7. OPERATION OF THE PROLINE PLUS SYSTEMS

1 Connection kit and manual valve
2 Turbidity filter
3 Granulated Active Carbon filter (GAC)
4 Pressed Activated Carbon filter (BLOCK)
5 Shut off valve
6 Reverse Osmosis membrane
7 Restrictor with manual wash valve
8 Connection to the drain
9 Check valve
PROLINE PLUS PUMP
Electrical diagram of proline plus pump
VALID LIST FOR PROLINE PLUS PUMP AND PROLINE PLUS
Low pressure
switch
24 Vdc
7. Operation of the PROLINE PLUS systems
10 Manual valve of reservoir tank
11 Pressurised reservoir tank
12 Activated carbon post-filter
13 Counter-top tap
14 Low pressure switch
15 Shut off electro-valve
16 Booster pump
17 High pressure switch
High pressure
switch
In-let solenoid
valve
MOTOR
PUMP
17
