KOBALT® and the K & Design®
are registered trademarks of
LF, LLC. All Rights Reserved.
ATTACH YOUR RECEIPT HERE
Serial Number
Questions, problems, missing parts? Before returning to your retailer, call our
customer service department at 1-888-3KOBALT (1-888-356-2258), 8 a.m - 8 p.m., EST,
Monday - Friday.
NEXT GENERATION
OF TOUGH TOOLS
TM
Purchase Date
1
ITEM #0394231
10-AMP
CORDED DRILL
MODEL #K10D-06AB
Français p. 14
Español p. 27
Advertisement
Related Manuals for Kobalt K10D-06AB
Summary of Contents for Kobalt K10D-06AB
- Page 1 NEXT GENERATION OF TOUGH TOOLS ITEM #0394231 10-AMP CORDED DRILL MODEL #K10D-06AB Français p. 14 KOBALT® and the K & Design® Español p. 27 are registered trademarks of LF, LLC. All Rights Reserved. ATTACH YOUR RECEIPT HERE Serial Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-888-3KOBALT (1-888-356-2258), 8 a.m - 8 p.m., EST,...
-
Page 2: Table Of Contents
Table of ConTenTs Product Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Safety Information . -
Page 3: Safety Information
safeTy informaTion Please read and understand this entire manual before attempting to assemble or operate this product. If you have any questions regarding the product, please call customer service at 1-888-3KOBALT, 8 a.m. - 8 p.m., EST, Monday - Friday. WarninG •... - Page 4 safeTy informaTion Some of the following symbols may be used on this tool. Please study them and their meaning. Proper interpretation of these symbols will allow you to operate the tool better and more safely. symbol definiTion symbol definiTion Volts Direct Current Amps No-load Speed...
- Page 5 safeTy informaTion Personal safety • Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol, or medication. A moment of inattention while operating power tools may result in serious personal injury.
- Page 6 safeTy informaTion service • Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. Specific Safety Rules for the Electric Drill • Hold the power tool by the insulated gripping surfaces when performing an operation where the cutting tool may contact hidden wiring or its own cord.
-
Page 7: Package Contents
PaCKaGe ConTenTs ParT desriPTion QuanTiTy Sleeve Chuck key hole Chuck Direction-of-rotation selector Trigger switch Chuck key Lock-on button Live wire indicator light Chuck key strap Auxiliary handle Auxiliary handle quick-clamp... -
Page 8: Operating Instructions
oPeraTinG insTruCTions 1. Trigger switch a. To turn the drill ON, press the trigger switch (E). b . To turn the drill OFF, release the trigger switch. noTe: The trigger switch delivers higher speed with increased trigger pressure and lower speed with decreased trigger pressure. - Page 9 oPeraTinG insTruCTions 4. Auxiliary Handle This drill is equipped with an auxiliary handle (J). For ease of operation, you can use the handle with either the left or right hand. The handle can be rotated 360°. To adjust the auxiliary handle assembly: a.
-
Page 10: Removing Bits
oPeraTinG insTruCTions 6. installing bits (sold separately) a. Unplug the drill from the power source. b . Lock the trigger switch by placing the direction-of- rotation selector (D) in the OFF (center) position. Open the chuck (C) jaws by turning the sleeve (A) in a counterclockwise direction until the opening is slightly larger than the bit you intend to use. - Page 11 oPeraTinG insTruCTions 8. drilling a. Secure the material to be drilled in a vise or with clamps to keep it from turning as the drill bit rotates. b . Install the correct bit. Verify that the direction-of-rotation selector (D) is at the correct setting (forward).
-
Page 12: Care And Maintenance
oPeraTinG insTruCTions 10. drilling in metal For maximum performance, use high-speed steel bits for metal or steel drilling. a. When drilling metals, use light oil on the drill bit to keep it from overheating. The oil will prolong the life of the bit and increase the drilling action. b . -
Page 13: Troubleshooting
TRouBLESHooTing WarninG: Turn the switch to the OFF position and unplug the drill from the power source before you perform any troubleshooting procedures. If you have any questions regarding this product, please call customer service at 1-888-3KOBALT, 8 a.m. - 8 p.m., EST, Monday - Friday. Problem Possible Cause CorreCTiVe aCTion...
