When the ClearView
be de-activated (unlocked position). Be sure to position the X/Y table
in the "home" position prior to powering off the unit.
ClearView
+
is switched on, the brake will
+
