SERVICE
MICRO COMPONENT SYSTEM
TUNER
CD
TAPE
Band
Down
Tuning Mode
Up
MICRO COMPONENT
SYSTEM
MM-B3
Push Open
Volume
EQ
S.Bass
AUX
Power
Sound
Counter
REC/Pause CD Sync.
Mute
Reset
Repeat
A
B
Push Eject
Manual
CONTENTS
5. PCB Diagrams
- Confidential -

Advertisement

loading

Related Manuals for Samsung MM-B3

Summary of Contents for Samsung MM-B3

  • Page 1: Table Of Contents

    MICRO COMPONENT SYSTEM MM-B3 SERVICE Manual MICRO COMPONENT SYSTEM CONTENTS 1. Alignment and Adjustments 2. Exploded Views and Parts List Push Open 3. Electrical Parts List 4. Block Diagrams 5. PCB Diagrams Volume 6. Wiring Diagram S.Bass TUNER TAPE Band 7.
  • Page 2 ELECTRONICS © Samsung Electronics Co.,Ltd. JAN. 2003 Printed in Korea Code no. AH68-01225C...

  • Page 3: Alignment And Adjustments

    1. Alignment and Adjustments 1-1. Tuner Samsung Electronics...
  • Page 4 Alignment and Adjustments Samsung Electronics...
  • Page 5 Alignment and Adjustments 1-2. Cassette Deck Samsung Electronics...

  • Page 6: Exploded Views And Parts List

    FF19S-31 AH81-00543D SOLENOID F765-292 F765-292 AH81-00543E ROLLER PINCH BLK R F514-129 F514-129 AH81-00543F ROLLER PINCH BLK L F514-130 F514-130 AH81-00734A MOTOR CCM09-120L-1-2 AH81-00543H REEL SENSOR SG-107F3;KODENSHI AH81-00543J LEAF S/W - WHITE SPLFF AH81-00543K LEAF S/W - BLK SPLFE1 Samsung Electronics...
  • Page 7 HASVH5503B,,R/P HE AH81-00733A A/S-MAIN BELT MAIN BELT AH81-00543C A/S-F/R BELT FF19S-31,FF19S-31,F/R BELT, AH81-00543D A/S-SOLENOID F765-292,F765-292,SOLENOID, AH81-00543E A/S-ROLLER PINCH BLK R F514-129,F514-129 AH81-00734A A/S-MOTOR CCM09-120L-1-2 AH81-00543H A/S-REEL SENSOR SG-107F3;KODENSHI,-,REEL AH81-00543J A/S-LEAF S/W-WHITE SPLFF,-,LEAF S/W-WHIT AH81-00543K A/S-LEAF S/W-BLK SPLFF1,-,LEAF S/W-BLK Samsung Electronics...
  • Page 8 2-2 Total Exploded View and Parts List Samsung Electronics...
  • Page 9 KNOB FUNCTION 2 0101-46539-00 ABS MOLD.COL.SPY AH81-00561S KNOB VOLUME 0101-46542-00 MOLD PMMA W/PLATING AH81-00561P KNOB FUNCTION 3 0101-46540-00 ABS MOLD.COL.SPY AH81-00552Z LENS LCD 0101-46547-00 PMMA MOLD AH81-00551V QUICK ACTION SWITCH 0323-60208-01 LS-323-0 (1P2T) AH81-00554E REMOTE HOLDER 0101-46550-00 ABS MOLD.COL Samsung Electronics...
  • Page 10 Remarks AH81-00568R CD MECHA P31TG6U(CMS-P31) AH81-00635A CHASSIS-DECK(M) AJ70-00601E AH81-00635D COVER-GEAR AJ66-00601G AH81-00635B GEAR(A) AJ66-00601D AH81-00635E GEAR(B) AJ66-00601B AH81-00635F GEAR(C) AJ66-00601F AH81-00635G SHAFT-PU AJ70-00601A AH81-00635H TURN-TABLE(T) AJ72-00602A AH81-00635J SOH-AA AJ75-00601F AH81-00635K MOTOR-SPINDLE AJ31-00601C AH81-00635C MOTOR-FEED AJ31-00601A AH81-00635L SCREW-PH AJ60-00601D Samsung Electronics...
  • Page 11 2-4 SPEAKER Exploded View and Parts list * CAUTION : When the disassembly, take extreme care not to demage the SPEAKER. Samsung Electronics...

  • Page 12: Electrical Parts List

    2007-000129 R-CHIP;27Kohm,5%,1/16W,DA,TP,1608 AH42-20001Q ANT LOOP;-,KS980214-01,18.5uH,CONNECTOR R113 2007-000132 R-CHIP;180Kohm,5%,1/16W,DA,TP,1608 AH59-01086A DECK-CASSETTE;CMAL5Z217A,MM-B3,-,-,DC12V R133 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012 AH81-00579E A/S PART-SPEAKER SYSTEM ASS’Y;MM-B3 (EXP R132 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012 AH81-00569G A/S PART-SPEAKER L ASS’Y;MM-B3,PS B3H, R207 2007-000309 R-CHIP;10ohm,5%,1/16W,DA,TP,1608 AH81-00570G A/S PART-SPEAKER R ASS’Y;MM-B3,PS B3H, R121 2007-000455 R-CHIP;18Kohm,1%,1/16W,DA,TP,1608 AH59-00043F REMOCON-ASSY;-,-,-,22KEY,MQ-N4,-...
  • Page 13 Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks R117 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm AH81-00905P A/S PART-MAIN PCB ASS’Y;MM-B3 EUROPE,-,- R140 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm R142 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, R147 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, R198 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm...
  • Page 14 2301-000387 C-FILM,PEF;150nF,10%,50V,TP,12.5x15x7.5, VR55 2007-001654 R-CHIP;10MOHM,1%,1/10W,DA,TP,2012 AC13 2301-000387 C-FILM,PEF;150nF,10%,50V,TP,12.5x15x7.5, C152 2201-000146 C-CERAMIC,DISC;0.1NF,5%,50V,SL,TP,5X3.5M JC26 2301-000390 C-FILM,PEF;15nF,10%,50V,TP,7x12x3.5mm,- C150 2201-000146 C-CERAMIC,DISC;0.1NF,5%,50V,SL,TP,5X3.5M JC27 2301-000404 C-FILM,PEF;2.2nF,10%,50V,TP,5.5x12x3mm,- C147 2201-000146 C-CERAMIC,DISC;0.1NF,5%,50V,SL,TP,5X3.5M C142 2301-000404 C-FILM,PEF;2.2nF,10%,50V,TP,5.5x12x3mm,- C146 2201-000146 C-CERAMIC,DISC;0.1NF,5%,50V,SL,TP,5X3.5M C141 2301-000404 C-FILM,PEF;2.2nF,10%,50V,TP,5.5x12x3mm,- C145 2201-000146 C-CERAMIC,DISC;0.1NF,5%,50V,SL,TP,5X3.5M C456 2301-000407 C-FILM,PEF;2.7nF,10%,50V,TP,5.5x12x3mm,- Samsung Electronics...
  • Page 15 X105 2801-000734 CRYSTAL-UNIT;7.2MHz,50ppm,28-AAM,12pF,30 AH81-00911Q A/S PART-FFC CABLE;0321-10300-G0,10PINS 2801-001394 CRYSTAL-UNIT;32.768KHz,20ppm,28-AAY,12.5 AH81-00911S A/S PART-LCD HOLDER;0101-46541-00,HIPS M 2802-000181 RESONATOR-CERAMIC;6MHz,0.3%,BK,9.0x4.0x7 X104 2802-000215 RESONATOR-CERAMIC;19KHz,+-38Hz,-,7.0x3.5 AH81-00905Q A/S PART-FRONT PCB ASS’Y;MM-B3 EUROPE,-, X103 2903-000106 FILTER-CERAMIC;BP,10.7MHz+-25KHz,280KHz+ 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, X101 2903-000106 FILTER-CERAMIC;BP,10.7MHz+-25KHz,280KHz+ 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, SW813 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,...
  • Page 16 VC15 2401-001893 C-AL;100uF,20%,16V,GP,6*7,5MM,TP VC13 2401-001893 C-AL;100uF,20%,16V,GP,6*7,5MM,TP 2701-000111 INDUCTOR-AXIAL;100uH,10%,2.5x3.4mm 2701-000298 INDUCTOR-AXIAL;470uH,10%,4.2x9.8mm 2801-001394 CRYSTAL-UNIT;32.768KHz,20ppm,28-AAY,12.5 2802-000181 RESONATOR-CERAMIC;6MHz,0.3%,BK,9.0x4.0x7 SW813 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST SW814 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST SW815 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST SW816 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST SW817 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST SW818 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST SW819 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST SW811 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST Samsung Electronics...

  • Page 17: Block Diagrams

    4. Block Diagram 4-1 CD Part Samsung Electronics...
  • Page 18 4-2 MAIN Samsung Electronics...
  • Page 19 5. Printed Circuit Board Diagram 5-1 CD Part Samsung Electronics...
  • Page 20 5-2-1 MAIN (TOP VIEW) Samsung Electronics...
  • Page 21 5-2-2 MAIN (BOTTOM VIEW) Samsung Electronics...
  • Page 22 5-3 CONTROL(KEY) PCB * TOP VIEW *BOTTOM VIEW Samsung Electronics...

  • Page 23: Wiring Diagram

    6. Wiring Diagram Samsung Electronics...

  • Page 24: Schematic Diagrams

    7. Schematic Diagram 7-1 CD Part Samsung Electronics...
  • Page 25 7-2 MAIN Samsung Electronics...
  • Page 26 7-3 CONTROL (KEY) Samsung Electronics...
