MULTISPAN UTC-4201A Operating Manual page 4

Sr. Parameter
1 PC
2 IC
3 DC
4 CT
5
MR
6
Hysteresis
7 Off-set correction
Output Scaling
8
9
Low Percentage
10 High Percentage
Mode Selection
11
Process Value
Set Value
Factory Setting
1) Connection Diagram with Relay Output.:
Product improvement and upgrade is a constant procedure. So for more updated operating information and support, please
contact our Helpline : 9978991474/75 or Email at marketing@multispanindia.com
Range for J, K, PT100
00.00 to 99.99
0.000 to 9.999
0 to 9999
4 sec to 99 sec
-9 to +9
1°C to 50°C
-20°C to +20°C
Forward /Reverse Sele.
00 to high percentage
Low percentage to 100
Auto/Manual
FACTORY SETTING
Press + key for 3 sec
-
Relay
O/P
+
Page - 4
Range for PT.1 sensor
0.1°C to 50.0°C
-20.0°C to +20.0°C
SR.
1
2
3
4
5
6
Output scaling
7
8
9
10
L
N
NC
C
NO
-9.0 to +9.0
FACTORY SETTING
PARAMETER
VALUES
PC
IC
DC
CT
MR
OFFSET
Forward
Low (%)
High (%)
Mode
www.multispanindia.com
05.00
0.225
25
6 sec
0°C
0°C
000%
100%
Auto
