Work Pro MINIDIM 8 User Manual

DESCRIPTION
Congratulations with your purchase of this product.
MINIDIM 8 is a constant voltage driver for RGB LED devices control. It can operate on several modes: Through DMX signal (with several channel control configurations),
Manual (with intensity adjustment by dip assignation) or Program (3 built-in programs with intensity and speed control). It allows to connect up to 3 A load on its output.
MINIDIM 8 can be used in a standard DIN rail using the separate accesories for its fixation.
BOX CONTENTS
You should be in possession of the following items:
1 MiniDim 8
1 Manual
Check for transport damage.
If you discover transport damage after unpacking the equipment, inform the hauler immediately. Never connect a damaged device. You
Power Requirement
12~24VDC, 24 A Max.
3 A,Max. each one
Output
OPERATION GUIDE
1. DMX Control Mode (DMX addressing)
MINIDIM 8 incorporates 6 different operating configurations inside DMX mode. These configurations are available using the dip switches 10 to 12. See the closed table.
Dip Switch 1 address equals 1
Dip Switch 2 address equals 2
Dip Switch 3 address equals 4
Dip Switch 4 address equals 8
Dip Switch 5 address equals 16
Dip Switch 6 address equals 32
Dip Switch 7 address equals 64
Dip Switch 8 address equals 128
Dip Switch 9 address equals 256
For example: Setting DMX address for 21.
Flip switches1,3,&5 to the
"ON"position
1=1
3=4
Dipswitches# 5=16
=21
MINIDIM 8 incorporates 6 different operation configurations inside DMX mode. These configurations are available through dip-switches numbre 10 to 12. See closed
tables.
Mode Dip-Switches
1= ON
DMX 8 000
10 11 12 0=OFF
1= ON
DMX 4 001
10 11 12 0=OFF
1= ON
DMX 2 010
10 11 12
0=OFF
1= ON
DMX 1 011
10 11 12
0=OFF
1= ON
DMX C/B 110
0=OFF
10 11 12
1= ON
DMX C 111
10 11 12 0=OFF
Channel layout on each mode, assuming that the DMX starting address channel is setup for channel 1. If the starting channel is another, use the table
assigning it by analogy.
Mode
DMX 8 CH 1: Red OUTPUT 1, CH 2: Green OUTPUT 1, CH 3: Blue OUTPUT 1, CH 4: Red OUTPUT 2 .................. CH 24: Blue OUTPUT 8, CH 25: General dimmer
DMX 4 CH 1: Red OUTPUT 1-2, CH 2: Green OUTPUT 1-2, CH 3: Blue OUTPUT 1-2, CH 4: Red OUTPUT 3-4 ..... CH 12: Blue OUTPUT 7-8, CH 25: General Dimmer
DMX 2 CH 1: Red OUTPUT 1 to 4, CH 2: Green OUTPUT 1 to 4, CH 3: Blue OUTPUT 1 to 4, ..... CH 6: Blue OUTPUT 5 to 8, CH 7: General Dimmer
DMX 1 CH 1: Red OUTPUT 1 to 8, CH 2: Green OUTPUT 1 to 8, CH 3: Blue OUTPUT 1 to 8, CH 4: General Dimmer
DMX C/B CH 1: Color change from Red to White, CH 2: Bright.
DMX C CH 1: Color change from Red to White. Full intensity.
* NOTE: in all DMX mode, the General dimmer channel is the last channel of the configuration, Channel 25, 13, 7, 4 respectivelly
MINIDIM 8
MINIDIM 8
User Manual
Oper. temperature
Connection
Use the dip switches to set the DMX starting address
START
CH#
1
2
3
4
5
6
7
8
9
Value
10
Qty of DMX
Channels
25 Each color on each output can be controlled independently (24 channels) + General Dimmer
13 Outputs are grouped in blocks of 2 (OUTPUT 1-2), The colors of each groups are common (12 channels) + General dimmer.
7 Outputs are grouped in blocks of 4 (OUTPUT 1-4), The colors of each groups are common (6 channels) + General dimmer.
4 All Outputs obbey the same color control, it is common in the whole outputs (3 channels) +General Dimmer
2 All outputs obbey to the same control. 1 cannel for color change and another for Bright.
1 All outputs obbey to the same control. 1 channel for color change.
User Manual/Manual de uso
o o
-10 C to +50 C Dimensions
Terminal Blocks Weight
1= ON
1 2 3 4 5 6 7 8 9 10 11 12
0= OFF
START
SWITCHES ON SWITCHES ON
CH#
1,2,4
1 11
2 12 3,4
1,2 1,3,4
13
2,3,4
3 14
1,3 15 1,2,3,4
2,3
1,2,3
4
1,4
2,4 1,2,3,4,5,6,7,8,9
Function
Channels Layout
EN
NOTE: For a better
1=
understanding. the
square in white color
is considered the switch
12
in all pictures of this
0=OFF
user manual
may also contact your supplier.
154(L)x83(W)x28(H)mm
370g
DMX starting address
1 2 3 4 5 6 7 8 9 10 11 12
Pag 1
ON
1= ON
0=OFF
