1. Vista General
1.1 Vista Frontal
1 PANTALLA LCD
Usada para mostar varios menus y submenus
2 BOTON LEFT (IZQ.)
3 BOTON MIDDLE (CENTRAL)
Los 3 menús básicos pueden ser seleccionados uno despues del otro
mediante este botón.
4 BOTON RIGHT (DER.)
5 ENCODER
El encoder puede girar tanto si se pulsa como si no el botón, las
funciones serán diferentes en cada caso.
La programación sólo es posible presionando un botón y girando e
encoder a la vez.
6 MODULOS DE DIMMER DE CANAL (x12)
El módulo de canal viene equipado con un magnetotermico de 10 A
y triacs de 1000A de capacidad de pico de corriente. La facilidad de
cambio o colocación de estos módulos permiten una fácil y flexible
configuración del dimmer.
3
Pagina 32
2. Operating Guide
2.4 Setup Menu

2.4.4 MIDI Channel

A total of channels 1~16 can be selected.

2.4.5 Phase Correction

Usually this control parameter is set to "ON". It makes a brightness-linear
control possible. The normal non-linearity, produced by the SRC's phase
angle control, is thereby compensated. This function works in addition to
the " USER CURVES".

2.4.6 USER MODE

With this function the dimmer function can be cut down in 3 steps.
-SUPER : "Supervisor" means that all functions can be used.
-NORM : "Normal User" means that in the Channel Menu, only the
DMX address can be programmed. The Memory Menu is
switched off. After having tested the dimmer functions,
the user shall use this mode, which helps protect the
parameters set by the dimmer. The DMX address shall be
programmable.
- LOCK : The dimmer is completely locked and can be not be
operated with the buttons or encoder. To change this mode,
press the middle button because it allows the entry into the
Setup Menu by pressing it for 5 seconds.
3 6
