Chapter 1: About this User Manual 1.1 Manual Structure This User Manual is divided into seven functionally distinct sections reflecting the activities required to set up a RADWIN 2000 D+ link. The division is shown in the following table: Table 1‐1: User Manual ‐ General layout Section General Content Purpose Preliminaries About this manual, Introduction to RADWIN 2000 D+ • Core information to physically install a link: Site preparation and hardware Installation • Understanding the RADWIN Manager windows. Basic Installation Using the RADWIN Manager to bring up a link • Fine tuning the link • Monitoring, diagnostics Intra‐site with Hub Site Synchronization, inter‐site with Site Synchronization the GPS Synchronization Unit Advanced Software upgrade, backup and restore, VLAN, QoS, Radar Installation Topics mitigation and avoidance, DFS, Field Installation Link Budget Calculator, Spectrum View, Web interface Topics Product Reference RF Exposure, Setting antenna parameters 1.1.1 Typographical Convention Where a term is defined or introduced for the first time, it is shown in Boldface. 1.1.2 Viewing and Printing This manual is optimized for viewing online as a PDF file. To this end it uses an 11 point Tahoma typeface for main text. Tables for most part, use 7 or 8 point fonts. Here are a few pointers for hard‐copy printing: RADWIN 2000 D+ User Manual Release 3.6.00...
Page 11 Notifications Chapter 1 • The text and table typefaces used are large enough to print the manual at two pages per sheet • For good legibility, use a commercial grade laser printer. A color printer is of course best, however a monochrome printer set to use gray‐scale gives acceptable results • Better quality ink jet printers also give good output 1.1.3 Notifications Notifications consist of Warnings, Cautions and Notes. The purpose of a Note is to • Draw your attention to something that may not be obvious or counter‐ intuitive • Emphasize a special feature or peculiarity of the RADWIN 2000 D+ • Offer an external reference for additional information • Add a caveat that would not qualify as a full Caution or Warning (see below) • Provide additional background to what follows Note • Offer a recommendation • Highlight an indication of something to watch out for • Advise you if an action has “side effects” i.e. it may disturb something else that would be best left undisturbed • Remind you of something that should be kept in mind A Warning is a notification of risk of danger to persons operating near the equipment Warning A Caution is a notification of risk of damage to equipment or of service degradation Caution Occasionally we use a Note as a Tip: ...
Page 12 Customer Support Chapter 1 A link then, consists of two sites. • In Broadband Wireless terminology, the local and remote sites are sometimes referred to as “near” and “far”, “HQ” and “remote” and so on. The RADWIN 2000 D+ class radios achieve their 700Mbps throughput by drawing on new technology developed for the RADWIN 5000 Point to Multipoint series. Therefore the sites are not symmetrical. The local site referred to earlier, uses a base station radio as the link Master ODU and the remote site uses a subscriber unit as the link Slave ODU. The Master ODU radio is labelled RT‐A(HBS) and the Slave ODU labelled RT‐B(HSU). RT stands for Radio Terminal. The RT‐A(HBS)/RT‐B(HSU) and master/slave terminology will be used throughout the manual both to describe the two link sites without further comment. The link is normally configured and managed using a PC, the managing computer connected to the Master ODU. (The precise requirements for the managing computer are set out in Minimum System Requirements). It may also be connected to the Slave ODU either directly or over‐the‐ air. We will occasionally need to distinguish between the site to which the managing computer is connected, and the second site, when they are not specifically RT‐A(HBS) or RT‐B(HSU). The former will be called the managing site and the latter, the over‐the‐air site. Which is which, is always determined by the location of the managing computer. • Downlink traffic is data transfer from anRT‐A(HBS) to an RT‐B(HSU). • Uplink traffic is data transfer from an RT‐B(HSU) to an RT‐A(HBS). • RADWIN 2000 D+ supports three connection methods for the managing computer: • Local ‐ a direct peer to peer connection between the Ethernet ports on the managing computer and the PoE device. • Network ‐ the managing computer and the site A IDU or PoE device belong to a LAN and communicate through a router or switch • Over‐the‐air ‐ the managing computer connects to site B via the air interface • The managing computer is connected to the link through a PoE device. • Universal bands refer to RADWIN Universal bands.
Page 13 Chapter 2: Introduction 2.1 Welcome to RADWIN 2000 D+! RADWIN 2000 D+ delivers up to 750 Mbps and is the ideal choice for last mile enterprise connectivity and high‐end applications that demand assured performance with guaranteed link bandwidth. RADWIN 2000 D+ provides the highest end user capacity in the market to best support data and high resolution video applications. By delivering high capacity over a single radio unit, the RADWIN solution saves valuable tower space, eases maintenance efforts and reduces the total cost of ownership per megabit. RADWIN 2000 D+ is ideal for carrier IP backhaul or heavy IP connectivity in variety of vertical applications that require guaranteed QoS. It provides best of it class performance in highly congested spectrum and in nLOS/NLOS conditions due to its enhanced interference mitigation and auto selection ability between Spatially Multiplexed and Diversity modes. 2.2 What’s New in Release 3.6.00 LA release 3.6.00 adds to release 3.5.70, a new platform for enhanced performance and extended functionality. It implements dynamic selection of the Modulation Coding Scheme (MCS) and channel bandwidth combination to attain the highest throughput. The new channel bandwidth scheme is set by default to use 20/40/80 MHz. From a configured channel bandwidth of 80MHz, the link can fall back to 20 or 40 MHz. From 40 MHz it can fall back to 20 MHz. The other configured channel bandwidths of 20 and 10 MHz remain fixed. 2.3 Key features of RADWIN 2000 D+ » Ethernet connectivity » Advanced OFDM & MIMO 2x2 for nLOS performance » Enhanced interference mitigation capability » Inter & intra site sync to reduce self interference » Long range – up to 40 km/25 miles » Wide range of frequency bands ‐ 4.9 ‐6.0GHz RADWIN 2000 D+ User Manual Release 3.6.00 2‐1...
Page 14 » Dedicated Bandwidth ensuring SLA & latency » Low and constant latency – min < 3ms » Channel bandwidth – 10/20/40/80 MHz » Regulations supported ‐ FCC/IC/ETSI/WPC/MII/Universal » Simple to deploy » Web Interface for link management » SFP support when connecting to a IDU‐H in place of a PoE device » 750 Mbps aggregate throughput » Fully integrated with RADWIN Legacy solutions: • Coexist (HBS‐collocatable) with RADWIN 2000 and RADWIN 5000 products • Common RADWIN Manager • Common RNMS » Separate uplink and downlink configurable Maximum Information Rate (MIR) 2.4 Components of a RADWIN 2000 D+ Link 2.4.1 Major Components The major element of each site is the ODU radio transceiver. The ODU actually contains two radios, which may be connected to a dual pole integrated or external antenna. The ODU itself is connected to a PoE device. The PoE provides an Ethernet LAN connection to user equipment (typically a switch). 2.4.2 Accessories To build a RADWIN 2000 D+ link you will require some of the following accessories: • PoE devices ‐ Both Gigabit and 100 Mbps • HSS unit ‐ Collocation unit for intra‐site synchronization • IDU‐H Aggregation unit for a collocated hub site instead of multiple PoE devices •...
Page 15 Link Management Tools Chapter 2 2.4.3 Link Management Tools RADWIN Manager The RADWIN Manager is an SNMP‐based management application which manages a complete link over a single IP address. The intuitive, easy‐to‐use RADWIN Manager has a rich graphical user interface. RADWIN Web Interface for Management The Web Interface enables you to carry out basic link management functions using a Web browser. It is an easy way to rapidly configure and setup a link. It may be used to ‐ • Establish a link on a minimal basis • Check link parameters and make basic changes • View the link Inventory • Inspect the Recent Events logs Full details are supplied in Using the Web Interface. RADWIN Network Management System (RNMS) The RADWIN Network Management System enables Service Providers to manage all RADWIN links in their network from a Network Operations Center (NOC). Using RNMS, Service Providers can configure and monitor up to 10,000 RADWIN links . The intuitive easy‐to‐use RNMS provides a full range of network surveillance, monitoring, configuration and fault management capabilities. It offers users complete visibility and control over their RADWIN‐based networks. Documentation supplied with RADWIN 2000 D+ The technical documentation supplied with a RADWIN 2000 D+, is located on the product CD. It includes the following items: • A Quick Installation Guide for experienced installers (also hardcopy) • A full User Manual ‐ the document which you are reading • A Help file accessible from the RADWIN Manager • Link Budget Calculator 1. Depending on license type RADWIN 2000 D+ User Manual...
Page 16 Part 2: Basic Installation Release 3.6.00...
Page 17 Chapter 3: Site Survey 3.1 Planning the Link Site 3.1.1 Overview Link site planning consists of a set of surveys, which must be carried out before any equipment is brought to the site. If for some reason, the outcome of any of these surveys is negative, site re‐location will need to be considered. A Site Survey consists of three stages: 1. Preliminary survey ‐ The proposed link is analyzed in the office using a topographic map. 2. Physical survey ‐ The locations of the indoor and outdoor equipment are determined on‐ site. 3. Radio Frequency (RF) survey ‐ It is recommended that the installation area be scanned with a spectrum analyzer, to identify RF interference so as to determine a clear channel for radio installation (on‐site). 3.2 The Site Survey 3.2.1 Introduction RADWIN wireless links must be planned before installation. The designated installation site must be appraised to determine that the wireless system is able to operate efficiently and provide connectivity without signal degradation. RADWIN 2000 D+ offers a wide operating frequency range. A free frequency channel must be determined within the operating range, for optimum performance. 3.2.2 Recommended Equipment Stage 1: Preliminary Survey • Topological map of the area • Urban map of the area RADWIN 2000 D+ User Manual Release 3.6.00 3‐1...
Page 18 • GPS device (optional) • Compass (optional) Stage 3: RF Survey • Spectrum Analyzer with Max Hold function and screen capture facility that can store multiple images, for documentation purposes • RF accessories (connectors and cables) • Communication devices (for example, cellular phones, or a set of walkie‐talkies) 3.3 Stage 1: Preliminary Survey A preliminary survey is necessary before visiting potential installation sites. As much detail as possible should be obtained about the two designated ODU installation sites and the area between them.  To perform a preliminary survey: 1. Mark the two designated installation sites on a topographic map of the area. 2. Measure the distance between the sites; check that it is within the specified range of the equipment. 3. On the urban map, check for developed areas situated between the two installation sites. Pay attention to these areas when performing the physical site survey; there may be tall buildings, RF towers, or transmitters, which could cause interference to the link. 4. Check the area between the two sites for obstructions such as: • High ground ‐ hills or mountains • Lakes or large bodies of water. Water has a reflection effect on RF signals like a building. This type of reflection causes the received amplitude to be reduced. As a rule of thumb, the presence of a large body of water between the link sites may double the required antenna height. 5. Determine and record the compass bearings between both ODUs, relative to north. 6. If there are obstructions between the two sites, calculate the Fresnel Zone (see Link Budget Calculator for details). 7. If the site chosen does not meet requirements, consider alternative sites. RADWIN 2000 D+ User Manual Release 3.6.00 3‐2...
Page 19 Stage 2: Physical Survey Chapter 3 8. Use the Link Budget Calculator (on the CD supplied with the equipment or using the RADWIN Manager) to determine the expected performance. 3.4 Stage 2: Physical Survey The physical site survey reviews the environment of the proposed installation location, to ensure that the link sites are suitable for the wireless network. The results of the physical site survey should be recorded. It is advisable to go on a clear day, so you can more easily see any obstructions between the two sites. Note  To perform a physical survey: 1. From the compass readings taken in the preliminary survey, find the azimuth (hori‐ zontal position) that the ODU should face towards the second ODU. 2. Using binoculars, locate any obstructions such as tall trees, high buildings, hills or mountains. Look for other RF towers between the two sites. Mark the locations of the obstructions on the map. 3. Determine the location for the ODU (having regard for existing rooftop installations and tower space). It should be above any obstructions, considering the Fresnel zone (see Link Budget Calculator). 4. If you need to install the ODU on a tower, make sure that the tower is far away from overhead electric power lines. 5. Determine a location for the indoor equipment; it should be as close as possible to the ODU. At an existing site, there is probably an equipment room with cable‐routing channels. The IDU ‐ ODU cable length limit is 100m, in accordance with 10/100BaseT interface. Note 6. Measure and record the path length of the cable from the ODU position to the indoor equipment room. 7. Determine the ground and lightning connection points of the installation. The ODU and IDU must both be grounded. 8. Using the Ohmmeter, measure and record the resistance of the required installation to the grounding point. The resistance must be less than 1O ohm. 9. Review the results of the physical site survey. Decide if the site is suitable for the wireless network installation. • If the site is suitable, continue with stage 3, the RF survey RADWIN 2000 D+ User Manual Release 3.6.00...
Page 20 3.4.1 Additional Outdoor Site Requirements The ambient outdoor operating temperature should be ‐35 to 60C (‐31 to 140F). 3.4.2 Additional Indoor Site Requirements The following requirements guarantee proper operation of the system: • For IDU‐C units, allow at least 90 cm (36 “) of front clearance for operating and mainte‐ nance accessibility. Allow at least 10 cm (4 “) clearance at the rear of the unit for signal lines and interface cables • The ambient operating temperature should be 0 to 50°C (32 to 122 °F) at a humidity of up to 90%, non condensing 3.5 Stage 3: RF Survey The RF survey examines the wireless environment of the installation site, to determine whether there are available channels within the radio operating frequency band. An RF survey is performed using a spectrum analyzer. It is advisable to familiarize yourself with the spectrum analyzer before going out on site, specifically the Max Hold and Marker functions. You should perform the RF survey at both proposed link sites. The survey should be carried out during a busy time of day, to best judge the worst‐case radio interference. Allow 2‐4 hours duration for a good RF survey. It is possible to install the link and use the RADWIN Manager to find a clear channel. Each frequency channel can be evaluated in turn. Achievement of a clear channel is indicated by the marker in the Quality bar on the Channel Note Setting window (see Figure 6‐4) moving into the green area. 3.6 RF Planning for Dense Installations and Collocated Sites Interference may arise from • Self interference from collocated RADWIN radios • Other collocated radio devices installed on the same site. To avoid or minimize interference, follow these recommendations: • For collocated RADWIN units, use an HSS unit to synchronize between them. Select a different operating channels for each collocated RADWIN unit. RADWIN 2000 D+ User Manual Release 3.6.00 3‐4...
Page 21 RF Planning for Dense Installations and Collocated Sites Chapter 3 • If one or more collocated units are not RADWIN units, ensure that there is a physical separation of at least three meters between a RADWIN unit and any other collocated radio on the site. • Use the largest possible frequency gap between these units. • Choose the best frequency channel (as clear as possible form interference). You may have to use the Change Band facility available for all RADWIN 2000 products. • To select a frequency channel, move the link to Installation Mode (using Site configura‐ tion) and start the Installation wizard. In the Channel Settings window, use the quality bar at the bottom to help you choose a better channel (clearer of interference). • Use the Spectrum View tool to find the best working channel (Tools | Spectrum View). • Decreasing the Tx Power of a link will reduce collocation interference (Site Configura‐ tion | Air Interface). Use the Link Budget Calculator to determine the minimum Tx Power required to maintain link stability. Note RADWIN 2000 D+ User Manual Release 3.6.00 3‐5...
Page 22 Chapter 4: Hardware Installation 4.1 Overview This chapter covers the requirements and procedures for the hardware installation and alignment of a RADWIN 2000 D+ sector in accordance with prior planning. (See Site Survey.) It is intended to assist qualified field technicians. The material in this chapter is largely generic to all RADWIN radio products unless stated otherwise. ODU may be an HBS or any type of HSU. Note Outdoor units and antennas should be installed ONLY by qualified field technicians who are familiar with local building and safety codes and, wherever applicable, are licensed by the appropriate government regulatory authorities. Failure to do so may expose the end user or the service provider to legal and financial liabilities. RADWIN and its resellers or Warning distributors are not liable for injury, damage or violation of regulations associated with the installation of outdoor units or antennas. This chapter covers the following topics: • Unpacking and checking supplied equipment: • ODUs • PoE devices • IDU‐H aggregation unit • Antennas • Accessories • Tools required for installation • Safety practices • Mounting an ODU • Connecting an ODU • Grounding and lightning protection for an ODU •...
Page 23: Odu - Large
What’s in the box Chapter 4 • Establishing a radio link 4.2 What’s in the box 4.2.1 Unpacking and Checking  For each of the items below: 1. Remove the equipment from the box. 2. Check that everything listed on the included Bill of Materials or Pro‐forma Invoice is present. 3. If any item is missing, contact Customer Service. You will be advised whether to return the package for replacement, or whether the missing item can be supplied separately. 4. Do not dispose of the packaging until the unit is installed and operational. 4.2.2 Radios The RADWIN 2000 D+ package includes the following items: • Two ODUs ‐ see the next figure for front and rear view Front Rear Figure 4‐1: ODU ‐ Large Form Factors • Two ODU mounting kits • A CD containing ‐ RADWIN 2000 D+ User Manual Release 3.6.00 4‐2...
Page 24: Figure 4-2 G B E P Oedevice
Power over Ethernet (PoE) Devices Chapter 4 • The RADWIN Manager software • Quick Start Guide • This User Manual • Link Budget Calculator • For each ODU, a self‐adhesive label with the MAC address and alternative Community string. Keep these labels in a safe place for future reference. • Cable glands (to be used with the HBS‐PoE cable) • Quick Start Guide leaflet 4.2.3 Power over Ethernet (PoE) Devices RADWIN’s Gigabit Power over Ethernet (GbE PoE) device provides data and power to RADWIN 2000 D+ outdoor units. The PoE device is available with a variety of AC cables with different plug types. This is the recommended PoE device for use with HBSs and HSUs. The unit comes with a VAC cable. Both the cable length and plug are region dependent. Figure 4‐2: GbE PoE device 4.2.4 IDU‐H aggregation unit The IDU‐H provides aggregation for multiple RADWIN ODUs and HBSs at a hub site. It supports all RADWIN ODUs. It features ‐ • Six PoE ports (PoE legacy mode / RADWIN PoE) • Up to 25W per PoE port • 2 LAN Interfaces 10/100/1000 Mbps; auto‐negotiation •...
Page 25: Figure 4-3 Idu-H
IDU‐H aggregation unit Chapter 4 Figure 4‐3: IDU‐H The IDU‐H package contains: • One IDU‐H • One short mounting ear • One long mounting ear • One dual connector to join two units mounted side by side • Two DC power plugs for power cables ‐ see Figure 4‐4 below Figure 4‐4: DC three pin power plug The power connectors are 3 pin in line female, with polarities (left to right) minus, ground, plus. If required, an AC/DC power adapter should be ordered separately, depending on your region. The IDU‐H may be installed in single or double configurations: Figure 4‐5: IDU‐H front view ‐ single configuration RADWIN 2000 D+ User Manual Release 3.6.00 4‐4...
Page 26 Antennas Chapter 4 Figure 4‐6: IDU‐H front view ‐ double configuration 4.2.5 Antennas An antenna is the radiating and receiving element from which the radio signal, in the form of RF power, is radiated to its surroundings and vice versa. The antenna gain and transmitting power may be limited by country regulations. The RADWIN 2000 D+ may be operated with an integrated antenna that is part of the ODU, or with external antennas connected to the ODU via N‐type connectors. All cables and connections must be connected correctly to reduce RF losses. The required antenna impedance is 50  . The 5.x GHz Integrated Antenna ODU is provided with 370 mm (1.2ft) flat panel antenna, with a gain of 23dBi (5.x GHz) / 19dBi (4.9 GHz) and 8° beam width. The 2.x GHz Integrated Antenna ODU is provided with 370 mm (1.2ft) flat panel antenna, with a gain of 16dBi and 16° beam width. The radio and the antenna are housed in a weatherproof case as a single unit. Figure 4‐7: ODU with integrated Flat Panel antenna 4.2.6 External Antennas External antennas are available for the RADWIN 2000 D+ radios, varying in operating frequencies, form factor, size and gain, dual or single polarization. The Flat Panel antenna shown below can be used either as an integrated or external antenna. RADWIN 2000 D+ User Manual Release 3.6.00 4‐5...
Page 27: Figure 4-8 External Antennas For Use With Radwin 2000 D
Accessories Chapter 4 Figure 4‐8: External Antennas for use with RADWIN 2000 D+ The 11 dBi 120° Base Station sectorial antennas must be installed with a tilt angle of at least 32° downwards relative to the horizon. Caution Antenna Kits External antennas are available for the RADWIN 2000 D+ radios, varying in operating frequencies, form factor, size and gain. See the RADWIN products catalog for a more detailed offering of external antennas. External A typical antenna kit contains ‐ • An antenna • Two RF cables 1.2 m (4’) long • Mounting kit 4.2.7 Accessories Hub Site Synchronization (HSS) Unit The HSS unit synchronizes collocated ODUs to prevent self interference. It is particularly useful at a multi‐link base station employing several ODUs. A single HSS unit supports up to ten collocated ODUs. In addition to each unit being connected to its PoE device, the collocated unit has an additional cable that is connected to the HSS Unit. The HSS Unit is a compact, weatherproof (IP67) connector box that is installed on the same mast as the ODUs. All collocated units connect to this box using an HSS cable. Cables in prepared lengths are available for purchase. The HSS unit is supplied with ten protective covers; any port not in use must be closed with a protective cover. RADWIN 2000 D+ User Manual Release 3.6.00 4‐6...
Page 28 Accessories Chapter 4 Figure 4‐9: HSS Interconnection Unit See Hub Site Synchronization for further details about the use of HSS. RADWIN GSU The GPS‐based synchronization unit (GSU) is designed to handle inter‐site interferences under large‐scale deployment scenarios. The RADWIN GSU is a small form factor outdoor unit consisting of GPS antenna and a PoE device. Figure 4‐10: RADWIN GSU ‐ front and rear view. The RADWIN GSU may be operated over Ethernet or connected to an HSS Unit using a standard HSS cable. It synchronizes the transmission timing of multiple Hub‐Sites to the same clock source thus eliminating self‐interference (see Using the GSU). RADWIN 2000 D+ User Manual Release 3.6.00 4‐7...
Page 29: Figure 4-11 General Gsu Configuration Using Both Ethernet And An Hss Unit
Accessories Chapter 4 Figure 4‐11: General GSU configuration using both Ethernet and an HSS unit Lightning Protector Unit (LPU) The use of lightning protection is dependent on regulatory and end user requirements. The RADWIN 2000 D+ ODU is designed with surge limiting circuits to minimize the risk of damage due to lightning strikes. It is designed for use with RADWIN products. See RADWIN 2000 D+ User Manual Release 3.6.00 4‐8...
Page 30 Tools required for installation Chapter 4 Figure 4‐12: RADWIN Lightning Protector The lightning protector incorporates high‐power gas discharge tube and current transistor protection in a single protector unit. Ethernet Cable Repeater The RADWIN Ethernet repeater enables you to extend the PoE to ODU cable beyond the 100m limit (but no more than 200m). Figure 4‐13: RADWIN Ethernet Cable Repeater The Ethernet repeater cannot be used with GbE PoE‐ODU cables. Note 4.3 Tools required for installation The following is a list of the equipment and materials required to install RADWIN 2000 D+ hardware. 4.3.1 Tools and Materials • Crimping tool for RJ‐45 (if the ODU‐PoE cable is without connectors) • Spanner/wrench 13 mm (½”) • Drill (for wall mounting only) RADWIN 2000 D+ User Manual Release 3.6.00 4‐9...
Page 31 Cables and connectors Chapter 4 • Cable ties • Sealing material • Waterproofing tape such as Scotch 23 Tape ¾” wide, from 3M to ensure IP‐67 compliant protection against water and dust 4.3.2 Cables and connectors • ODU grounding cable 10 AWG • ODU‐PoE cable (outdoor class, CAT‐5e, 4 twisted pairs, 24AWG): • Up to 100 m. for 100BaseT connection. • For a 1000BaseT connection (HBS only) use an ODU‐PoE cable no longer than 75m. For 1000BaseT, you should use RADWIN supplied ODU‐PoE cables, which guarantees 1Gb performance. RADWIN cannot guarantee 1Gb performance if you use third party cables. Note • External CAT‐5e cable diameter should be between 7‐9 mm to ensure waterproof sealing. 4.4 Safety Practices and Provisions 4.4.1 Preventing Overexposure to RF Energy To protect against overexposure to RF energy, install the ODUs so as to provide and maintain minimal separation distances from all persons. When the system is operational, avoid standing directly in front of the antenna. Strong RF fields are present when the transmitter is on. The ODU must not be deployed in a location where it is possible for people to stand or walk inadvertently in front of the antenna. 4.4.2 Grounding All RADWIN products should be grounded during operation. In addition: • All ODUs should be earthed by a wire with diameter of at least 10 AWG. RADWIN 2000 D+ ODUs must be properly grounded to protect against lightning. It is the user's responsibility to install the equipment in accordance with Section 810 of the National Electric Code, ANSI/NFPA No.70‐1984 or Section 54 of the Canadian Electrical Code. These codes describe correct installation procedures for grounding outdoor units, ...
Page 32 Protection Against Lightning Chapter 4 • The earth lug on an IDU‐H should be connected to the protective earth at all times, by a wire with a diameter of 18 AWG or wider. Rack‐mounted equipment should be mounted only in earthed racks and cabinets. Further, you should ‐ • Always make the ground connection first and disconnect it last • Never connect telecommunication cables to ungrounded equipment • Ensure that all other cables are disconnected before disconnecting the ground 4.4.3 Protection Against Lightning The use of lightning protection is dependent on regulatory and end user requirements. All of RADWIN outdoor units are designed with surge limiting circuits to minimize the risk of damage due to lightning strikes. RADWIN recommends the use of additional surge arrestor devices to protect the equipment from nearby lightning strikes. 4.4.4 General • It is recommended that installation of outdoor units be contracted to a professional installer • Before working on equipment connected to power lines or telecommunication lines, you should remove jewelry or any other metallic object that may come into contact with energized parts • Use extreme care when installing antennas near power lines • Use extreme care when working at heights • When using an AC power source for RADWIN devices, always use the AC power adapter supplied by RADWIN • Use the right tools! • Do not mount an ODU upside down or horizontally. Doing this may void you product warranty. 4.4.5 Internal ESD Protection circuits RADWIN equipment is designed to meet the ETSI/FCC/Aus/NZ/CSA EMC and Safety ...
Page 33 Hardware Installation Workflow for a RADWIN 2000 D+ link Chapter 4 4.5 Hardware Installation Workflow for a RADWIN 2000 D+ link 4.5.1 Installing a Link Site Survey The Site Survey is carried out as described in Site Survey. Recall that the Site Survey has three main steps: • Stage 1: Preliminary Survey • Stage 2: Physical Survey • Stage 3: RF Survey Site preparation Site Preparation includes ‐ • Obtaining any necessary legal and statutory permits for installation of radio equipment • Clearing physical obstructions as far as possible • Erecting a mast or tower if required. A mast‐sited ODU typically uses a pole attached to the mast. • Installing a pole on a building wall if required • Constructing a weather‐proof cabinet to house a PoE device or other IDU if it is not to be housed indoors • Ensuring availability of power, typically standard local AC power • Ensuring that there is a LAN cable in place from the user’s switch to the PoE/IDU loca‐ tion RADWIN 2000 D+ User Manual Release 3.6.00 4‐12...
Page 34: Figure 4-14 Mounted Odu: Large Angle To Wall
Installing a Link Chapter 4 Mounting an ODU Use a mounting kit to mount an ODU on a wall or pole. An example is shown in the following figure: • When mounting an ODU on a pole or wall, ensure that the unit is ori‐ ented so that the cable connectors are at the bottom. • Do not mount an ODU horizontally • Ensure that there are no direct obstructions in front of an integrated antenna ODU or interference from man‐made obstacles. Note • For complete instructions on using the mounting kit, see the included Quick Installation Guide. The mounting kit has an extra arm enables the ODU to be mounted at large angles relative to the wall or pole, or to a horizontal pole, as shown: Figure 4‐14: Mounted ODU: large angle to wall Mounting an External Flat Panel Antenna Typically, a flat panel antenna such as that show in Figure 4‐16 has four bolts for a mounting kit adapter. RADWIN 2000 D+ User Manual Release 3.6.00 4‐13...
Page 35: Figure 4-15 Flat Panel Antenna Mounting Kit Adapter
Installing a Link Chapter 4 Figure 4‐15: Flat panel antenna mounting kit adapter It is mounted on a pole in exactly the same manner as the ODU itself using the adapter shown in Figure 4‐15. The left hand view in shows the knurled surface adjacent to the mounting kit ear. The right hand view shows the recess for the mounting kit holding nut. Figure 4‐16: Flat Panel antenna ‐ rear with mounting kit adapter Mounting External Antennas using Pole Clamps Many of the antennas of the types shown in Figure 4‐8 use the standard mounting kit. Some third party antennas use pole clamps, similar to those shown below: RADWIN 2000 D+ User Manual Release 3.6.00 4‐14...
Page 36 Installing a Link Chapter 4 Grounding an ODU external antenna External antennas should be individually grounded using a suitable Grounding Kit such as an Andrew Type 223158‐2 (http://www.commscope.com). Grounding the ODU There is a grounding lug on the rear of the HBS as shown in Figure 4‐17. Connect it to ground using 10 AWG wire. Grounding is often carried out in conjunction with lightning protection. Figure 4‐17: ODU: Grounding lug Installing a PoE device The PoE device (Figure 4‐2) is a very simple piece of equipment. It has a recessed three pin AC power plug, a matching power cable, a LAN‐In port (from a switch), a LAN‐Out port (to the HBS) and a power LED, green under normal operation. It is typically strapped into a network equipment rack using plastic ties. It may also sit free on a tray or table‐top. Connecting the ODU to the PoE device Connect the HBS to the LAN‐Out port only. It will not work on the LAN‐In port. RADWIN 2000 D+ User Manual Release 3.6.00 4‐15...
Page 37 The IDU‐H: A Base Station Alternative to PoE Devices Chapter 4 Connecting the PoE Device to a Network Connect the PoE to network equipment such as a switch from the LAN‐In port. Connecting network equipment to the LAN‐Out port may damage it. Powering up the ODU from a Poe Device Connecting the ODU port labelled IDU to a powered up PoE is sufficient. If you have not already closed and weather‐sealed the ODU port marked IDU, then inside it you can see an amber colored power LED which turn green when the ODU is activated. (See Getting Started with the RADWIN Manager.) Mounting the Lightning Protection Units (LPUs) The use of lightning protection is dependent on regulatory and end user requirements. The RADWIN 2000 D+ ODU is designed with surge limiting circuits to minimize the risk of damage due to lightning strikes. RADWIN recommends the use of additional surge arrestor devices to protect the equipment from nearby lightning strikes. The full mounting procedure is show in the LPU Quick Installation Guide, supplied as a hard copy pamphlet. Water Sealing External Ports for CAT‐5e Cables All external ODU ports should be water sealed. 4.5.2 The IDU‐H: A Base Station Alternative to PoE Devices Using an IDU‐H instead of several PoE devices The IDU‐H is an aggregation switch with the functionality of six PoE devices. It is ideal for use at a base station having several collocated ODUs. Figure 4‐18: IDU‐H Installing an IDU‐H The IDU‐H can sit on a table top, but is best installed in a rack using the supplied ears as in Figure 4‐5 and Figure 4‐6. Connecting the ODU to an IDU‐H Connect the IDU port to any of the six PoE ports of the IDU‐H. Connecting the IDU‐H device to a network The IDU‐H has two LAN ports, either of which may be used for network connection. RADWIN 2000 D+ User Manual Release 3.6.00 4‐16...
Page 38 The IDU‐H: A Base Station Alternative to PoE Devices Chapter 4 Grounding and Powering Up the IDU‐H The IDU‐H has redundant power connection circuits. An enlarged view of the power connectors is shown in below: Figure 4‐19: IDU‐H power connectors, grounding lug and power plug. • For direct DC connection: The connectors are 3 pin in line female, with polarities (left to right) minus, ground, plus. • For AC connection: To avoid damage to the IDU‐H, always use an AC/DC adapter and power plug supplied by RADWIN. Ground the unit with a 10 AWG wire before applying power. Warning IDU‐H ‐ Functional Overview Figure 4‐20: IDU‐H front panel The front panel is very straight forward: The SFP ports are standard. The LAN ports are Ethernet and support GbE. The six ODU WAN ports function identically to the LAN‐Out port on a PoE device. Radios connected to the WAN ports have Layer‐2 connectivity, required to collocate them if needed. See HSSoE Concepts. Note RADWIN 2000 D+ User Manual Release 3.6.00 4‐17...
Page 39 Towards Establishing a Link Chapter 4 The IDU‐H LEDs Table 4‐1: IDU‐H LED Indicators Port Green Yellow WAN (2xRJ45 LEDs) Link / Activity Duplex or Port’s PoE status (configurable) LAN (2xRJ45 LEDs) Link / Activity Duplex SFP (2 panel mounted LEDs) Link / Activity Duplex 4.6 Towards Establishing a Link To make best use of a RADWIN 2000 D+ link, you should have a Radio Plan based on your Site Survey. The plan should specify the precise location and alignment of the radio antennas. The RADWIN 2000 D+ radios are designed to operate in nLOS and NLOS environments so that it is possible that the alignment required may be off‐line of sight. To determine whether the radios communicate as planned you must carry out the first configuration steps described in the next chapter. For users familiar with classic style RADWIN 2000 links: The buzzer method of antenna alignment may not work here both because of the way a link is powered up and also because there is no absolute Note requirement for LOS. RADWIN 2000 D+ User Manual Release 3.6.00 4‐18...
Page 40 Chapter 5: Getting Started with the RADWIN Manager 5.1 Installing the RADWIN Manager Application 5.1.1 Minimum System Requirements The RADWIN Manager application is distributed on a CD. Operating system specific PC resources required by the application are set out in Table 5‐1 below: Table 5‐1: PC Requirements for the RADWIN Manager Application Windows Version Vista/7/8 XP Pro 32 bit 64 bit 512 Mb 1 Gb 2 Gb Memory P IV P IV Dual Core Processor Requirements common to all systems are: • Hard disk: 1 GB free space • Network: 10/100BaseT NIC • Graphics: 1024x768 screen resolution with 16 bit color • Any modern Web browser to view additional material, use the Web Interface or get help from the RADWIN Web site. 5.1.2 Installing the Software Any PC running the RADWIN Manager application can be used to configure a RADWIN 2000 D+ sector. RADWIN 2000 D+ User Manual Release 3.6.00 5‐1...
Page 41 Getting Started with the RADWIN Manager Chapter 5  To install the RADWIN Manager application: 1. Insert the CD into the CD/DVD drive of your computer. 2. The CD opening window appears: 3. Choose Install RADWIN Manager and follow the on‐screen instructions of the installation wizard to complete the setup of the RADWIN Manager application. If the installation program fails to start, browse to your CD/DVD drive, chose the setup.exe program and run it. 5.2 Getting Started with the RADWIN Manager 5.2.1 Preparation for First Log‐on As supplied, one ODU is factory pre‐configured as RT‐A(HBS) and the second as RT‐B(HSU).  To start the RADWIN Manager: 1. Connect the managing computer to PoE LAN port of the RT‐A(HBS)/ 2. The default IP address on all new radios is 10.0.0.120 with subnet mask, 255.0.0.0. Set your network interface to an available IP address on that subnet, say 10.0.0.111. This is the preferred way of logging on. 3. Check that you have connectivity to the ODU. You can do this by opening up a command line session (Start|Run and then type, cmd). At the command prompt, type RADWIN 2000 D+ User Manual Release 3.6.00 5‐2...
Page 42: Figure 5-1 Pinging The Base Station
First Log‐on Chapter 5 ping 10.0.0.120 You should see a display similar to this: Figure 5‐1: Pinging the base station. Any other response from ping means that the ODU is not responding. Check your Ethernet connection and that both the PoE and ODU are switched on and then try again. If you do not succeed, seek assistance from RADWIN Customer Service. 4. Dismiss the command line session. 5.2.2 First Log‐on Open the RADWIN Manager from the desktop icon, or click Start|Programs|RADWIN Manager|RADWIN Manager. The Log‐on dialog box appears: Figure 5‐2: Log‐on window ‐ default Log on with IP address 10.0.0.120 and password admin: RADWIN 2000 D+ User Manual Release 3.6.00 5‐3...
Page 43: Figure 5-3 Log - On Window Using An Ip Address
Log‐On with Local Connection Chapter 5 Figure 5‐3: Log‐on window using an IP address • The RADWIN Manager stores the last 10 successful log‐on IP addresses. • Other log‐on options are described below in The RADWIN Manager Note Log‐on Concept 5.2.3 Log‐On with Local Connection Alternatively, you can log on using Local Connection (Figure 5‐2) without need to change your Network Interface Card address. • The Local Connection method uses broadcast packets to “discover” the attached ODU • If you log on using Local Connection, but your physical connection is not local (i.e. anything other than a direct connection between the managing computer and the PoE device), then any configuration you carry out may affect other links in the network. Do not do this! • Do not carry out this procedure using a multi homed managing com‐ puter also connected to a network. It will flood the network with broadcast packets. Further, it will throw any other links on the network into Installation or Inactive mode. Warning • In any event, as a precaution, default log‐on over Local Connection is read‐only mode. Check the Read/Write enable box to carry out instal‐ lation procedures. • Network log on (IP address to the ODU) is recommended. RADWIN 2000 D+ User Manual Release 3.6.00 5‐4...
Page 44: Figure 5-4 Extended Log - On Window
The RADWIN Manager Log‐on Concept Chapter 5 5.3 The RADWIN Manager Log‐on Concept RADWIN 5000 supports SNMPv1 and SNMPv3 either separately or together. The log‐on procedure differs slightly between operation under SNMPv1 and SNMPv3. In what follows below, we assume that SNMPv1 is in use. In Table 5‐2 at end of the section, we show the difference between SNMPv1 and SNMPv3 at log‐on time. The RADWIN Manager provides three levels of access in one of two entry modes. To see them, click Options at any time in the Log on window (Figure 5‐2 above). You are offered an extended log‐on window: Figure 5‐4: Extended log‐on window At the User Type field, click the list button: Figure 5‐5: Log on window exposing the user types. There are three user types: RADWIN 2000 D+ User Manual Release 3.6.00 5‐5...
Page 45: Table 5-2 User Types , Default
The RADWIN Manager Log‐on Concept Chapter 5 • An Observer has read‐only access to the sector. An Observer can monitor the sector, generate reports, but may not change any sector parameters. • An Operator can install and configure the sector. • An Installer can, in addition to functioning as an Operator, also change the operating frequency band (or regulation). The latter function has legal ramifications, requiring familiarity with local regulations. You may choose the SNMP version. If your firewall blocks SNMPv3 messages and for security reasons cannot be changed them use SNMPv1. If you are using Trap Authentication, enter the User and Password. Leaving these fields blank or incorrect, will not prevent you from logging on. You will not be able to see trap messages directed to the trap message address associated with a defined user. The allocation and association of a trap address with a user is described in Management. If you are connecting through the RNMS server check the RNMS connect button and enter your server IP address. The following table summarizes these options: Table 5‐2: User types, default passwords and function SNMPv1 SNMPv3 Default User Type Function Communi Default Password Community Password ty String Value Observer admin Monitoring Read‐Only public Read‐Only public Installation, ...
Page 46: Figure 5-6 Unsupported Device Message
Log‐on Errors and Cautions Chapter 5 5.4 Log‐on Errors and Cautions 5.4.1 Unsupported Device Attempting to connect to an unsupported device on an otherwise valid IP address (for example, a LAN printer) will result in the following error message: Figure 5‐6: Unsupported device message 5.4.2 Incorrect IP Address If the IP address chosen is invalid or the sector is unreachable, the following error message will be displayed: Figure 5‐7: Unreachable device message 5.4.3 Incorrect Password If you type an incorrect password in the Login window, the follwing message will be displayed: RADWIN 2000 D+ User Manual Release 3.6.00 5‐7...
Page 47: Figure 5-8 Invalid User Type Or Password
Invalid Read/Write Community String or SNMPv3 Passwords Chapter 5 Figure 5‐8: Invalid user type or password 5.4.4 Invalid Read/Write Community String or SNMPv3 Passwords This will result in the same message as shown in Figure 5‐7.  To deal with lost or forgotten Community Strings: 1. Send an email request for to RADWIN Customer Service for an alternative key. Your email must include the ODU serial number shown on the adhesive sticker on rear of one of your ODUs. 2. The reply will contain an alternative key, which functions as a temporary master Community String. Copy/paste the supplied alternative key to both the Read‐Only and Read‐Write fields in the log‐on window (Figure 5‐4). This gets you to the RADWIN Manager main window. 3. Use the procedure in Editing SNMPv1 Community Strings to enter new Community Strings. 5.5 The Initial RADWIN Manager Main Window Upon successful log on, the main window is displayed: RADWIN 2000 D+ User Manual Release 3.6.00 5‐8...
Page 48: Figure 5-9 Main Window Prior To Link Configuration
Setting RADWIN Manager Preferences Chapter 5 Figure 5‐9: Main window prior to link configuration 5.6 Setting RADWIN Manager Preferences The Preferences tabs appearing on both the RT‐A(HBS) and RT‐B(HSU) relate entirely to the way the Manager displays certain items for the connected unit. They are completely local to the managing computer. They are identical for both the RT‐A(HBS) and RT‐B(HSU). Each technician servicing a sector will need to set up his managing computer (typically a laptop) with his own preferences. Note RADWIN 2000 D+ User Manual Release 3.6.00 5‐9...
Page 49: Figure 5-10 Monitor Preferences
Monitor Chapter 5 5.6.1 Monitor Figure 5‐10: Monitor Preferences The Monitor file contains a vast amount of information and can become inordinately large very quickly. You should therefore choose a longer sampling interval if you intend to store this information for a lengthy duration. For the RT‐A(HBS), it will show details for itself and RT‐B(HSU). The KMZ button is only relevant to Mobility sectors and otherwise does nothing. The content of the Monitor file will be discussed in more detail in Chapter 12. The Show IP item is useful if you are using both IPv4 and IPv6 addresses. The choice of compressed addresses will drop leading zeros and use the :: notation where appropriate. For example, the expanded address, FE80:0000:0000:0000:5AFE:00AA:20A2 compresses to Fe80::5AFE:AA:20A2. Switching the Show IP and Address Format items result in immediate display updating without the ned to press OK or Apply. Note RADWIN 2000 D+ User Manual Release 3.6.00 5‐10...
Page 50 Events Chapter 5 5.6.2 Events Here you may choose your own color coding for the Recent Event display (see Monitoring and Diagnostics). You may also choose a location and file name for the events log for storage. These settings are again, per RT‐A(HBS) or RT‐B(HSU). To avoid over‐writing, you should use file names reflecting their source ODU. The SNMPv3 User and Password are relevant if you are using SNMPv3. In this, case trap messages are keyed to the user name and password and not visible to anyone else. The preferences entered here, relate to trap messages sent to the specified user if specified or to all trap messages, otherwise. For associating a user with a trap address, see Chapter 8, Management. RADWIN 2000 D+ User Manual Release 3.6.00 5‐11...
Page 51: Figure 5-11 Advanced Preferences
Advanced Chapter 5 5.6.3 Advanced Figure 5‐11: Advanced Preferences Change Password You may change your log‐on password here from the default, admin. Restore Alerts Many alert messages in the RADWIN Manager have an option of the form “Do not show this message again”. These alert messages can be reverted to their default state (shown) by clicking the Restore Alerts button. You will be asked to confirm: Check for Updates If you are not connected to the Internet, disable the Check for updates check box. Enable RSS Balance Indication for Mobility This item is not functional and may be ignored. Enable RSS Extended View Checking this box enables a dual chain view for RSS. Disabled, the RSS is shown as a single bar for each radio. The effect is visible immediately. RADWIN 2000 D+ User Manual Release 3.6.00 5‐12...
Page 52 What Comes Next Chapter 5 Figure 5‐12: RSS Extended view enabled Figure 5‐13: RSS Extended view disabled Monitoring and Timeout Intervals The monitoring interval determines the lowest interval between request to the ODU for status updates. The timeout (default 1 sec, maximum 5 sec) may have to be increased if you are on a slow network. Setting the Map View Background Mode You have a choice of two map providers, a default or a self‐chosen background. If you log on without an Internet connection, you will get a default gray background or, if you have caching enabled, your last used map. 5.7 What Comes Next In Link Configuration we will show how to set up a link and then explore the Main window functions in detail. RADWIN 2000 D+ User Manual Release 3.6.00 5‐13...
Page 53 Chapter 6: Link Configuration 6.1 Chapter Contents This chapter is divided into two sections covering the two phases of Link configuration: 1. Link establishment: Initial setup 2. Link maintenance: Fine tuning and special functions Link establishment is typically a once‐only task. Link maintenance is required for fine‐tuning the link and configuration of special features such as VLAN, Quality of Service and more. 6.2 Link Establishment 6.2.1 Link Configuration Workflow The previous chapter showed you how to log on to the RT‐A(HBS). The RT‐A(HBS) requires activation. The ODU will commence transmitting and receiving packets related to link management only ‐ that is no service. Activation and Deactivation are effected quite simply by clicking a toggle button. Assuming that the ODU intended as Link RT‐B(HSU) is mounted aligned and powered up, it will discover the Master ODU establishing a link for management only. At this point the RT‐ B(HSU) may be managed over the air. Having Identified the Link RT‐B(HSU), the latter must be registered to the RT‐B(HSU) to enable traffic between them, completing phase 1. Following registration, you can set separately, • MIMO mode • Transmission ratio between uplink and downlink • Uplink and downlink Maximum Information Rate (MIR) in Mbps • VLAN parameters • Quality of Service parameters. In what follows, we assume that you are logged on to RT‐A(HBS) on IP address as shown in the previous chapter. Here is the opening situation: RADWIN 2000 D+ User Manual Release 3.6.00 6‐1...
Page 54: Figure 6-1 Main Window Prior To Link Configuration
Activating the RT‐A(HBS) Chapter 6 Figure 6‐1: Main window prior to link configuration 6.2.2 Activating the RT‐A(HBS)  To activate a HBS: 1. Click the Activate button. The Activation Wizard opens. 2. Click Next: RADWIN 2000 D+ User Manual Release 3.6.00 6‐2...
Page 55 Activating the RT‐A(HBS) Chapter 6 Enter the Sector ID, Name and Location. All fields are mandatory. Here are the entries for our demonstration link: You may also ignore the Coordinates button. Note 3. The Link Password may also be changed by clicking Change: RADWIN 2000 D+ User Manual Release 3.6.00 6‐3...
Page 56 Activating the RT‐A(HBS) Chapter 6 Full details for changing the Link Password may be found in Changing the Link Pass‐ word. It is best left as is if there is no pressing need to change it. If you skipped an entry, it will be framed in red like this: Note 4. From the previous Activation Wizard window, click Next. Enter the IP details. Here are our demonstration IP details: RADWIN 2000 D+ User Manual Release 3.6.00 6‐4...
Page 57 Activating the RT‐A(HBS) Chapter 6 To continue, click Next. 5. The next window is used to set the frequency and channels. The default frequency is the lowest available (5.735 GHz) in the operating band, 5.730 ‐ 5.845 GHz FCC/IC. 6. Click Other to see other available bands for this ODU. RADWIN 2000 D+ User Manual Release 3.6.00 6‐5...
Page 58 Activating the RT‐A(HBS) Chapter 6 7. For our purposes, we choose 5.820 GHz: right hand selector wheel Observe that the right hand spin‐wheel is no longer displayed. Had you left Other enabled, you could have chosen a frequency by working through those available in 5MHz increments. 8. Choose the required Channel Bandwidth: RADWIN 2000 D+ User Manual Release 3.6.00 6‐6...
Page 59 Activating the RT‐A(HBS) Chapter 6 If your hardware supports 250 Mbps net aggregate capacity, you should chose at least 40 MHz Channel Bandwidth to enable it. Note This release introduces automatic Dynamic Bandwidth Selection: If you choose 80MHz, the link may dynamically switch between 80, 40 MHz or 20MHz CBW to ensure the best throughput. If you choose 40 MHz, it may dynamically switch between 40 MHz or 20MHz. Selecting of one of 20, 10 or 5 MHz CBW sets your choice as the fixed CBW for the link. We will use 80 MHz. 9. Using ACS: • Choosing 40 or 80 MHz CBW automatically enables ACS. All that you may do is remove some of the channels: RADWIN 2000 D+ User Manual Release 3.6.00 6‐7...
Page 60 Activating the RT‐A(HBS) Chapter 6 • For CBW 20MHz or less, enable ACS by checking the Automatic Channel Selection box: You can perform a customized channel selection or click Select All to check all the channel boxes as shown: RADWIN 2000 D+ User Manual Release 3.6.00 6‐8...
Page 61 Activating the RT‐A(HBS) Chapter 6 10. Click Next. The Antenna type and Tx Power window is presented: The choice of Tx Power, antenna gain and cable loss (between the radio and the antenna) determines the EIRP and is affected by such considerations as radio limita‐ tions and regulatory restrictions. Before completing antenna installation, you might like to consider the background information about setting antenna parameters, in Setting Antenna Parameters. When setting Required Tx Power, it is your responsibility to chose a value in compliance with your local regulations. Warning Choose your Antenna Type, Required Tx Power, Antenna Gain and Cable Loss. We will set Required Tx Power to 5 dBm for our example. Click Next. 11. The Summary window of the Wizard is displayed. RADWIN 2000 D+ User Manual Release 3.6.00 6‐9...
Page 62: Figure 6-2 Main Window : Rt-A(Hbs) Activated , Rt-B(Hsu) Ready For Registration
Activating the RT‐A(HBS) Chapter 6 Check that all information showed is correct and click Activate. After a few moments the RT‐B(HSU) will be displayed in the Manager main panel as shown in the next fig‐ ure: Figure 6‐2: Main window: RT‐A(HBS) activated, RT‐B(HSU) ready for registration Notice the Rate line shown enlarged: RADWIN 2000 D+ User Manual Release 3.6.00 6‐10...
Page 63: Figure 6-3 Main Window : Link Master Odu Activated , Slave Odu Registered
Registering the RT‐B(HSU) Chapter 6 Observe that under management mode (no traffic) the throughput and MCS is mini‐ mal to support a link and the CBW is also at its minimum for DBS. 12. If you are using Local Connection, log out and log back in to the RT‐A(HBS) on its IP address. You may have observed that operating frequency 5.770 GHz shown, is not what we chose (5.820 GHz). The RT‐A(HBS) tries to optimize the frequency to minimize interference effects. We next register and configure the RT‐B(HSU). Many of the configuration and service parameters may be set prior to registration. During link establishment the order does not matter. However, many configuration changes to a link after registration, will affect traffic or even reset the link. 6.2.3 Registering the RT‐B(HSU) After few moments, the registration process completes. Here is the status of the link: Figure 6‐3: Main window: Link Master ODU activated, Slave ODU registered 6.2.4 Basic Configuration for Operations Several basic parameters should be configured for both link sites. Use the appropriate site Configuration button: RADWIN 2000 D+ User Manual Release 3.6.00 6‐11...
Page 64 Basic Configuration for Operations Chapter 6 RT‐A(HBS) Go to Configuration | System and change the Contact to something other than the default entry, “Person”: This only affects reports. RT‐B(HSU)  To complete basic configuration of the Slave ODU: 1. Go to Configuration | System and change the Name, Contact and Location fields to meaningful values: RADWIN 2000 D+ User Manual Release 3.6.00 6‐12...
Page 65 Basic Configuration for Operations Chapter 6 2. In the Tx & Antenna tab, ensure that Tx Power is set appropriately. For our demonstration link, we reduce it to 5dBm: 3. Open the Management tab and set the IP address, Subnet Mask and Default Gateway to their required values. Here are ours: RADWIN 2000 D+ User Manual Release 3.6.00 6‐13...
Page 66: Figure 6-4 Main Window : Link Fully Operational
Basic Configuration for Operations Chapter 6 4. Click OK on the Configuration window to save your changes. You are asked to confirm: 5. Accept the changes. Here is the status of the Link: Figure 6‐4: Main window: Link fully operational RADWIN 2000 D+ User Manual Release 3.6.00 6‐14...
Page 67: Figure 6-5 Link Air Interface Parameters - Manual Acs
Advanced Link Configuration Chapter 6 Notice the Rate line shown enlarged: Observe that in traffic mode the throughput and MCS are at their maximum and the CBW is also at its maximum. Under adverse conditions, such as high interference, DBS will cause these parameters to fallback for best throughput. 6.3 Advanced Link Configuration The link as configured so far, is sufficient to provide basic service. Additional link‐level services that can be configured from the Link Configuration tab on the top left of the main window. 6.3.1 Air Interface Figure 6‐5: Link Air Interface parameters ‐ manual ACS (CBW 10 or 20 MHz) RADWIN 2000 D+ User Manual Release 3.6.00 6‐15...
Page 68: Figure 6-6 Link Air Interface Parameters - Acs Enabled
Air Interface Chapter 6 Figure 6‐6: Link Air Interface parameters ‐ ACS enabled RADWIN 2000 D+ User Manual Release 3.6.00 6‐16...
Page 69: Figure 6-7 Link Air Interface Parameters - Dbs Enabled , Acs On By Default
Air Interface Chapter 6 Figure 6‐7: Link Air Interface parameters ‐ DBS enabled, ACS on by default Figure 6‐5 to Figure 6‐7 contain a subset of the Activation Air Interface settings. You may only change the Operating channel with ACS disabled. These parameters are automatically inherited by the RT‐B(HSU) when you click OK. Throughput Mode The Advanced button enables to choose a throughput mode: Throughput Mode determines how the Adaptive Modulation mechanism works. Maximum Throughput (default) should be chosen if throughput is more important than higher delay. Conversely, Reduced Latency minimizes delay at the expense of lower throughput. Link ID You may change this to any convenient string. After you click OK, RT‐B(HSU) will be immediately updated over the air without interruption to service. RADWIN 2000 D+ User Manual Release 3.6.00 6‐17...
Page 70 Ethernet Chapter 6 6.3.2 Ethernet MIMO Modes If you are using Dual Antennas, you may check a MIMO Mode: Spatial Multiplexing (default) splits the data in to two streams on transmission and recombines it on reception providing maximum throughput. Diversity transmits the same data on from both antennas and check for correctness on reception. For further details about MIMO antenna modes, see Link Configuration. Transmission Ratio The Transmission Ratio shows the allocation of throughput between downlink and uplink traffic at RT‐A(HBS). RADWIN 2000 D+ User Manual Release 3.6.00 6‐18...
Page 71 Ethernet Chapter 6 Figure 6‐8: RT‐A(HBS) Collocated client or independent unit The permissible Transmission Ratio is also dependent on RT‐A(HBS)’s HSS (collocation) status. (For further details about configuring and using HSS, see Hub Site Synchronization.) If the RT‐A(HBS) is an HSS master, you will see something like this: Figure 6‐9: RT‐A(HBS) Collocated master Moving the slider to the right in stages, yields the following: The effective available range for Aspymmetric allocation is determined by channel bandwidth as shown as well as link distance. In this context, “link” is a collocated RT‐A(HBS) or other RADWIN 2000 ODU. RADWIN 2000 D+ User Manual Release 3.6.00 6‐19...
Page 72: Figure 6-10 Change Or Add Bands
Changing the Link Band Chapter 6 Maximum Information Rate You can set separately, the uplink and downlink Maximum Information Rate (MIR) in Mbps or leave it as Unlimited. The MIR acts as a throttle; leaving the uplink or downlink as Unlimited commits the link to operating at best effort. VLAN and Quality of Service These services are covered respectively in VLAN Functionality and Quality of Service. 6.3.3 Changing the Link Band Changing the Band in use is always carried out at the link level (not per installed ODU). To change the Link Band you must be logged on to the RT‐A(HBS) as Installer. In Installer mode, the Tools drop‐down menu has an extra function, Change Band.  To change the Link Band: 1. Click Change Band. A list of available Bands is displayed: Figure 6‐10: Change or Add Bands 2. Select the required Band and click OK. For our purposes, we choose 5.720‐5.960 GHz Universal. The band is highlighted and right button is enabled. RADWIN 2000 D+ User Manual Release 3.6.00 6‐20...
Page 73: Figure 6-11 Add
Changing the Link Band Chapter 6 Figure 6‐11: Add/Change Band dialog 3. Click the right button. The following window opens: 4. Here you may chose the working channel bandwidth and channel selection as in the activation process. (We will set CBW to 80 MHz and ACS fully selected.) Click OK to accept your choice. You are returned to the display in Figure 6‐11. 5. Click OK again. The following cautionary message is displayed: RADWIN 2000 D+ User Manual Release 3.6.00 6‐21...
Page 74 Changing the Link Band Chapter 6 6. Click Yes to continue. After a short delay, you are offered a final confirmation: 7. Click OK. A link re‐sync follows. Here is the final result: Having set the channel bandwidth and operating channels earlier, there is no need for de‐activation and re‐activation. You may also add new Bands by clicking the Add Bands button. There are several provisos to this: • Additional Bands must be available for your hardware RADWIN 2000 D+ User Manual Release 3.6.00 6‐22...
Page 75: Figure 6-12 Add
Changing the Link Band Chapter 6 • Such additional Bands must be available within the framework of your local regulations The foregoing applies to both regulated and unregulated Bands.  To obtain and install additional bands: 1. As Installer, open the window of Figure 6‐10 above, and click Add Bands. The follow‐ ing instruction panel is displayed: Figure 6‐12: Add Bands Instructions Panel The serial numbers displayed are those of the ODUs in the link. Click Copy to Clip‐ board. 2. Now carry out steps 2 to 5 in Figure 6‐12. Step 2 will take you to a Web page, which contains a form like this: RADWIN 2000 D+ User Manual Release 3.6.00 6‐23...
Page 76 Changing the Link Band Chapter 6 3. Fill out the requested details. Remember to terminate the dialog by clicking the Get Key button. 4. The results of your request will be displayed with further instructions. RADWIN 2000 D+ User Manual Release 3.6.00 6‐24...
Page 77: Figure 6-13 Using The Master Odu (Hbs) Configuration Button For Licensing
.Logging on to the RT‐B(HSU) Over the Air Chapter 6 A few minutes later, you should receive an email, containing in its body, a list of license keys. You may see error messages in the Status Column such as Band not supported or Serial not found. Supported bands typically reflect your local regulations. Check missing serial numbers with RADWIN Customer Service. Note 5. Copy and Paste the license keys into a plain text file and save it to a safe known place. 6. Open the Configure | Operations tab for either ODU. Figure 6‐13: Using the Master ODU (HBS) Configuration button for licensing Check the License File button and navigate to the file you saved in the last step. 7. Click Activate. The next time you enter the Change Bands tab, the new bands will be available. 6.4 Logging on to the RT‐B(HSU) Over the Air You can log on to the RT‐B(HSU). The log on procedure is the same as for the RT‐A(HBS). The main window will appear as in Figure 6‐4, but with the RT‐A(HBS) and RT‐B(HSU) units reversed: RADWIN 2000 D+ User Manual Release 3.6.00 6‐25...
Page 78: Figure 6-14 Logging On To
Bulk Software Backup Chapter 6 Figure 6‐14: Logging on to the RT‐B(HSU) over the air Notice the over‐the‐air indicator in the status line: 6.5 Bulk Software Backup This covered in detail in Software Backup and Restore. 6.6 Configuration with Telnet 6.6.1 Telnet Access to Either ODU A Telnet terminal can be used to configure and monitor the RADWIN 2000 D+. To start a Telnet session on the RT‐A(HBS), use telnet <ODU_IP>. For example, if you run Telnet as follows, telnet 10.104.3.2 you will be asked for a user name and password. The Telnet log on user name is the password that you used to enter the RADWIN Manager (for example, the default: admin). The Telnet password is the corresponding Community string (default: netman). RADWIN 2000 D+ User Manual Release 3.6.00 6‐26...
Page 79: Figure 6-15 Telnet Session Log
Command Explanation Displays ODU product name, Name, Location, display inventory hardware and software revisions, uptime, MAC address. display management Displays IP, subnet, Gateway, Traps table display link Displays all static details about the link display ethernet Displays Port table (State, Status and action) display ethernet_errors Displays Cable statistics display ntp Displays Time, Server and Offset Shows the performance monitor tables for each display PM <interface:AIR,LAN1> interface according to user defined monitoring <interval:current,day,month> intervals display bands Displays available bands display ldpc_mode On or off; default off Table 6‐2: ODU Telnet ‐ Set Immediate Commands Command Explanation Set the ODU IP address, subnet mask and gateway. set ip <ipaddr> <subnetMask> The user must reset the ODU after the command <gateway> completion set trap <index:1‐10> <ipaddr> Set a specific trap from the traps table (e.g. set trap 3 <port:0‐65535> 192.168.101 162) RADWIN 2000 D+ User Manual Release 3.6.00 6‐27...
Page 80 <passwdRADWIN PtP SCB Jet> Set the read‐write access password (Read‐Write set writepw <oldpasswd> <passwd> Community) set trappw <oldpasswd> <passwd> Set the trap Community string set buzzer <mode> mode: 0 = off, 1 = auto, 2 = on set tpc<power:Value between Set the ODU Tx Power. If a wrong value is entered, minimal Tx power, and maximal Tx both min and max values shall be displayed in the power> error reply set name <new name> Set the name of the link set location <new location> Set the name of the location set contact <new contact> Set the name of the site manager set ethernet <port:LAN1> <mode:AUTO,10H,10F,100H,100F,D Set the mode and speed of the Ethernet port ISABLE> Resets the ODU. The user is warned that the reboot command will reset the ODU. A new Telnet session to the ODU may be opened after the reset is complete. help Displays the available commands Table 6‐3: ODU Telnet ‐ Set Commands requiring Reset Command Explanation set secId <SectorID> Set new sector ID set ldpc_mode <mode:on,off> Sets ldpc mode RADWIN 2000 D+ User Manual Release 3.6.00 6‐28...
Page 81: Figure 7-1 Site Tool Bars
Chapter 7: Site Configuration 7.1 Site Tool Bar Here are the site tool bars and their functions: Figure 7‐1: Site Tool Bars Table 7‐1: Site Buttons - Description Applies to Menu Button Purpose / Reference site Both Open the Site Configuration Window Both Recent Events Both Active Alarms RT‐A(HBS) Deactivate RT‐A(HBS) Both Reset the ODU RT‐B(HSU) Deregister RT‐B(HSU) RT‐B(HSU) Suspend a Deregistered RT‐B(HSU) In this chapter we describe the Site Configuration window in detail, noting differences between the RT‐A(HBS) and RT‐B(HSU) side of Link site window. We also comment briefly on the last four items in Table 7‐1. RADWIN 2000 D+ User Manual Release 3.6.00 7‐1...
Page 82: Figure 7-2 Site Configuration
Site Configuration Window Chapter 7 7.2 Site Configuration Window The Site Configuration windows are slightly different for the RT‐A(HBS) and RT‐B(HSU). Figure 7‐2: Site Configuration window ‐ RT‐A(HBS) Figure 7‐3: Site Configuration window ‐ RT‐B(HSU) RADWIN 2000 D+ User Manual Release 3.6.00 7‐2...
Page 83 Configuration Tabs Chapter 7 The RT‐A(HBS) site has a tab to configure HSS. Otherwise, the side tabs have identical functionality for both sites. Further, the tool bars are common to both sites have identical functionality. 7.3 Configuration Tabs 7.3.1 System 7.3.2 Tx & Antenna You may use this tab at either site to further fine‐tune Tx Power parameters set at Activation time. RADWIN 2000 D+ User Manual Release 3.6.00 7‐3...
Page 84 Hub Site Sync (RT‐A(HBS) Only) Chapter 7 Changing the Tx and Antenna parameters will take immediate effect without service interruption. 7.3.3 Hub Site Sync (RT‐A(HBS) Only) See Hub Site Synchronization for details about configuring HSS. RADWIN 2000 D+ RT‐B(HSU)s cannot be collocated. Note 7.3.4 Management IP Addresses We already used the management tab to set the IP addresses for the RT‐B(HSU). If you set the IP and related addresses correctly, you will not need to change them. Here is a “classic” IPv4 configuration: RADWIN 2000 D+ User Manual Release 3.6.00 7‐4...
Page 85 Management Chapter 7 IP Version You may configure a link for IPv4, IPv6 or both: Here we choose both and enter the IPv6 addresses: RADWIN 2000 D+ User Manual Release 3.6.00 7‐5...
Page 86 Management Chapter 7 Using both IP versions is useful in conjunction with applications that do not fully support IPv6. here are the results of setting IPv6 addresses for both sites and enabling Show IP to IPv6 in Preferences | Monitor: RADWIN 2000 D+ User Manual Release 3.6.00 7‐6...
Page 87 Management Chapter 7 Trap Destinations  To change a trap IP address: 1. Open an entry with its edit button: The following entry window is displayed: 2. Enter the Trap Destination IP Address and Port. It could be the IP address of the managing computer. The events log will be stored at the addresses chosen. IP addresses may be IPv4 or IPv6. Note RADWIN 2000 D+ User Manual Release 3.6.00 7‐7...
Page 88 Management Chapter 7 3. For Security model you may choose between SNMPv1 or SNMPv3. The choice is site dependent. If you choose SNMPv1, you may only enter an IP address and port number. For SNMPv3, you should supply a user name and password: 4. Click OK to save your choice. Note that for each active trap destination, the Clear Trap Destination button is enabled: VLAN for Management Management VLAN Configuration Figure 7‐4: VLAN for Management VLAN IDs are used by RADWIN products in three separate contexts: Management VLAN, Traffic VLAN and Ethernet Ring. It is recommended that you use different VLAN IDs for each context. Caution VLAN Management enables separation of user traffic from management traffic whenever such separation is required. It is recommended that each member of a sector be configured with different VLAN IDs for management traffic. (This reduces your chances of accidentally locking yourself out of the link.)  To enable VLAN for management: 1. In the window of Figure 7‐4, check the Enabled box. 2. Enter a VLAN ID. Its value should be between 2 and 4094. After entering the VLAN ID, only packets with the specified VLAN ID are processed for management purposes by the RT‐A(HBS)/RT‐B(HSU) ODU. This includes all the protocols supported by the ODU (ICMP, SNMP, Telnet and NTP). Using VLAN for man‐ RADWIN 2000 D+ User Manual Release 3.6.00 7‐8...
Page 89: Figure 7-5 Supported Protocols
Management Chapter 7 agement traffic affects all types of management connections (local, network and over the air). 3. Enter a Priority number between 0 and 7. The VLAN priority is used for the traffic sent from the ODU to the managing com‐ puter. 4. Change the VLAN ID and Priority of the managing computer NIC to be the same as those of steps 2 and 3 respectively. 5. Click Apply or OK. Lost or forgotten VLAN ID If the VLAN ID is forgotten or there is no VLAN traffic connected to the ODU, then reset the relevant ODU. During the first two minutes of connection, the ODU uses management packets both with and without VLAN. You may use this period to reconfigure the VLAN ID and priority. If the managing computer is directly connected to an ODU, and you enable management VLAN, you will lose connectivity. To log on again, You will need to configure the managing computer NIC to use the management VLAN Caution number. Supported Protocols Supported protocols are shown in Figure 7‐5: Figure 7‐5: Supported protocols SNMP support is permanently enabled. You may choose between SNMPv1, SNMPv3 or both. If you choose SNMPv3, you will be offered the following cautionary message: RADWIN 2000 D+ User Manual Release 3.6.00 7‐9...
Page 90 Management Chapter 7 For a link managed as part of a network, direct access to either site using Telnet is considered to be a security breach. Telnet access may be enabled or disabled by clicking the Protocol tab and enabling/disabling Telnet access using the Telnet check‐box. Similar considerations apply to access via the Web Interface. • For further details about Telnet access see Configuration with Telnet. • For further details about the Web Interface, see Using the Web Interface. Telnet and Web Interface access modes when available, are site specific. If for example, you want Telnet access from a specific site, you should enable it for that sites and disable it for the other. Conversely, If the Telnet or Web Interface access modes pose a general security risk, you must disable them for each site separately. Multiuser Support under SNMPv3 If you chose SNMPv3 or both versions, you are asked to log on again: For the first log‐on under SNMPv3, use as password, the User Name, admin. There is one change to the main window. The title bar now shows the SNMPv3 user name: Further, there is an additional button, SNMPv3 Users, in the Management window: RADWIN 2000 D+ User Manual Release 3.6.00 7‐10...
Page 91 Management Chapter 7 Using the new button opens up the following entry list: RADWIN 2000 D+ User Manual Release 3.6.00 7‐11...
Page 92: Figure 7-6 Add Or Edit Auser
Management Chapter 7 To make any of the following changes, you must be logged on as user admin. The SNMPv3 passwords for admin and operator are as follows: Table 7‐2: SNMPv3 predefined users User Name Password Profile admin netwireless Read Write operator netpublic Read Only  To add an SNMPv3 user: 1. Click the right hand edit icon on any empty line of the list: 2. An Edit window is displayed: Figure 7‐6: Add or Edit a user 3. Enter a user name and password. Confirm the password as indicated. 4. Choose a Profile: • Read Only provides Observer level log‐on access. • Read Write provides Operator level log‐on access • Disabled stores the user details in the data base for future use. It must be changed to Read Only or Read Write to become usable. RADWIN 2000 D+ User Manual Release 3.6.00 7‐12...
Page 93 Management Chapter 7 5. Click OK to accept. Here is the result of adding one more Read Write user, one Read Only User and one “Disabled” user: Figure 7‐7: SNMPv3 users list  To edit an existing user: 1. Use the same procedure as above to choose a user for editing. For illustration, we will correct the spelling of Teleman’s name: 2. Click the edit button: RADWIN 2000 D+ User Manual Release 3.6.00 7‐13...
Page 94 Management Chapter 7 3. Correct the spelling of the name: 4. Enter and confirm the user’s password: 5. Click OK to finish. The change will be reflected in the display of Figure 7‐7. 6. Use the same method to change the user’s profile. Passwords are never displayed as clear text. If a user looses his password, the only way that the situation can be corrected is to delete the user name and re‐create the same user name with another password. Note Logging on as a SNMPv3 User  To log off as user admin and log on as a Read Write profile user (Vivaldi): 1. Here is the default log‐on dialog: RADWIN 2000 D+ User Manual Release 3.6.00 7‐14...
Page 95: Figure 7-8 Default Snmp Log
Management Chapter 7 Figure 7‐8: Default SNMP log‐on dialog 2. In the right hand window, enter the user name (Vivaldi) and password. 3. For a Read Write profile user, you may log on as any user type (Observer, Operator, Installer). For example, log on Vivaldi as Operator. Since Vivaldi belongs to the Read Write profile, in the left hand window, use admin for the Password and leave User Type as is. (If necessary, you can use wireless and Installer, respectively.) In the main window we see the user name in the title bar: RADWIN 2000 D+ User Manual Release 3.6.00 7‐15...
Page 96 Management Chapter 7  To log on as a Read Only profile user (Handel): 1. In Figure 7‐8, log on as Handel instead of Vivaldi. 2. On the left hand side, set user type to Installer and password to wireless. In the main window we see the user name in the title bar as follows: The rule is, that the logged on privilege level will be the lowest of the SNMPv3 user type and the RADWIN Manager user type. Inventory You might like to capture or copy the information here: Use the button to the right of the Serial Number field to cony the serial number to the clipboard. The Inventory information will be required by Customer Service should you require assistance. RADWIN 2000 D+ User Manual Release 3.6.00 7‐16...
Page 97: Figure 7-9 Sector Security
Management Chapter 7 Security Figure 7‐9: Sector Security settings ‐ RT‐A(HBS) The Security dialog enables you to change the Link Password and the SNMP Community strings. Changing the Link Password This item is available as follows: • At the RT‐A(HBS) • At an isolated RT‐B(HSU) Here are the details: The default password is wireless‐p2mp. Optionally, you can change the link password as explained here.  To change the link password: 1. Open the Security tab (Figure 7‐9). The Change Link Password dialog box opens. Use the Hide characters check box for maximum security Note RADWIN 2000 D+ User Manual Release 3.6.00 7‐17...
Page 98: Figure 7-10 Change Linkp
Management Chapter 7 Figure 7‐10: Change Link Password dialog box 2. Enter the current link password (The default link password for a new ODU is wireless‐ p2mp). If you have forgotten the Link Password, click the Forgotten Link Password button. The following window is displayed: Figure 7‐11: Lost or forgotten Link Password recovery Follow the instructions to use the Alternative Link Password, and click OK to finish. You are returned to the window in Figure 7‐10 above. Continue with the next step. 3. Enter a new password. 4. Retype the new password in the Confirm field. 5. Click OK. 6. Click Yes when asked if you want to change the link password. 7. Click OK at the Password changed success message. • A link password must contain at least eight but no more than 16 char‐ acters excluding SPACE, TAB, and any of “>#@|*?;.” • Restoring Factory Defaults returns the Link Password to wireless‐ Note p2mp. RADWIN 2000 D+ User Manual Release 3.6.00 7‐18...
Page 99 Management Chapter 7 RADWIN Manager Community Strings The ODU communicates with the RADWIN Manager using the SNMPv1 or SNMPv3 protocol. The SNMPv1 protocol defines three types of communities: • Read‐Only for retrieving information from the ODU • Read‐Write to configure and control the ODU • Trap used by the ODU to issue traps. The Community string must be entered at log on. You must know the password and the correct Community string to gain access to the system. You may have read‐only privileges. It is not possible to manage the ODU if the read‐write or the read Community values are forgotten. A new Community value may be obtained from RADWIN Customer Service for the purpose of setting new Community. You must also have available the serial number or the MAC address of the ODU. The read‐write Community strings and read‐only Community strings have a minimum of five alphanumeric characters. (bru1 and bru4097 are not permitted). Changing the trap Community is optional and is done by clicking the check box. Editing SNMPv1 Community Strings When editing these strings, both read‐write and read‐only communities must be defined. Upon logging on for the first time, use the following as the current Community: • For Read‐Write Community, use netman. • For Read‐Only Community, use public. • For Trap Community, use public  To change a Community string: 1. Type the current read‐write Community (default is netman). 2. Choose the communities to be changed by clicking the check box. 3. Type the new Community string and re‐type to confirm. A community string must contain at least five and no more than 32 characters excluding SPACE, TAB, and any of “>#@|*?;." 4. Click OK to save. Editing SNMPv3 Passwords To commence the process, you must enter the current Read‐Write Community password as shown in the first field of Figure 7‐12 below. Change the Read‐Write an d Read‐Only ...
Page 100: Figure 7-12 Changing Thec
Management Chapter 7 Figure 7‐12: Changing the Community Strings/Passwords Forgotten SNMPv1 Community String If the read‐write Community string is unknown, an alternative Community key can be used. The alternative Community key is unique per ODU and can be used only to change the Community strings. The alternative Community key is supplied with the product, and should be kept in a safe place. If both the read‐write Community and the alternative Community key are unavailable, then an alternative Community key can be obtained from RADWIN Customer Service using the ODU serial number or MAC address. The serial number is located on the product label. The serial number and the MAC address are displayed in the Site Configuration inventory tab. When you have the alternative Community key, click the Forgot Community button and enter the Alternative Community key (Figure 7‐13). Then change the read‐write Community string. RADWIN 2000 D+ User Manual Release 3.6.00 7‐20...
Page 101: Figure 7-13 Alternativec
Management Chapter 7 Figure 7‐13: Alternative Community Dialog box Date & Time The ODU maintains a date and time. The date and time should be synchronized with any Network Time Protocol (NTP) version 3 compatible server. During power‐up the ODU attempts to configure the initial date and time using an NTP Server. If the server IP address is not configured or is not reachable, a default time is set. When configuring the NTP Server IP address, you should also configure the offset from the Universal Coordinated Time (UTC). If there is no server available, you can either set the date and time, or you can set it to use the date and time from the managing computer. Note that manual setting is not recommended since it will be overridden by a reset, power up, or synchronization with an NTP Server. The NTP uses UDP port 123. If a firewall is configured between the ODU and the NTP Server this port must be opened. It can take up to 8 minutes for the NTP to synchronize the ODU date and Note time.  To set the date and time: 1. Determine the IP address of the NTP server to be used. 2. Test it for connectivity using the command, for example: w32tm /stripchart /computer:216.218.192.202 RADWIN 2000 D+ User Manual Release 3.6.00 7‐21...
Page 102: Figure 7-14 Date And Timec
Management Chapter 7 Figure 7‐14: Date and Time Configuration 3. If entering an IP address for the NTP Server, click Clear, and then enter the new address. 4. Set your site Offset value in minutes ahead or behind GMT 5. To manually set the date and time, click Change and edit the new values. Figure 7‐15: Change Date and Time 6. Click OK to return to the Configuration dialog. 1. Greenwich Mean Time RADWIN 2000 D+ User Manual Release 3.6.00 7‐22...
Page 103 Management Chapter 7 Ethernet Figure 7‐16: Setting Ethernet services Aging Time The RT‐A(HBS) works in Bridge Mode. In Bridge mode the ODU performs both learning and aging, forwarding only relevant packets over the sector. The aging time of the ODU is by default, 300 seconds. Ethernet Ports Configuration The ODU Ethernet port mode is configurable for line speed (10/100/1000BaseT) and duplex mode (half or full duplex). Line speed 1000BaseT is only available if the ODU is connected to A GbE PoE device. An Auto Detect feature is provided, whereby the line speed and duplex mode are detected automatically using auto‐negotiation. Use manual configuration when attached external equipment does not support auto‐negotiation. The default setting is Auto Detect. RADWIN 2000 D+ User Manual Release 3.6.00 7‐23...
Page 104: Figure 7-17 Restore Factory
Management Chapter 7 The icon next to the CRC error count may be clicked to reset the counter to zero. You should not reconfigure the port that is used for the managing computer connection, since a wrong configuration can cause a management disconnection or Ethernet services interruption. Caution  To configure the Ethernet Mode: • In the Ethernet Ports Configuration pane, use the drop‐down menus to choose the required modes. Operations Figure 7‐17: Restore Factory Settings, License Activation and Change ODU Mode Reverting to Factory Settings Clicking the Restore Defaults button opens the following self explanatory dialog: RADWIN 2000 D+ User Manual Release 3.6.00 7‐24...
Page 105: Table 7-3 Enhanced Feature
Site Configuration Tool Bar Chapter 7 License Activation Some product enhancements require a license key or a file of license keys. For a single key, just enter the supplied license Key and click Activate. If you have a list of them (a text file) you will need to use the License File option. In some instances it may involve purchasing the relevant license from RADWIN. You should contact Customer Service for details. Table 7‐3: Enhanced feature support May be free; Add bands Changing the Link Band regulatory requirement Change ODU Mode Your two radios as supplied, were pre‐configured as RT‐A(HBS) and RT‐B(HSU) so you should never need to use this. It is intended for use by a field technician. 7.3.5 Site Configuration Tool Bar Backup and Restore The Backup and Restore buttons provide for backup and restore of the ODU software.For further information about Backup and Restore, see Software Backup and Restore. Buzzer The Buzzer button may set or mute the buzzer. The buzzer tone is primarily used for ODU antenna alignment. The default setting is Auto. RADWIN 2000 D+ User Manual Release 3.6.00 7‐25...
Page 106 Deactivate RT‐A(HBS) Chapter 7 Refresh The Refresh button restores the current window to its previous state abandoning any changes you made, provided that you did not click Apply or OK. 7.4 Deactivate RT‐A(HBS) Deactivating the RT‐A(HBS) halts traffic over the link and drops it back to the default transmission mode prior to configuration with one exception: The RT‐B(HSU) remains “registered” but inaccessible over the air. You can reactivate the RT‐A(HBS) without need to re‐register the RT‐B(HSU). All of the RT‐B(HSU) configuration settings are preserved. 7.5 Deregister RT‐B(HSU) Deregistering the RT‐B(HSU) stops link traffics but leaves it accessible over the air from the RT‐ A(HBS). All of the RT‐B(HSU) tool bar functions are available. 7.6 Suspend a Deregistered RT‐B(HSU) You may break the link (cause a full sync loss) to the deregistered RT‐B(HSU) for a fixed amount of time. 7.7 Reset the ODU The reset functions are equivalent to powering the ODU down and then powering it up again. RADWIN 2000 D+ User Manual Release 3.6.00 7‐26...
Page 107: Table 8-1 Get Diagnosticsd
Chapter 8: Monitoring and Diagnostics The RADWIN Manager application enables you to monitor the sector, as well as perform basic diagnostic operations such as throughput testing. This chapter covers: • Retrieving Link Information • Throughput Checking • Recent Events • Performance Monitoring • Manager Traps • Active Alarms Other relevant facilities include: • Link Budget Calculator • Customer Service 8.1 Retrieving Link Information The Get Diagnostics feature collects and writes link and Manager information from selected sites into a text file. The file information can be used for diagnostics and should be sent to RADWIN Customer Service to expedite assistance. The following table lists link and system information that can be monitored. Table 8‐1: Get Diagnostics Data and Description Data Description System Data General information about the system • List of system events including those from other sites if this site is defined as the trap destination Events Log • Last 256 events from all sites Link Information Information about the RT‐A(HBS) and RT‐B(HSU) settings RADWIN 2000 D+ User Manual...
Page 108: Figure 8-1 Get Diagnostics
Retrieving Link Information Chapter 8 Table 8‐1: Get Diagnostics Data and Description (Continued) Data Description Site Configuration Data about the site parameters Monitor Detailed event data record Active Alarms Active Alarms are raised for any event affecting availability or quality Service Configuration Settings: MIMO, Tx Ratio, MIR, VLAN, QoS Performance Monitor Network performance data over defined time periods ‐ ‐ every 15 Spectrum Analysis For HBS, selected HSUs and general inter fence statistics for the sector  To get diagnostics: 1. Click the Get Diagnostics button: Figure 8‐1: Get Diagnostics window 2. Select or deselect the data options. If the file is to be sent to RADWIN Customer Service leave all options checked. 3. Click File Path to specify the file name and older in which you want to save the file and then click Run to save the information. On completion, the status of the checked items is confirmed: RADWIN 2000 D+ User Manual Release 3.6.00 8‐2...
Page 109 Throughput Checking Chapter 8 The content of the Diagnostics report is an aggregate of all the more specific reports discussed below. It is primarily intended for use by RADWIN Customer Service. The Spectrum Analysis output is available directly from the Spectrum View utility as a CSV file (see Spectrum View). The format in the Diagnostics report is intended for use by RADWIN Customer Service. The Spectrum Analysis section of the Diagnostics report is based on the last available spectrum analysis (if any). If you are submitting a support request involving interference issues, or if you are specifically asked by Customer Note Service to submit a Diagnostics report containing a recent spectrum analysis, you should carry out the analysis in accordance with the Spectrum View instructions prior to using the Get Diagnostics facility. 8.2 Throughput Checking In this mode, RADWIN 2000 D+ estimates Ethernet throughput by filling frames over the air to maximum for 30 seconds. This mode should not influence service.  To use Throughput Checking: 1. Chose Estimated Throughput from the Tools tab: RADWIN 2000 D+ User Manual Release 3.6.00 8‐3...
Page 110 Throughput Checking Chapter 8 2. You are asked to enter the testing period: 3. Enter the required time and click OK to continue. The Ethernet services area changes appearance and the estimated throughput is displayed: At the end of 30 seconds, the display reverts to normal. RADWIN 2000 D+ User Manual Release 3.6.00 8‐4...
Page 111 Recent Events Chapter 8 8.3 Recent Events The Recent Events log records system failures, loss of synchronization, loss of signal, compatibility problems and other fault conditions and events. The foregoing event types include events from all links for which this managing computer has been defined as the traps address. Only events from RADWIN equipment will be shown. Note Alarms (traps) are displayed in the Events Log in the lower panel of the main window. The Events Log may be saved as a text file. The Events Log includes the following fields: » Sequential number (ID) » Date and time stamp » Message » Trap source » IP address of the ODU that initiated alarm. You may filter the events shown by choosing All or Internal. A full report may be seem by clicking Recent Events in either ODU tool bar: In each case the report has the same format: RADWIN 2000 D+ User Manual Release 3.6.00 8‐5...
Page 112 Performance Monitoring Chapter 8 Here is a more readable enlargement of the table area: The left button may be used to save the report to a file. 8.4 Performance Monitoring 8.4.1 Obtaining Reports RADWIN 2000 D+ Performance Monitoring constantly monitors traffic over the radio link and collects statistics data for the air interface and Ethernet ports. It does so continuously, even when the RADWIN Manager is not connected. The report is obtained from the Tools tab: The on‐screen and generated reports have the same general formats, but there are differences in what is reported. The Performance Monitoring window offers the following button menu: RADWIN 2000 D+ User Manual Release 3.6.00 8‐6...
Page 113: Figure 8-2 Setting The Upper
Obtaining Reports Chapter 8 You can choose monitoring for Uplink or Downlink: Choose the data period required with the 15 Minutes button. • Current gives you the latest entry. • 15 Minutes provides data in a scroll down list in 15 minute intervals • Daily (24 hours) shows results for the last 30 days at midnight. The Threshold button enables you to set the upper traffic thresholds for reporting. Traffic conditions above the threshold indicate congestion and probably lost frames. The thresholds are set separately for uplink and downlink: Figure 8‐2: Setting the upper traffic threshold ‐ Downlink To get data for display, click Get Data. The process may take a few seconds. RADWIN 2000 D+ User Manual Release 3.6.00 8‐7...
Page 114: Figure 8-3 Downlink - P
Column Heading Description Meaning Green tick for current and valid; Red cross for invalidated data (See example below). Note that the Integrity Valid data flag Performance Monitoring data is not valid if not all the values were stored (e.g., due to clock changes within the interval or power up reset) Data are recorded every 15 minutes; the last 30 days Date & Time Time stamp of recordings are maintained. Roll‐over is at midnight. Unavailable Seconds in which the interface was out of service. Seconds The number of seconds in which there was at least Errored seconds one error block. Severe Errored The number of seconds in which the service quality Seconds was low as determined by the BBER threshold. Background The number of errored blocks in an interval. Block Error Received The number of Megabytes received at the specified Rx MBytes Mbytes port within the interval Transmitted The number of Megabytes transmitted at the Tx MBytes Mbytes specified port within the interval. RADWIN 2000 D+ User Manual Release 3.6.00 8‐8...
Page 115 Chapter 8 Table 8‐2: HBS Performance Monitoring Fields (Continued) Abbreviation Column Heading Description Meaning Above Traffic Threshold set in Seconds count when actual traffic exceeded the Thresh Figure 8‐2 threshold The number of seconds that the configured Ethernet Active Seconds service is active Data becomes invalidated following a reset. In the example below, the Slave ODU was reset shortly after 08:45. All data prior to that time becomes invalidated. The only valid items are the recordings following the re‐sync. Figure 8‐4: HBS ‐ Performance Monitoring report ‐ Showing invalid data Use the Save button to store the current data to a file and the Clear button to delete currently stored performance data. 8.4.2 More on the Thresholds RSL Thresholds Two RSL Thresholds can be defined. They are used as an indicator of problems in the radio channel. You can check the RSS from the Link Budget Calculator results during installation. Values of ‐5dB and ‐8dB from the current RSS are typical. TSL Threshold A counter is maintained, of the number of second intervals during which Tx power exceeds this threshold. BBER Threshold The Background Block Error Ratio is measured as a percentage. The threshold can be set from 0.1% up to 50%. An 8% threshold is recommended. If there are no problems during the interval, then for that threshold, the recommended BBER value should be 0. Since the system provides a lossless Ethernet service, there is throughput degradation in case of interference. The degradation is proportional to the BBER. RADWIN 2000 D+ User Manual Release 3.6.00 8‐9...
Page 116 Manager Traps Chapter 8 Ethernet Thresholds ‐ Capacity This is used as a basis for checking adherence to a Service Level Agreement. It is the number of seconds count that the link capacity falls bellow the threshold. Ethernet Thresholds ‐ Traffic The number of seconds count that received traffic exceeded this threshold. It can be used to measure traffic peaks. 8.5 Manager Traps The RADWIN Manager application issues traps to indicate various events, displayed in the Events Log. Table 8‐3: RADWIN Manager Trap Messages Trap Message Severity Remarks Cannot bind to trap service port. Port Warning RADWIN Manager will not catch any 162 already in use by ProcessName traps from the ODU, some other (pid: ProcessId) application has grabbed this port. Device unreachable! Error Check connectivity to ODU Connected to <site_name> Information <site_name> Site will be reset. Information Restore Factory Default Settings in Information process on Site <site_name> Factory Settings: The process was not Warning Factory setting failed due to finished due to connection issues. connectivity problem to ODU Reset: The process was not finished Warning Factory setting failed due to ...
Page 117 Active Alarms Chapter 8 Table 8‐3: RADWIN Manager Trap Messages (Continued) Trap Message Severity Remarks The Product is not identified at both Warning sites. Product Not Identified! Warning The Manager identified a newer ODU Warning ODU release is newer than RADWIN release at the <remote_site_name> Manager release. site. Wizards are not available. RADWIN Manager will be used just for monitoring. Upgrade the RADWIN Manager. (You will get this message as a pop up) The Manager identified a newer ODU Warning release at the <local_site_name> site. Newer Version identified at the Warning ODU release is newer than RADWIN <local_site_name> site. Manager release. Wizards are not available. RADWIN Manager will be used just for monitoring. Upgrade the RADWIN Manager. Newer Version identified at the Warning <remote_site_name> site. Newer Version Identified! Warning 8.6 Active Alarms...
Page 118 Other Diagnostic Aids Chapter 8 Current Active Alarms may be saved to a file. The list displayed will not be updated unless you click Refresh. 8.7 Other Diagnostic Aids 8.7.1 Link Budget Calculator The Link Budget Calculator is part of the RADWIN Manager software and is found in the Help menu. This useful utility enables you to calculate the expected performance of the wireless link and the possible configurations for a specific link range including antenna size, cable loss and climate conditions. For full details, see Link Budget Calculator.  To run the Link Budget Calculator from the Windows Start Menu: • Go to Start | Programs | RADWIN Manager | Link Budget Calculator 8.7.2 Online Help Online help can be accessed from the Help menu on the main window of the RADWIN Manager. Using most common Web browsers, it may also be run going to Start | Programs | RADWIN Manager | User Manual RADWIN 5000 8.7.3 Customer Service Customer support for this product can be obtained from the local VAR, Integrator or distributor from whom it was purchased. For further information, please contact the RADWIN distributor nearest to you or one of RADWIN's offices worldwide. RADWIN 2000 D+ User Manual Release 3.6.00 8‐12...
Page 119 Part 3: Site Synchronization Release 3.6.00...
Page 120 Chapter 9: Hub Site Synchronization 9.1 What is Hub Site Synchronization (HSS) When several radios are collocated at a common hub site, interference may occur from one unit to another. RADWIN ODUs support the collocation of more than two units at a central site. Like any other RF deployment, the wireless operation is highly dependent on factors such as available frequencies, the physical spacing between radios, other third party interfering radios, and whether other RADWIN radios are installed. HSS does not eliminate the need for careful RF planning to ensure the design will work as planned. See Site Survey for information on installation site survey. Note 9.2 RADWIN HSS The RADWIN HSS method uses carries pulses sent to each ODU, which synchronize their transmission with each other. The pulse synchronization ensures that transmission occurs at the same time for all collocated units. This also results in all of the hub site units receiving data at the same time, eliminating the possibility of interference that could result if some units transmit while other units at the same location receive. Figure 9‐1 illustrates interference caused by non‐synchronized collocated units. RADWIN 2000 D+ User Manual Release 3.6.00 9‐1...
Page 121: Figure 9-1 Interference Caused
RADWIN HSS Chapter 9 Figure 9‐1: Interference caused by collocated units Adding HSS removes interference as shown in the next two figures: Figure 9‐2: Collocated units using Hub Site Synchronization (1) Figure 9‐3: Collocated units using Hub Site Synchronization (2) The units are connected to each other with HSS cables and HSS Distribution Units. One of the radios in the site is defined as HSS Master and generates synchronization pulses. The other collocated radios in the site ‐ the HSS Clients, are connected to the HSS Master and synchronize their transmission to the pulses. An HSS Client can be configured to work in one of two modes: RADWIN 2000 D+ User Manual Release 3.6.00 9‐2...
Page 122 RADWIN HSS Chapter 9 • HSS Client‐Continue Transmission (HSC‐CT): If the unit loses synchronization with the HSS Master, the link remains active. However, without synchronization pulses, it is pos‐ sible that this unit will cause interference. • HSS Client‐Disable Transmission (HSC‐DT): If the unit loses synchronization with the HSS Master, the link is dropped until the synchronization pulses resume. This setting prevents the unit from causing interference. The remote ODUs that are not located at the hub site, are called Independent Units (INU). RADWIN offers two types of HSS: » Serial HSS The RADWIN Serial Hub Site Synchronization (SHSS) method uses a cable connected from the master ODU to all collocated ODUs; this cable carries pulses sent to each ODU, which synchronize their transmission with each other. SHSS is covered in Serial Hub Site Synchronization. » Ethernet HSS The Ethernet HSS (HSSoE) method requires Layer 2 Ethernet connectivity between collocated ODUs. It has two requirements: • Collocated ODUs providing Ethernet services only, should be connected to an IDU‐H instead of regular PoE devices. Other simple switches may work with degraded per‐ formance. They are not recommended and problems arising from their use will not be eligible for any kind of support. • Collocated ODUs providing E1/T1 services should use an IDU‐C or IDU‐E and then be connected to an IDU‐H functioning as a switch. One of the LAN ports on the IDU‐C or IDU‐E is connected to any of the six IDU‐H PoE ports or the two LAN ports. (This is possible because the IDU‐C or IDU‐E LAN cable only uses four pins for data; the power pins are not used so there is no risk of damage to them.) In this way, up to eight such ODUs may be collocated. You may only use one IDU‐H. That is, they may not be cascaded. Note If you are using an IDU‐C0 (GbE) it must be connected to the IDU‐H LAN port only. Connecting it to the PoE ports will damage the unit and in any event, it will not work. Caution RADWIN 2000 D+ User Manual...
Page 123: Figure 9-4 Radio Framep
HSS Concepts: Radio Frame Pattern (RFP) Chapter 9 9.3 HSS Concepts: Radio Frame Pattern (RFP) A Radio Frame Pattern (RFP) is the cycle duration of transmit and receive of the air‐frame. 9.3.1 Without HSS When selecting TDM or Ethernet services, the system automatically and transparently chooses the optimal RFP. When TDM and Ethernet services are configured, the RFP is optimized for TDM. 9.3.2 RFP and HSS When HSS is used, the RFP for the collocated radios must be selected manually. RADWIN 2000 uses the Time Division Duplex (TDD) mechanism. Under HSS, TDD enables synchronization of transmission for the collocated units as shown in Figure 9‐4: Figure 9‐4: Radio Frame Pattern Two RFP types (labelled B and E) are available. Under HSS the RFP must be configured by the user depending on the type of the radio products, services and channel bandwidth in accordance with Table 9‐2. The table describe the efficiency of the air interface according to the RFP type, services and channel bandwidth. The tables may also be viewed in the RADWIN Manager and in the Link Budget Calculator. The efficiency of the air interface will vary according to the product used. Table 9‐1: Radio Frame Pattern Table ‐ RADWIN 5000, RADWIN 2000 D+ RFP 5/10/20/40 MHz Ethernet Best fit Table 9‐2: Radio Frame Pattern Table ‐ RADWIN 2000 RFP 40 MHz 20 MHz 10 MHz 5 MHz Ethernet TDM Ethernet TDM Ethernet TDM Ethernet Available Available Available Available Available Available Best fit...
Page 124: Table 9-3 Legend For Radiof
RFP: General Radio Frame Pattern Chapter 9 Table 9‐3: Legend for Radio Frame Pattern Tables Item Description Best fit Optimal RFP choice for TDM and Ethernet services Available Available RFP for TDM and Ethernet services, but not optima Service unavailable Select the RFP that gives you the Best Fit or Available for required system services and select the channel bandwidth accordingly. The RFP must be the same for each link within the collocated system. Note 9.3.3 RFP: General Radio Frame Pattern When setting the RPF, the following considerations should be borne in mind: • When synchronizing RADWIN 2000 D+ or RADWIN 5000 units you must use RFP E • When synchronizing RADWIN 2000 D+ or RADWIN 5000 with RADWIN 2000 or Airmux‐ 200 units you must use RFP E • RFP influences capacity and latency. • Using the Link Budget Calculator, you can see the effect of the RFP on the Ethernet throughput. 9.4 Which Type of HSS to Use You may use both forms of HSS with an RT‐A(HBS). There are however some limitations: • If you collocate an RT‐A(HBS) to both a unit supporting SHSS and HSSoE, the RT‐A(HBS) must always be HSM • If you collocate with a GSU, you can only use HSSoE and the GSU mast be HSM. RADWIN 2000 D+ User Manual Release 3.6.00 9‐5...
Page 125 Chapter 10: Serial Hub Site Synchronization 10.1 RADWIN Serial HSS The RADWIN Serial Hub Site Synchronization (SHSS) method uses a CAT 5e cable connected from the master ODU to all collocated ODUs; this cable carries pulses sent to each ODU, which synchronize their transmission with each other. Since the SHSS unit is still shown in the RADWIN Catalog as an “HSS unit”, in the remainder of this chapter we will continue with this convention on the clear understanding that we are dealing only with SHSS. 10.2 Hardware Installation 10.2.1 Connecting an HSS Unit A single HSS unit supports up to ten collocated ODUs. In addition to each unit being connected to its IDU or PoE device, the collocated unit has an additional cable that is connected to the HSS Unit. The HSS Unit is a compact, weatherproof (IP67) connector box that is installed on the same mast as the ODUs. All collocated units connect to this box using CAT‐5e cable. Cables in prepared lengths are available for purchase. The HSS unit is supplied with ten protective covers; any port not in use must be closed with a protective cover. RADWIN 2000 D+ User Manual Release 3.6.00 10‐1...
Page 126 Connecting an HSS Unit Chapter 10 Figure 10‐1: HSS Interconnection Unit • For a single HSS unit, ensure that the collocated units are connected in sequence from SYNC 1. If an ODU is removed from the hub site, then all remaining ODUs must be reconnected to maintain the connectivity. • You may cascade (daisy‐chain) two or more HSS Units with an HSS Note cable. The method is described in detail below.  To connect an ODU to an HSS unit: 1. Unscrew the protective cover from the port marked SYNC 1. 2. Connect the RJ‐45 connector from one end of the prepared CAT‐5e cable to SYNC 1. 3. Connect the other end of the CAT‐5e cable to the ODU connector labeled SYNC. 4. Tighten the protective seal that is on the prepared cable over the RJ‐45 connector. 5. Repeat for all ODUs that are to be collocated at the hub site. The next ODU to be connected is inserted in SYNC 1, SYNC 2, followed by SYNC 3 and so on. RADWIN 2000 D+ User Manual Release 3.6.00 10‐2...
Page 127: Figure 10-3 Hss Sync Signal
Using a Single HSS Unit Chapter 10 10.2.2 Using a Single HSS Unit Figure 10‐2: HSS Wiring schematic The wiring, as shown in Figure 10‐2 is self explanatory. The Sync signal path is less self evident. If we set ODU 1 (on SYNC 1) to HSS Master, then the Sync signal path is as shown in Figure 10‐3. The signal travels from ODU 1 to SYNC 1, from SYNC 1 to SYNC 2, from SYNC 2 to ODU 2 and back again. The back and forth paths repeat for the second to fourth ODU, from left to right. The signal exits the HSS unit at SYNC 5 and terminates in ODU 5. The choice of the ODU on SYNC 1 as HSS master is not mandatory, but is good practice. If for example we were to use ODU 3 as HSS master, the Sync signal path would be ODU 3 to SYNC 3, then left and right to SYNC 2 and SYNC 4. It would then propagate to ODUs 2 and 4, terminating at both ODUs 1 and 5. Figure 10‐3: HSS sync signal path with ODU 1 as HSS Master 10.2.3 Using More than One HSS Unit In a large collocation site, several HSS units may be cascaded (daisy‐chained) subject to the following conditions: RADWIN 2000 D+ User Manual Release 3.6.00 10‐3...
Page 128: Figure 10-4 Cascading Two
Using More than One HSS Unit Chapter 10 Condition 1: Cabling Sequence 1. Up to nine ODUs may be connected to the first HSS unit using HSS ports SYNC 1, SYNC 2, SYNC 3,... up to SYNC 9 in order without leaving empty ports. 2. The next available SYNC port of the first HSS unit should be connected to SYNC 10 of the second HSS unit as shown in Figure 10‐4. In the illustration, the next available port on the first HSS unit is SYNC 6. 3. The second HSS unit may be filled out with up to nine more ODUs in reverse order. That is, connect SYNC 9, SYNC 8, SYNC 7... as shown in Figure 10‐4. Figure 10‐4: Cascading two HSS units 4. To add a a further HSS unit: Connect the next available SYNC port from the second HSS unit in descending order (SYNC 5 in Figure 10‐4) to SYNC 1 of the third HSS unit. ODUs are connected to the third HSS unit from SYNC 2 as shown in Figure 10‐5, in ascending order: Figure 10‐5: Cascading three HSS units RADWIN 2000 D+ User Manual Release 3.6.00 10‐4...
Page 129 Lmn denote the length of the ODU‐HSS unit cable at SYNC n on HSS unit m Hm be the length of the cable joining HSS unit m to HSS unit m+1 One HSS unit with five collocated ODUs    PathLength Two cascaded HSS units as shown in Figure 10‐4    PathLength     Three cascaded HSS units as shown in Figure 10‐5    PathLength         10.3 ODU/HSS Unit Connection Pinout See Table B‐3. 10.4 Sector Configuration and HSS The Hub Site Synchronization Settings dialog box appears in the HBS Site Configuration window. RADWIN 2000 D+ User Manual Release 3.6.00 10‐5...
Page 130 Sector Configuration and HSS Chapter 10 Figure 10‐6: HSS Settings window If you click the Enabled box and choose Serial or Serial and Ethernet: The central display (with Operational state opened) will look like this: RADWIN 2000 D+ User Manual Release 3.6.00 10‐6...
Page 131: Figure 10-7 Setting Hbs As
Sync Status Messages and Color Codes Chapter 10 Figure 10‐7: Setting HBS as HSM or HSC Continue Tx means that the HBS as a client to continue to work if there is no HSM pulse. If you select Hub Sync Master and click Apply, the Configuration display changes: Figure 10‐8: HBS as HSM Setting up the HBS as a client is carried out in a similar manner. 10.5 Sync Status Messages and Color Codes The possible External Pulses conditions are shown in the following table: RADWIN 2000 D+ User Manual Release 3.6.00 10‐7...
Page 132: Table 10-1 External Pulses
Sync Status Messages and Color Codes Chapter 10 Table 10‐1: External Pulse Status Color HSS Sync Status Meaning code ODU is HSM and generates the sync pulse Generating ODU is HSC and detects the sync pulse Green Detected ODU is independent Not detected Generating and HSM, but other HSM present detected Generating and RADWIN 2000 D+ or RADWIN 5000 is HSM, but detects a Orange Improperly Airmux‐200 or RRADWIN 2000 HSM signal that is not RFP E Detected HSC but no HSM present Not detected HSC but HSM pulse doesn’t fit the HSC as configured. Occurs Improperly only for RADWIN 2000 D+ and RADWIN 5000, which stop detected transmitting. RADWIN 2000 D+ User Manual Release 3.6.00 10‐8...
Page 133 Chapter 11: Hub Site Synchronization over Ethernet 11.1 RADWIN Ethernet HSS 11.1.1 Ethernet HSS Requirements The RADWIN Ethernet Hub Site Synchronization (HSSoE) method provides intra‐site synchronization without the need for external cables or an HSS unit. Sync signals are exchanged between collocated radios over the regular Ethernet connection. The Ethernet HSS (HSSoE) method requires Layer 2 Ethernet connectivity between collocated ODUs. It has two requirements: • Collocated ODUs providing Ethernet services only, should be connected to an IDU‐H instead of regular PoE devices. Other simple switches may work with degraded per‐ formance. They are not recommended and problems arising from their use will not be eligible for any kind of support. • Collocated RADWIN 2000 class ODUs providing E1/T1 services should use an IDU‐C or IDU‐E and then be connected to an IDU‐H functioning as a switch. One of the LAN ports on the IDU‐C or IDU‐E is connected to any of the six IDU‐H PoE ports or the two LAN ports. (This is possible because the IDU‐C or IDU‐E LAN cable only uses four pins for data; the power pins are not used so there is no risk of damage to them.) In this way, up to eight such ODUs may be collocated. You may only use one IDU‐H. That is, they may not be cascaded. Note If you are using an IDU‐C0 (GbE) it must be connected to the IDU‐H LAN port only. Connecting it to the P0E ports will damage the unit and in any event, it will not work. Caution RADWIN 2000 D+ User Manual Release 3.6.00 11‐1...
Page 134 HSSoE Concepts Chapter 11 VLAN Tagging should not use the VLAN ID used by HSSoE and vice versa. Caution 11.1.2 HSSoE Concepts ODUs For HSSoE purposes, an ODU is any RADWIN radio supporting it. Currently, these include RADWIN 5000, RADWIN 2000 D+ RT‐A(HBS) and RADWIN Jetb ase station units. Sync Frames Sync frames are exchanged between collocated ODUs using Layer‐2 broadcasting. Domain To prevent network flooding, each group of collocated ODUs is configured with an internal “domain name”. The default name must be changed to prevent sync frames being received over the LAN by another ODU, which could be then mistakenly configured as a client of an HSM at the wrong location. Discovery Discovery by the HSM and HSCs is provided using the following choice of filters: RADWIN 2000 D+ User Manual Release 3.6.00 11‐2...
Page 135 HSSoE Concepts Chapter 11 Using discovery at the HSM, you can select only those HSCs in the HSM’s domain; when configuring a new HSC you may use discovery to pick the correct HSM. VLAN VLAN is used to separate sync frames from traffic so as to give sync frames highest priority. If you have collocated ODUs running close to full capacity, failure to do so, would result in excessive jitter and dropped traffic frames. By default, the VLAN ID 1997 and priority 7 are reserved for HSS. You may change the VLAN ID but not the priority. RADWIN 2000 D+ User Manual Release 3.6.00 11‐3...
Page 136 Installing Collocated HSSoE ODUs Chapter 11 11.2 Installing Collocated HSSoE ODUs 11.2.1 Ethernet Services Only Use an IDU‐H for the collocated ODUs instead of separate PoE devices. The IDU‐H has two LAN ports, one of which will be connected to a switch. 11.2.2 Ethernet and TDM Services For RADWIN 2000 class ODUs: To attain Layer 2 connectivity for up to two such ODUs, you should connect one of the two the IDU‐C (or IDU‐E) LAN ports to the IDU‐H LAN ports. You may use the second IDU‐C (or IDU‐E) LAN port to connect to a switch. As pointed out earlier, you may only collocate two ODUs in this way. 11.3 Link Configuration and HSSoE 11.3.1 Setup for Illustration We will show how to set up our demonstration link as HSM and HSC in turn. (The second collocated link is a similar unit, the setup details of which, need not concern us). 11.3.2 Configuring the RT‐A(HBS) as an HSM  To configure the RT‐A(HBS) as EHSS Master: 1. Log on to the RT‐A(HBS). 2. Open the Configure | Hub Site Sync tab. RADWIN 2000 D+ User Manual Release 3.6.00 11‐4...
Page 137 Configuring the RT‐A(HBS) as an HSM Chapter 11 Figure 11‐1: HSS Settings window 3. Check the Enabled box. The grayed out bottom part of the window in Figure 11‐1 is enabled. RADWIN 2000 D+ User Manual Release 3.6.00 11‐5...
Page 138: Figure 11-2 Extended Protocol
Configuring the RT‐A(HBS) as an HSM Chapter 11 Figure 11‐2: Extended Protocol Parameters for HSSoE 4. Leave the Operation state as is at Hub Sync Master. Here is the full range of options: Later, we will need one of the client options for the collocated site. 5. The Protocol should be left as is at Ethernet. (For the moment, there are no other options.) 6. The Domain is the HSS domain and refers to the current hub site. It is used to distinguish between hub sites to prevent inadvertent collocation to an over‐the‐air unit. We set it as shown, to PM_Lab. 7. Leave the VLAN ID as is at 1977 unless there is some reason to change it. 8. The Discovery options are as follows: Figure 11‐3: HSS discovery filters 9. Choose All. In our case it will show the HBS as HSM and the collocated ODU as HSC: RADWIN 2000 D+ User Manual Release 3.6.00 11‐6...
Page 139 Configuring the RT‐A(HBS) as an HSM Chapter 11 You can save the results to a text file or change the display type from the Discovery window tool bar: The choices are the same as for Figure 11‐3. 10. Use the OK or Apply buttons to commit your changes. Here is the outcome: RADWIN 2000 D+ User Manual Release 3.6.00 11‐7...
Page 140: Figure 11-4 Configuration
Configuring the RT‐A(HBS) as an HSM Chapter 11 Figure 11‐4: Configuration for HSM 11. Click the Details button. A table of other Ethernet HSMs with the same domain is displayed: This is a mistake: There should not be a second HSM in this domain. Change it to be HSC and the display is updated: RADWIN 2000 D+ User Manual Release 3.6.00 11‐8...
Page 141 Configuring the Master ODU as an HSC Chapter 11 Notice additional HSC at IP address 10.104.3.2: It is collocated to the foregoing radios using an HSS unit connected to theHBS. 11.3.3 Configuring the Master ODU as an HSC We switch HSS roles between our HBS and the collocated ODU.  To configure the Master ODU as EHSS Master: 1. Follow steps 1 to 4 for configuring the HSM. 2. At step 5 for HSM, choose Hub Sync Client ‐ Continue Tx. Here is the outcome: RADWIN 2000 D+ User Manual Release 3.6.00 11‐9...
Page 142 Configuring the Master ODU as an HSC Chapter 11 Note that the IP address of the HSM is displayed for confirmation. RADWIN 2000 D+ User Manual Release 3.6.00 11‐10...
Page 143: Table 11-1 External Pulses
Sync Status Messages and Color Codes Chapter 11 11.4 Sync Status Messages and Color Codes The possible External Pulses conditions are shown in the following table: Table 11‐1: External Pulse Status Color HSS Sync Status Meaning code ODU is HSM and generates the sync pulse Generating ODU is HSC and detects the sync pulse Green Detected ODU is independent Not detected Generating and HSM, but other HSM present detected Generating and RADWIN 2000 D+ or RADWIN 5000 is HSM, but detects a Orange Improperly Airmux‐200 or RADWIN 2000 HSM signal that is not RFP E Detected HSC but no HSM present Not detected HSC but HSM pulse doesn’t fit the HSC as configured. Occurs Improperly only for RADWIN 2000 D+ and RADWIN 5000, which stop detected transmitting. RADWIN 2000 D+ User Manual Release 3.6.00 11‐11...
Page 144 Chapter 12: Using the GSU 12.1 What is it for The GPS‐based synchronization unit (GSU) is designed to handle inter‐site interferences under large‐scale deployment scenarios. The GSU is an outdoor unit consisting of a small size enclosure, a GPS antenna and a PoE device. It may be operated through an HSS unit or over Ethernet. For use over Ethernet, the GSU requires Layer 2 connectivity to the multiple Hub‐Sites that it is required to synchronize. It synchronizes the transmission timing of these Hub‐Sites to the same clock source thus eliminating mutual interference. Typically, an IDU‐H is used. RADWIN 2000 D+ User Manual Release 3.6.00 12‐1...
Page 145: Figure 12-1 General Gsu
GSU Functionality Figure 12‐1: General GSU configuration using both Ethernet and an HSS unit 12.2 GSU Functionality The GSU receives a synchronization signal from the GPS once per second. It distributes a RADWIN proprietary synchronization signal to all other ODU units using a proprietary synchronization signal over Ethernet. When the GSU doesn’t receive a synchronization signal from the GPS for 30 seconds, it moves automatically to Self‐Generation mode until the GPS recovers. 12.3 GSU Kit Contents The GSU package includes: • 1 x GSU • 1 x GSU Mounting Kit • 1 x GPS Antenna • 1 x GPS Antenna Mounting Kit RADWIN 2000 D+ User Manual Release 3.6.00 12‐2...
Page 146 Commissioning and Installation • 1 x RF Cable, 1.5m • RADWIN Manager supplied either on CD or by electronic means 12.4 Commissioning and Installation 12.4.1 Preparing the GSU for Use At the depot, log on to the unit using Local Connection or IP address 10.0.0.120 to change its IP address from the default (10.0.0.120). The method is the same as is used for an HBS. In the example screen captures below, we use 10.104.20.1 with Subnet Mask 255.255.0.0 and Gateway 10.104.10.21. 12.4.2 GSU Installation The GSU looks like a small form factor ODU. Mounting the GSU follows the standard pattern. The GPS antenna is mounted outside on a wall or pole. 12.4.3 Configuring the GSU Getting Started To configure the GSU, you log on to it, exactly as in Getting Started with the RADWIN Manager. The GSU Main Window Here is the main window for GSU configuration: RADWIN 2000 D+ User Manual Release 3.6.00 12‐3...
Page 147: Figure 12-3 Gps Status Under
Configuring the GSU Figure 12‐2: GSU Main widow at startup The GPS satellite data is contained in the bottom left panel: Figure 12‐3: GPS status under normal use RADWIN 2000 D+ User Manual Release 3.6.00 12‐4...
Page 148 Configuring the GSU The Configuration Window Figure 12‐4: GSU Configuration window The main tabs of interest are Management, Hub Site Sync and GPS Sync. The Management tab is the same as the corresponding RT‐A(HBS) Management tab. If you set the IP and related addresses correctly, there should be little to change here (see Site Configuration). The other three tabs, Trap Destination, VLAN and Protocol also have the same function here. In the Hub Site Sync window, ensure that it is enabled and the Domain item set to be the same as the corresponding item in Figure 11‐4. RADWIN 2000 D+ User Manual Release 3.6.00 12‐5...
Page 149 Configuring the GSU The GPS Sync tab allows you to choose an RFP (see HSS Concepts: Radio Frame Pattern (RFP)) and set the Transmission Ratio for the sector. Its value is application dependent: (The reason that this is done at the GSU is that Transmission Ratio must always be determined at the unit generating the sync pulses.) For administrative purposes, you can view the Inventory: RADWIN 2000 D+ User Manual Release 3.6.00 12‐6...
Page 150 Configuring the GSU RADWIN 2000 D+ User Manual Release 3.6.00 12‐7...
Page 151 Part 4: Advanced Installation Topics Release 3.6.00...
Page 152 Chapter 13: Software Upgrade What is the Software Upgrade Utility? The RADWIN Manager provides a Software Upgrade Utility (SWU) to upgrade the software (firmware) of installed ODUs in a network. The update files may be located anywhere accessible by the operator. The SWU provides for: • Prior backup of the current files prior to upgrade • Upgrade from a list • Delayed upgrade • Various ODU reset options The default location of the software files is in the installation area, and can be used to restore factory defaults. Upgrading an Installed Link  To upgrade software for a link: 1. In the RADWIN Manager, click the Tools | Software Upgrade button.The following detached window appears: RADWIN 2000 D+ User Manual Release 3.6.00 13‐1...
Page 153: Figure 13-1 Software Upgrade
Upgrading an Installed Link Chapter 13 Figure 13‐1: Software Upgrade Utility ‐ Main window The default sites shown in the Software Upgrade list panel belong to the currently installed sector. The list may be empty if you are running the RADWIN Manager “offline”. 2. The Software upgrade list title bar has three buttons on the right hand side. Figure 13‐2: Add / Remove site buttons The left button opens up a Windows file dialog to locate a list of locations to update. The list has the following format: <IP address>,<Read‐Only community>,<Read‐Write community> For example: 10.104.3.2,netman 10.104.3.4,netman The list should include RT‐A(HBS)s and RT‐B(HSU)s able to accept the same upgrade. Non‐upgradable items will result in an error message. Contact Customer Service about upgrading them. The center button allows you to add a single site: RADWIN 2000 D+ User Manual Release 3.6.00 13‐2...
Page 154: Figure 13-3 Adding Asingle
Upgrading an Installed Link Chapter 13 Figure 13‐3: Adding a single site for upgrade Enter the IP address of the site and the Read‐Write Community (Default: netman). If you area SNMPv3 user, add your User Name and Password and then click OK. The site will appear in the Software Upgrade list box. Items from the list can be cleared by selecting them and then using the right button. The right button in Figure 13‐3, may be ruse to remove one or more selected sites. 3. Having created an update list, click Upgrade Package to chose the relevant files. The default files are located in the SWU subdirectory in the RADWIN Manager installation area. You may see one or more of the following SWU files: Table 13‐1: SWU Files by product File name Product SWU_2k.swu RADWIN 2000 SWU_5k.swu RADWIN 5000 For RADWIN 2000 D+, always choose SWU_5k.swu (Not the 2k package). 4. To back up your existing system, check Backup device software check‐box. Then click the button for a standard file dialog. The default location is the My Documents directory on the managing computer or the last backup directory you used. The backup here is the same as that in Backup and Restore, and serves the same purpose. It provides a fallback if the upgrade proves problematic. Note 5. In addition to the previous step, you may opt to perform a delayed upgrade. Check the Delayed Upgrade box, and enter the date and time for the delayed upgrade. A Calendar dialog box opens: RADWIN 2000 D+ User Manual Release 3.6.00 13‐3...
Page 155 Upgrading an Installed Link Chapter 13 6. The radio buttons on the right determines how your ODUs should be reset. Bear in mind that on the one hand, a reset involves a service interruption, but on the other hand, the software upgrade will not become effective until after the reset is carried out. Here is a typical delayed upgrade scenario: 7. Click Start Upgrade to commence the process. For an immediate upgrade you will be able to observe the upgrade progress from the green progress bars: RADWIN 2000 D+ User Manual Release 3.6.00 13‐4...
Page 156: Figure 13-4 Software Upgrade
Bulk Software Backup Chapter 13 Figure 13‐4: Software upgrade in progress ‐ Note the stop button Figure 13‐5: Software upgrade completed successfully 8. Use the title bar exit button to dismiss the Software upgrade window.. If any sites fail to update, a warning notice will be displayed. If one or more sites of a sector update fails, you should correct the problem and update the failed sites as soon as possible. If you do not, following the next reset of the updated sites, you could experience a link software Caution mismatch which may affect service. Bulk Software Backup You can back up the sector software independently of Software Upgrade using the main button menu. See Software Backup and Restore. RADWIN 2000 D+ User Manual Release 3.6.00 13‐5...
Page 157 Chapter 14: Software Backup and Restore 14.1 Backup and Restore Facilities You can backup the ODU software fora complete link (Bulk Backup) or a single site. The Restore facility is selective: You may restore backed up ODUs one at a time. The restore may be the full software or just the configuration settings. A backup (full or configuration only) may be restored to another ODU provided that the product IDs and revision levels of the source and target ODUs are identical. They are shown in the ODU Inventory window. Note 14.2 Bulk Software Backup  To backup a link or sector: 1. Go to Tools | Bulk Backup: The following detached window appears: RADWIN 2000 D+ User Manual Release 3.6.00 14‐1...
Page 158: Figure 14-1 Bulk Backup Setup
Bulk Software Backup Chapter 14 Figure 14‐1: Bulk Backup setup window The default sites shown in the Bulk Backup list panel belong to the currently installed link. The list may be empty if you are running the RADWIN Manager “offline”. 2. The Bulk Backup list title bar has three buttons on the right hand side. Figure 14‐2: Add / Remove site buttons The left button opens up a Windows file dialog to locate a list of locations to backup. The list has the following format for SNMPv1: <IP address>,<Read‐Only community>,<Read‐Write community> For SNMPv3 it is: <IP address>,<Dummy>,<User_type><Password> For example: 10.104.3.2,netman,admin,netwireless 10.104.3.4,netman,admin,netwireless A PtMP list will contain the HBS and registered HSUs. The center button allows you to add a single site: RADWIN 2000 D+ User Manual Release 3.6.00 14‐2...
Page 159: Figure 14-3 Adding Asingle
Bulk Software Backup Chapter 14 Figure 14‐3: Adding a single site for backup Enter the IP address of the site, the Read‐Write Community (Default: netman) and then click OK. The site will appear in the Software Upgrade list box. Items from the list can be cleared by selecting them and then using the right button. The right button in Figure 14‐3, may be ruse to remove one or more selected sites. 3. You may choose the SNMP version but probably it should be best left at your log‐on setting. 4. Click the Start Backup button. Progress bars indicate backup status. The success or failure of the backup is displayed on completion: Save configuration produces a text file in the format of the above example for backing up an installed link. The files produced by the above process are: 10.104.3.4_29.01.2015.backup 10.104.3.2_29.01.2015.backup BulkBackupConfig_2015_01_29.txt RADWIN 2000 D+ User Manual Release 3.6.00 14‐3...
Page 160 Site Backup Chapter 14 Notice that the files are date stamped. The first two files are binary. The last is the save‐ configuration text file: 10.104.3.2,netman,admin,netwireless 10.104.3.4,netman,admin,netwireless The backup files are identical in naming convention and format to those produced on a site‐ by‐site basis. 14.3 Site Backup A single site may be backed up directly from the Backup tab of the ODU Configuration window. Both of the Backup and Restore buttons open standard MS Windows file dialogs respectively to create and read a backup file. The file is stored using a proprietary binary format. The Restore button offers two extra options, Configuration Restore or Full Restore. Configuration Restore just restores configuration settings, whereas Full Restore reverts the ODU software to the backed up version. RADWIN 2000 D+ User Manual Release 3.6.00 14‐4...
Page 161 Chapter 15: VLAN Functionality 15.1 VLAN Tagging ‐ Overview 15.1.1 VLAN and Related Terminology Both the technical literature and the RADWIN Manager use the terms VLAN ID and VID interchangeably to denote a VLAN identification number. The VLAN implementation for RADWIN 2000 D+ is based on that of RADWIN 5000 so the latter ODU terminology is retained. Recall, that HBS always means the Master ODU and HSU always means the Slave ODU. 15.1.2 VLAN Background Information on the Web The standards defining VLAN Tagging are IEEE_802.1Q and extensions. For general background about VLAN see http://en.wikipedia.org/wiki/Virtual_LAN. Background information about Double Tagging also known as QinQ may be found here: http://en.wikipedia.org/wiki/802.1QinQ. 15.2 Scope of this Chapter This chapter describes how the components of a RADWIN 2000 D+ link deal with tagging and untagging. 15.3 Requirements It is assumed that you are familiar with VLAN usage and terminology. 15.4 VLAN Tagging VLAN tagging enables multiple bridged networks to transparently share the same physical network link without leakage of information between networks: RADWIN 2000 D+ User Manual Release 3.6.00 15‐1...
Page 162 QinQ (Double Tagging) for Service Providers Chapter 15 IEEE 802.1Q is used as the encapsulation protocol to implement this mechanism over Ethernet networks. 15.4.1 QinQ (Double Tagging) for Service Providers QinQ is useful for Service Providers, allowing them to use VLANs internally in their “transport network” while mixing Ethernet traffic from clients that are already VLAN‐tagged. The outer tag (representing the Provider VLAN) comes first, followed by the inner tag. In QinQ the EtherType = 0x9100. VLAN tags may be stacked three or more deep. When using this type of “Provider Tagging” you should keep the following in mind: • Under Provider Tagging, the system double‐tags egress frames towards the Provider’s network. The system adds a tag with a VLAN ID and EtherType = 0x9100 to all frames, as configured by the service provider (Provider VLAN ID). • The system always adds to each frame, tags with VLAN ID and EtherType = 0x9100. Therefore, • For a frame without a tag – the system will add a tag with VLAN ID and EtherType = 0x9100 so the frame will have one tag • For a frame with a VLAN tag – the system will add a tag with VLAN ID and EtherType = 0x9100 so the frame will be double‐tagged For a frame with a VLAN tag and a provider tag – the system will add a tag with VLAN ID and EtherType = 0x9100 so the frame will be triple‐tagged and so on. At the egress side, the RT‐B(HSU) removes the QinQ tag with EtherType = 0x9100 no matter what the value of its VLAN ID. 15.4.2 VLAN Untagging VLAN Untagging means the removal of a VLAN or a Provider tag. 15.4.3 Port Functionality In a RADWIN 2000 D+ link, all VLAN activity is configured and supported from the RT‐B(HSU). To this end, VLAN functionality is supported at the LAN port of the RT‐B(HSU). The RT‐B(HSU) LAN port can be configured to handle Ethernet frames at the ingress direction (where frames enter the RT‐B(HSU)) and at the egress direction (where frames exit the RT‐ B(HSU)). RADWIN 2000 D+ User Manual Release 3.6.00 15‐2...
Page 163: Table 15-1 Port Settings - I
Priority Code Point (PCP) which refers to the IEEE 802.1p priority. It indicates the frame priority level from 0 (lowest) to 7 (highest), which can be used to prioritize different classes of traffic (voice, video, data, etc). RADWIN 2000 D+ User Manual Release 3.6.00 15‐3...
Page 164: Table 15-2 Port Settings - E
VLAN Configuration Using the RADWIN Manager Chapter 15 Egress Direction Table 15‐2: Port settings ‐ Egress direction The port ‘does nothing’ with regard to VLANs ‐ outbound frames are left Transparent untouched. Port configured to untag user VLAD tags for all frames. Untag all Filter 15.5 VLAN Configuration Using the RADWIN Manager If you are not a VLAN expert, please be aware that incorrect VLAN configuration may cause havoc on your network. The facilities described below are offered as a service to enable you to get best value from your RADWIN 2000 D+ links and are provided “as is”. Under no circumstances Disclaimer does RADWIN accept responsibility for network system or financial damages arising from incorrect use of these VLAN facilities. 15.5.1 Management Traffic and Ethernet Service Separation You can define a VLAN ID for management traffic separation. You should configure the system to prevent conflicts as detailed below. When configured for the default operational mode, a “Provider port” will handle ingress traffic as follows: • Filters frames that are not tagged with the Provider VLAN ID • Removes the Provider double tag Therefore, if a port is configured for management traffic separation by VLAN and as ‘Provider port’, then the received management frames must be double tagged as follows: RADWIN 2000 D+ User Manual Release 3.6.00 15‐4...
Page 165 Configuration of VLAN Tagging for Ethernet Service Chapter 15 • The outer tag has to be the Provider’s tag (so the frame is not filtered) • The internal tag has to be management VLAN ID To avoid mix‐ups, best practice is to: • Separate the management and data ports • Define only a data port with Provider function 15.5.2 Configuration of VLAN Tagging for Ethernet Service  To set up an HSU for VLAN tagging: 1. Open Link Configuration | Ethernet and then click the VLAN Configuration button. In Disabled mode, Ethernet frames pass transparently over the radio links. 2. For Provider tagging, click the Provider Radio button: In Provider mode, Ethernet frames are tagged with the provider’s VLAN ID before they enter into the provider’s network/backbone. RADWIN 2000 D+ User Manual Release 3.6.00 15‐5...
Page 166 Configuration of VLAN Tagging for Ethernet Service Chapter 15 3. Enter a Provider VLAN ID and Priority. The VLAN ID must be in the range 2 to 4094. The VLAN Priority must be in the range 0 to 7. You may also change the TPID from the default as shown. This facility is provided to enable connection through legacy switches requiring it. Otherwise, there is no need to change the TPID. Note 4. Click OK to accept. 5. For user VLAN tagging, click the Tag Radio button: In Tag mode Ethernet frames are tagged or untagged to distinguish between differ‐ ent networks. 6. For completely transparent passage of tagged frames, there is nothing further to do. Table 15‐3 shows the possible settings for each combination of Ingress and Egress modes. RADWIN 2000 D+ User Manual Release 3.6.00 15‐6...
Page 167: Table 15-3 Further Vlan C
Transparent and are Untag VLAN IDs: forwarded untagged through. Untag the VLAN tag transparently of the selected VLAN IDs. Frames are Tag: not modified All frames with Allow up to 4 VIDs Allow up to 4 VIDs Enter a VID (1‐ and are VLAN tag are to be passed to be passed 4094) and forwarded untagged through through Priority (0‐7) transparently a. Frames with Provider Tag 9100 or 88A8 will be passed through transparently b. For frames with Provider Tag 8100, the filter will be applied to the outer tag c. For frames with Provider Tag 8100, the filter will be applied to the outer tag d. Frames with Provider Tag 8100 at egress will be stripped of the outer tag RADWIN 2000 D+ User Manual Release 3.6.00 15‐7...
Page 168: Table 16-1 Default Priorities
Chapter 16: Quality of Service 16.1 Prerequisites To use the facility you must be familiar with the use of VLAN (802.1p) or Diffserv. 16.2 QoS ‐ Overview QoS is a technique for prioritization of network traffic packets during congestion. RADWIN 2000 D+ links support two classification criteria, VLAN based or Diffserv based. You may choose which of them to use. Table 16‐1: Default priorities an d allocation by VLAN ID and Diffserv Priority Quality queue Diffserv VLAN 48‐63 6‐7 Real time Near real time (responsive 32‐47 4‐5 applications) 16‐31 2‐3 Controlled load 0‐15 0‐1 Best effort Based upon the classification criterion chosen, received packets will be mapped into one of four quality groups: Real time, Near real time, Controlled load and Best effort. You may partition the total link capacity across the four Quality queues. The default weights as percentages are shown in Table 16‐1. 16.3 Setting up the Link for QoS 16.3.1 Preparing for QoS Open Services Configuration and then click the QoS Configuration button. RADWIN 2000 D+ User Manual Release 3.6.00 16‐1...
Page 169: Figure 16-1 Q O S Configuration
Preparing for QoS Chapter 16 Figure 16‐1: QoS Configuration window QoS is disabled by default. You may choose between the VLAN (802.1p) and Diffserv methods. The default settings for Diffserv and VLAN are as shown in the next two figures: RADWIN 2000 D+ User Manual Release 3.6.00 16‐2...
Page 170 Assigning Queue Priorities Chapter 16 If you un‐check a queue, it will be disabled for the link. It will not prevent the Slave ODU from configuring it as “live”. The purpose behind this is to avoid the necessity of reconfiguring QoS for the Slave ODU, should the queue be reinstated. 16.3.2 Assigning Queue Priorities Four mechanisms are available to control queue performance: • Strict ‐ An over‐the‐air packet is loaded first with data from Real Tome queue (see Figure 16‐2), and then from the remaining queues in order. If there is too much data for the first queue, it will “starve” the lower queues and so on. • Weight ‐ One solution to such “starvation” is to weight input flow to the four queues. This could still lead to wasted resources. If in the example below, the actual traffic is all Near Real Time, only 20% will be allocated to Near real time and the rest will be held up. • Maximum Information Rate (MIR) ‐ This is a simple throttle mechanism, which suffers from a drawback similar to the previous case. • Time to Live (TTL) in ms ‐ This device is use to reduce re‐transmits of real time data (such as voice or viewed video). RADWIN 2000 D+ User Manual Release 3.6.00 16‐3...
Page 171: Figure 16-2 The Four Q Os
Assigning Queue Priorities Chapter 16  To configure queue priorities for uplink and downlink in turn: 1. For each queue, both downlink and uplink enter the required weight, MIR and TTL. The MIR and TTL may respectively be left Unlimited and Disabled in which case the system will use a “best effort” method. If you exceed 100% total weight, you will receive an error message. Figure 16‐2: The four QoS data queues You will be required to correct this before leaving the window other than by cancel‐ lation. If you are under‐booked, for example by setting a queue to zero, the unused weight will be distributed to the remaining queues. The effect of doing this will only become apparent under congestion. In particular, a queue set to zero weight will become nearly blocked under congestion with packets passing through on a best effort basis. 2. When you complete your entries, in the QoS Configuration window (Figure 16‐1), click OK to save them and continue. RADWIN 2000 D+ User Manual Release 3.6.00 16‐4...
Page 172 Chapter 17: False Radar Mitigation Facilities 17.1 Who needs it If you are using DFS frequency bands 5.3/5.4 GHz ETSI and 5.4/5.8GHz FCC you should use this facility. 17.2 DFS and False Radar Mitigation 17.2.1 About DFS Under DFS frequency bands, it must be ensured that radio links do not interfere with certain radar systems in the 5 GHz band. If radar is detected, the radio link should move automatically to a frequency that does not interfere with the detected radar. 17.2.2 What is False Radar Mitigation False Radar Mitigation capability is an advanced method to reduce or eliminate false radar detection and DFS triggering (“False positives”). False radar detection can be caused by other radios transmissions or external interference that can be interpreted as true radar. This option is active only in DFS frequency bands, 5.3/5.4 GHz FCC (HBS only) and 5.4/5.8GHz ETSI (HBS & HSU). In what follows false radar means any source of radar‐like signals which are not real radar. False Radar Mitigation has two components: 1. Reduction of false positive radar detection by reduction of the probability of detecting any kind of false radars, while allowing the system to detect real radar signals. 2. Elimination of detection of specific false radar types by blocking detection of false radars of a specific type. There are three types of radars: • Fixed: False radars with fixed pulse width having fixed repetition frequency RADWIN 2000 D+ User Manual Release 3.6.00 17‐1...
Page 173: Figure 17-1 False Radarm
Configuring False Radar Mitigation Chapter 17 • Variable: False radars with variable pulse width having variable repetition frequency • Staggered: False radars with variable repetition frequency within a burst period (Applies to 5.4 GHz ETSI only) 17.3 Configuring False Radar Mitigation The configuration method for the Master ODU (ETSI and FCC/IC) is the same as for the Slave ODU (ETSI only). We will demonstrate the Master ODU for a link using the 5.3 GHz FCC/IC band:  To configure False Radar Mitigation: 1. Log on to the Master ODU as Installer. 2. Enter the Configuration window and open the Advanced tab. Figure 17‐1: False Radar Mitigation 3. The DFS Frequency Status Table at the bottom of Figure 17‐1 shows the time, type and frequency of the last radars detected. This table should be used to select the RADWIN 2000 D+ User Manual Release 3.6.00 17‐2...
Page 174 FCC/IC Requirements Chapter 17 best option(s) to reduce or eliminate false radar detection without completely blocking out real radar detection. 4. Check the mitigation features to be used. 5. When you are satisfied with your configuration parameters, click OK to save them and dismiss the Configuration window. 17.4 FCC/IC Requirements The FCC requires that devices installed within 35 km of any Terminal Doppler Weather Radars (TDWR) location should be registered in the voluntary WISPA sponsored database.For convenience, we supply guidelines about the way this is done in FCC/IC DFS Considerations. RADWIN 2000 D+ User Manual Release 3.6.00 17‐3...
Page 175 Chapter 18: FCC/IC DFS Considerations 18.1 FCC 5.4GHz Device Registration The FCC requires that devices installed within 35 km of any TDWR location should be registered in the voluntary WISPA sponsored database. The FCC has published a TDWR Location Information table that lists the exact location of all TDWR towers (see Table 18‐1 at the end of the chapter). 1. When installing a 5.4 GHz device define your exact location (latitude and longitude) 2. Use the TDWR Location Information table to determine if the distance between the device and any TDWR tower is less than 35 km. 3. If the distance is less than 35 km then register the device in the voluntary WISPA sponsored database (following section) 4. Disable the frequencies between 5570 – 5680 MHz from the available channels list. 5. The frequency range between 5.600 to 5.650 GHz is not included in the available channels list. 18.2 Registering the Device  To register a device: 1. Enter the website http://www.spectrumbridge.com/udia/home.aspx and follow the instructions. At your first entry into the site, you will be required to register as a user: RADWIN 2000 D+ User Manual Release 3.6.00 18‐1...
Page 176 Registering the Device Chapter 18 2. Click the User Registration button to enter the registration page. RADWIN 2000 D+ User Manual Release 3.6.00 18‐2...
Page 177 Registering the Device Chapter 18 3. Fill in the registration page and click Register. 4. To complete device registration enter the Register Device tab as shown: RADWIN 2000 D+ User Manual Release 3.6.00 18‐3...
Page 178 Registering the Device Chapter 18 You are offered this: 5. Fill in the required information in the preceding web page and click the Register Device button. RADWIN 2000 D+ User Manual Release 3.6.00 18‐4...
Page 179: Table 18-1 Latitude And Table 20-1 Spectrum Viewa
371 113 NC CHARLOTTE W 080 53 06 N 35 20 14 5608 MHz 757 113 NC RALEIGH DURHAM W 078 41 50 N 36 00 07 5647 MHz 400 113 NJ WOODBRIDGE W 074 16 13 N 40 35 37 5620 MHz 19 113 NJ PENNSAUKEN W 075 04 12 N 39 56 57 5610 MHz 39 113 NV LAS VEGAS W 115 00 26 N 36 08 37 5645 MHz 1995 64 RADWIN 2000 D+ User Manual Release 3.6.00 18‐5...
Page 180 36 80 TX DALLAS LOVE FIELD W 096 58 06 N 32 55 33 5608 MHz 541 80 TX LEWISVILLE DFW W 096 55 05 N 33 03 53 5640 MHz 554 31 UT SALT LAKE CITY W 111 55 47 N 40 58 02 5610 MHz 4219 80 VA LEESBURG W 077 31 46 N 39 05 02 5605 MHz 361 113 WI MILWAUKEE W 088 02 47 N 42 49 10 5603 MHz 820 113 RADWIN 2000 D+ User Manual Release 3.6.00 18‐6...
Page 181 Part 5: Field Installation Topics Release 3.6.00...
Page 182 Chapter 19: Link Budget Calculator 19.1 Overview The Link Budget Calculator is a utility for calculating the expected performance of the RADWIN 2000 D+ wireless link and the possible configurations for a specific link range. The utility allows you to calculate the expected RSS of the link, and find the type of services and their effective throughput as a function of the link range and deployment conditions. 19.1.1 User Input You are required to enter or choose the following parameters. Depending on the product, some of the parameters have a default value that cannot be changed. • Band, which determines frequency and regulation • ODU series used • Channel Bandwidth • Tx Power (maximum Tx power per modulation is validated) • Antenna Type (currently dual; cannot be changed for ODU with integrated antenna) • Antenna Gain per site (cannot be changed for integrated antenna) • Cable Loss per site (cannot be changed for integrated antenna) • Fade Margin (currently 6dB) • Rate • Required Range and climate type 19.1.2 Link Budget Calculator Internal Data For each product (or Regulation and Band) the calculator stores the following data required for link budget calculations: • Maximum Transmit power (per modulation) • Receiver Sensitivity (per modulation) for Ethernet service • Maximum linear input power (used to calculate minimum distance) • Antenna gain and cable loss for ODU with integrated antenna •...
Page 183      32.45 PathLoss frequency RequiredRange – ExpectedFadeM ExpectedRSS Sensitivity where Sensitivity is dependent on air‐rate. 19.2.3 Min and Max Range  MinRange is the shortest range for which ExpectedRSS MaxInputPower per air‐rate. MaxRange (with Adaptive checked) is the largest range for which  ExpectedRSS Sensitivity , at the highest air‐rate for which this relationship is true. In a link with adaptive rate this will be the actual behavior. MaxRange (for a given air‐rate) is the largest range for which  ExpectedRSS Sensitivity RequiredFadeM 19.2.4 Service The Ethernet and configured TDM trunks throughput is calculated according to internal product algorithms. 19.2.5 Availability The Service Availability calculation is based on the Vigants Barnett method which predicts the downtime probability based on a climate factor (C factor). RADWIN 2000 D+ User Manual Release 3.6.00 19‐2...
Page 184  ---------------------------------- - ---------------------------------------- - frequency  ------------------------------------------------------------------------------------------- - which gives ExpectedRange ExpectedRange ---------------------------------------- - ---------------------------------------- - ExpectedRange  0.52 ---------------------------------------- - simplifying to frequency ExpectedRange ---------------------------------------- - – The boresight clearance height is calculated as: Mean Mean 6367.4425Km where Mean 19.3 About the Fresnel Zone The Fresnel zone (pronounced "frA‐nel", with a silent “s”) is an elliptically shaped conical zone of electromagnetic energy that propagates from the transmitting antenna to the receiving antenna. It is always widest in the middle of the path between the two antennas. RADWIN 2000 D+ User Manual Release 3.6.00 19‐3...
Page 185: Figure 19-1 Fresnel Zone
About the Fresnel Zone Chapter 19 Figure 19‐1: Fresnel zone Fresnel loss is the path loss occurring from multi‐path reflections from reflective surfaces such as water, and intervening obstacles such as buildings or mountain peaks within the Fresnel zone. Radio links should be designed to accommodate obstructions and atmospheric conditions, weather conditions, large bodies of water, and other reflectors and absorbers of electromagnetic energy. The Fresnel zone provides us with a way to calculate the amount of clearance that a wireless wave needs from an obstacle to ensure that the obstacle does not attenuate the signal. There are infinitely many Fresnel zones located coaxially around the center of the direct wave. The outer boundary of the first Fresnel zone is defined as the combined path length of all paths, which are half wavelength (1/2 ) of the frequency transmitted longer than the direct path. If the total path distance is one wavelength (1 ) longer than the direct path, then the outer boundary is said to be two Fresnel zones. Odd number Fresnel zones reinforce the direct wave path signal; even number Fresnel zones cancel the direct wave path signal. The amount of the Fresnel zone clearance is determined by the wavelength of the signal, the path length, and the distance to the obstacle. For reliability, point‐to‐point links are designed to have at least 60% of the first Fresnel zone clear to avoid significant attenuation. The concept of the Fresnel zone is shown in Figure 19‐1 above. The top of the obstruction does not extend far into the Fresnel zone, leaving 60% of the Fresnel zone clear; therefore, the signal is not significantly attenuated. For more about Fresnel zone, see http://en.wikipedia.org/wiki/Fresnel_zone. RADWIN 2000 D+ User Manual Release 3.6.00 19‐4...
Page 186: Figure 19-2 Link Budget
Running the Link Budget Calculator Chapter 19 19.4 Running the Link Budget Calculator for RADWIN 2000 D+ is availableThe Link Budget Calculator for RADWIN 2000 D+ is available at http://www.radwin.com/planner/. Go to the URL. Your browser displays the following page (shown partially): Figure 19‐2: Link Budget window ‐ startup  To use the Link Budget Calculator for RADWIN 2000 D+: 1. Stay on the left hand highlighted tab. RADWIN 2000 D+ User Manual Release 3.6.00 19‐5...
Page 187 Running the Link Budget Calculator Chapter 19 Figure 19‐3: RADWIN 2000 D+ LBC main window 2. Chose the required band. Scroll down to get to Connectorized bands. RADWIN 2000 D+ User Manual Release 3.6.00 19‐6...
Page 188: Figure 19-4 Band Selector
Running the Link Budget Calculator Chapter 19 Figure 19‐4: Band selector For the purposes of our example, we will use 5.8 GHz FCC/IC Connectorized. 3. Choose the Series: 4. Choose the channel Bandwidth: Collocated ODUs use RFP E so there is no HSS entry Note 5. Choose the required Tx Power. Under Adaptive Rate, this will be the Max Tx Power and you cannot change it. 6. Choose the required antenna type ‐ dual or single. For integrated products this item will be disabled. 7. Enter the radio parameters for each site: RADWIN 2000 D+ User Manual Release 3.6.00 19‐7...
Page 189: Figure 19-5 Calculation Of
Running the Link Budget Calculator Chapter 19 The Fade margin is the minimum required for line‐of‐sight (LOS) conditions. For degraded link conditions, a larger Fade margin should be used. Again, it is not avail‐ able when using Adaptive Rate. The EIRP is calculated in dBm and Watts. 8. The Rate item may be used for calculating the Link Budget under best and worst scenarios. It is always set to maximum under Adaptive Rate. 9. If the required range between the two link sites is known, you may enter it directly. Alternatively, you may enter the latitude and longitude of each site in the link, in which case the distance between them will be calculated and displayed. Figure 19‐5: Calculation of distance from site coordinates If for example, we enter: Site A: 41.1°N lat 75.2°W Long Site B: 40.8°N lat 75.0°W Long RADWIN 2000 D+ User Manual Release 3.6.00 19‐8...
Page 190: Figure 19-6 Climacticc F
Running the Link Budget Calculator Chapter 19 and press Set, the range will be calculated and displayed: 10. Located to the right of the green Coordinates button is a drop‐down list of Climactic C Factor values. It is only available if you choose a non‐adaptive rate. Figure 19‐6: Climactic C Factors For help about what these mean, click the button to the right of the list in Figure 19‐6. RADWIN 2000 D+ User Manual Release 3.6.00 19‐9...
Page 191: Figure 19-7 Climacticc Factor
Running the Link Budget Calculator Chapter 19 Figure 19‐7: Climactic C Factor description In Figure 19‐8 we display a map of the world showing C Factor contours: Figure 19‐8: World map showing C Factor contours 11. Click Calculate to obtain the required performance estimate. Placing the cursor in any other calculated field will also update the calculated results. Note RADWIN 2000 D+ User Manual Release 3.6.00 19‐10...
Page 192 Running the Link Budget Calculator Chapter 19 Figure 19‐9: LBC ‐ Results section The Expected Performance parameters are calculated and displayed: • Expected RSS ‐ the expected RSS that the RADWIN Manager shows when the RADWIN 2000 D+ ODUs are optimally aligned • Services Type ‐ Ethernet only • Ethernet Rate ‐ maximum throughput available for the chosen parameter combination • Antenna height for LOS – the minimum antenna height required for line‐of‐sight opera‐ tion. It is the sum of the height required for boresight clearance due to the earth’s cur‐ vature plus the height required to clear the Fresnel zone If the expected performance is not suitable for your application, try different parameters and repeat the calculation. RADWIN 2000 D+ User Manual Release 3.6.00 19‐11...
Page 193 Chapter 20: Spectrum View 20.1 What is Spectrum View The RADWIN Manager Spectrum View utility is an RF survey tool designed to support the link installation prior to full link service activation. The tool provides comprehensive and clear spectral measurement information enabling easier, faster and better quality installations. You can view real‐time spectrum information, save the spectral information and view retrieved spectral information from historic spectrum scans. Separate information is generated for the Slave and Master ‐ all by selection. RADWIN’s spectrum measurement and estimation algorithms are designed to show accurate information accommodating variations in frequency, temperature and interference power and at the same time overcoming anomalies that tend to occur in high interference environments. 20.2 Who needs it As indicated in the previous paragraph, Spectrum View is primarily a professional tool for the technician. The Spectrum View reports may be generated as images, CSV files or text files as part of the Get Diagnostics feature. All of these are intended for use by to RADWIN Customer Service to assist with diagnosing interference related problems. 20.3 Scope of this Chapter In view of the nature of the intended audience, we assume that the reader knows about RF Spectrum Analysis. This chapter therefore, is not a tutorial on RF Spectrum Analysis and is restricted to showing how to use the Spectrum View tool without any further theoretical explanations. 20.4 Two Ways to Run Spectrum View Spectrum View may be run from RT‐A(HBS) in which case you have a choice of analyzing both sites in the link in one run, or choosing just one. RADWIN 2000 D+ User Manual Release 3.6.00 20‐1...
Page 194 Where is the Spectrum View Data stored Chapter 20 Spectrum View may also be run on a managing computer directly connected to the RT‐ B(HSU). Remember that in such a case the results will be quite different if the RT‐B(HSU) is already part of a link (registered or not) or if it is completely stand‐alone, for example using a different spectral range and operating Band from the RT‐A(HBS). In the former case, expect a “noise hump” around the channels used by the link, due to the duty signals from the RT‐ A(HBS). 20.5 Where is the Spectrum View Data stored Spectrum View data is always stored in the ODU originating the analysis. The RT‐A(HBS) maintains the last Spectrum View analysis data for both members of the link. If you run Spectrum View from a directly connected ODU, it stores its own data, which may be quite different from the analysis obtained for the same RT‐B(HSU) from the RT‐A(HBS). 20.6 Spectrum View Main Window In this section we review the main window management controls. From the Tools tab, choose Spectrum View. The Spectrum View main window opens in full screen mode: RADWIN 2000 D+ User Manual Release 3.6.00 20‐2...
Page 195 Spectrum View Main Window Chapter 20 Use the top left panel to set the Spectrum View configuration parameters and choose an analysis type ‐ Entire link or Specific ODU. The settings are “sticky” for the link and will be reused. The analysis range is limited from 4900 to 6050 MHz with a maximum difference of 500MHz. Erroneous entries will be shown with a red border like this: The timeout is the maximum analysis time per site. Use the bottom button bar to start or stop an analysis: Since a large link will clutter up the right hand display area, you may selectively Show, minimize or remove a link member. Another way of freeing up more space for analysis displays is to hide the left hand panel using the circled arrow: RADWIN 2000 D+ User Manual Release 3.6.00 20‐3...
Page 196 Spectrum View Display Function Buttons Chapter 20 The standard X button closes the window completely (but does not loose data). The ‐ button collapses the view to look like this: The two side arrows (circled) are used to reorder a stack of such view on the display area: The remaining controls on the Spectrum View main window relate to Spectrum View data manipulation. We will cover them in the next section using a live analysis. 20.7 Spectrum View Display Function Buttons Spectrum View data manipulation functions are provide on the top button bar: Each button function applies to all of the link members at once. Note RADWIN 2000 D+ User Manual Release 3.6.00 20‐4...
Page 197 Running Spectrum View Chapter 20 Table 20‐1: Spectrum View Analysis Display Buttons functionality Butto Purpose Show/Hide Antenna A Show/Hide Antenna B Show/Hide average Show/Hide current channel (HSUs only) Show/Hide maximum Show/Hide DFS information where relevant Show/Hide point values Save the analysis to a CSV file Clear all link member analyses from the display (They can be shown again) 20.8 Running Spectrum View Click Start. You are offered the following cautionary message: RADWIN 2000 D+ User Manual Release 3.6.00 20‐5...
Page 198: Figure 20-1 Spectrum Viewa
Running Spectrum View Chapter 20 If it is acceptable to drop the service click Yes. The processing may appear to have stopped ‐ but it is not complete until all of the Show buttons for link are enabled. Here is the result for the RT‐A(HBS): The keys to the color coding is permanently displayed at the bottom of the main window: Figure 20‐1: Spectrum View Analysis color codes The green band reflects the current Master operating frequency. Notice also the small fly‐ over diskette icon (circled) to the upper left of either graph. Clicking it opens a Windows File‐ Save dialog allowing you to save the graph to disk as a jpg file. Here is the analysis for RT‐B(HSU). It is very similar: The light green rectangle in the background of both antenna displays reflects actual channel (20 MHz wide here) being used by the Slave. The title bar also contains the Slave’s IP address. RADWIN 2000 D+ User Manual Release 3.6.00 20‐6...
Page 199 Zooming in and out Chapter 20 20.9 Zooming in and out You may zoom in on a range of interest and enlarge it. Use the mouse to swipe the range from left to right or reverse and then click.The swiped range is zoomed in. You may repeat this several times. The zoom applies to all charts for all element in the analysis. An indicator is provided at the top right of each chart: Zoom Out returns you to the previous zoom state; Show all reverts you to the original display. In a zoomed state, a horizontal scroll bar enables you to view other areas of the displayed frequency range. RADWIN 2000 D+ User Manual Release 3.6.00 20‐7...
Page 200 Chapter 21: Using the Web Interface 21.1 What is it For The Web Interface (WI) enables you to carry out basic link management functions using a Web browser. It may be used to ‐ • Monitor a link on a minimal basis • Check link parameters and make limited changes • View the link Inventory • Inspect the Recent Events logs 21.2 Who Needs it The WI is a tool for technicians to “quick‐install” an ODU in a link with minimum effort. It may also be employed by a user for a quick look at current operating parameters and the Recent Events logs. 21.3 How it Works Assume the link setup, which we used in and later. Link Configuration On the managing computer, point your browser to10.104.4.2 and log on as shown below. You can also log on over the air to the Slave ODU in the same way. For stand‐alone or unregistered ODUs, you must connect a managing computer directly to the ODU and again log on as shown below. 21.4 What it Provides The WI is a developing technology. It is possible that the current distributed release may have additional or slightly different features from those shown here. The description below, should nevertheless give you a good idea of how to use the WI. RADWIN 2000 D+ User Manual Release 3.6.00 21‐1...
Page 201 Prerequisites Chapter 21 21.5 Prerequisites 21.5.1 Hardware You need a regular LAN connection between a managing computer and one of the link ODUs. The WI can be used directly opposite the HBS any of its HSUs. It can also be used over the air from the HBS to any registered HSU. 21.5.2 Software Your computer should have at least version 6 of MS Internet Explorer. The Web interface also works with other browsers such as Mozilla Firefox version 3 and later. 21.5.3 Technical Background You should be familiar with the concepts underlying the RADWIN Manager and preferably with the Manager itself. 21.6 Special Considerations Working with the 21.6.1 Advanced Configurations For setup configurations using features such as HSS, VLAN and QoS, you will need to use the RADWIN Manager. 21.6.2 Operational Effects Several WI functions cause temporary sync loss. Typically, changing the number of antennas falls into this category. These cases will be pointed out in Warning messages. 21.6.3 Some Working Tips You can: » Log on to a ODU on the default IP address of 10.0.0.120/8, set the Link ID and IP address instead of using the RADWIN Manager as in Getting Started with the RADWIN Manager. Unlike the Local Connection method, you need to reset the ODU to see the change in the Web Interface. » Change the operating Band for the link instead of using the RADWIN Manager. You can revert it the same way or by a direct connection, logged on as Installer. » Look at Recent Events for either site RADWIN 2000 D+ User Manual Release 3.6.00 21‐2...
Page 202: Figure 21-1 Web Interface - L
Scope of this Chapter Chapter 21 You cannot: » Change default Tx Power » Configure Spatial Multiplexing/Diversity » Manage other features such as GSU (when supported), VLAN, QoS » Perform Software upgrade Be very careful: » Using this tool if your link is providing Customer Service which may not be interrupted with sync‐losses 21.7 Scope of this Chapter The remainder of this chapter is divided into three sections: Logging on, HBS Configuration and HSU Configuration. 21.8 Logging on To use the Web interface, simply point your browser to the IP address of the site to which you are connected. Figure 21‐1: Web interface ‐ Log on The User Name and Password are respectively, admin and netman as used for Telnet access. You must click the Log In button to effect entry to the WI. RADWIN 2000 D+ User Manual Release 3.6.00 21‐3...
Page 203: Figure 21-2 Web Interface - M
Site Management ‐ Master ODU Chapter 21 The foregoing applies to both ODUs. The functionality described below is predominantly site oriented. Site configuration items shown for Site_A may be carried out for Site_B by logging on to it. 21.9 Site Management ‐ Master ODU 21.9.1 The Main Window Figure 21‐2: Web interface ‐ Main window The link ID (EBGX20560334) appears all or in part as the heading. The main panel is self explanatory. The green Active indicator will vary according to the status of the Master ODU shown by the RADWIN Manager. The top green item (Registered here) indicates the status of the Slave ODU. Figure 21‐3: Link Status panel RADWIN 2000 D+ User Manual Release 3.6.00 21‐4...
Page 204 The Tool Bar Chapter 21 (it will typically be Active, Inactive, Probing etc.) 21.9.2 The Tool Bar Configure The Configure button opens the following display: System The Name, Contact and Location field may be changed. Using Save commits them. Clicking Refresh reverts the fields to their last Saved values. Air Interface You can change the Sector ID (Link ID) and the Buzzer status. RADWIN 2000 D+ User Manual Release 3.6.00 21‐5...
Page 205 The Tool Bar Chapter 21 You can use the Change Band button to open the following display: The Antenna & Tx Power button opens up the following window: RADWIN 2000 D+ User Manual Release 3.6.00 21‐6...
Page 206 The Tool Bar Chapter 21 The only item that can be changed is the Antenna Type: Changing Antenna Type will call a link‐wide sync loss. Caution Inventory The Inventory display is for information only. Management The Management fields are all fully editable: RADWIN 2000 D+ User Manual Release 3.6.00 21‐7...
Page 207 The Tool Bar Chapter 21 If you change any of these fields, you will cause an ODU reset: RADWIN 2000 D+ User Manual Release 3.6.00 21‐8...
Page 208 The Tool Bar Chapter 21 Other You may change the ODU LAN port configuration: You will receive the following notification: This action of course, has no bearing on the link. RADWIN 2000 D+ User Manual Release 3.6.00 21‐9...
Page 209 Events Chapter 21 21.9.3 Events The Recent Event List is displayed: 21.9.4 Reset Use this button to reset the ODU. As usual, for any action causing a sync loss you wil be asked to confirm the action: 21.10 Site Management ‐ Slave ODU Slave ODU site management is the same as that for the Master ODU. RADWIN 2000 D+ User Manual Release 3.6.00 21‐10...
Page 210 Part 6: Product Reference Release 3.6.00...
Page 211: Table A-1 Safety Distances
Appendix A: RF Exposure The antennas used for the following transmitters must be installed so as to provide a minimum separation distance from bystanders as specified in the following tables: Table A‐1: Safety Distances for RADWIN 2000 D+ FCC and IC Products Frequency Antenna gain Min. Safety Band FCC ID IC ID [dBi] Distance [cm] [GHz] Q3K‐5XACMOD 5100A‐5XACMOD Q3K‐5XACMOD 5100A‐5XACMOD Q3K‐5XACMOD 5100A‐5XACMOD Q3K‐5XACMOD 5100A‐5XACMOD Q3K‐5XACMOD 5100A‐5XACMOD Q3K‐5XACMOD 5100A‐5XACMOD Q3K‐5XACMOD 5100A‐5XACMOD Q3K‐5XACMOD 5100A‐5XACMOD Table A‐2: Safety Distances for RADWIN 2000 D+ ETSI Products Min. Safety Frequency Band Antenna gain Distance [GHz] [dBi] [cm] 5.8/5.4/5.3/ All gains RADWIN 2000 D+ User Manual Release 3.6.00...
Page 212 Appendix B: Setting Antenna Parameters B.1 Antenna Issues The choice of Tx Power, antenna gain and cable loss (between the radio and the antenna) determines the EIRP and is affected by such considerations as radio limitations and regulatory restrictions. Before proceeding to antenna installation details, the following background information should be considered: B.2 About Single and Dual Antennas Each RADWIN 2000 D+ ODU is made of two radio transceivers (radios). The radios make use of algorithms that utilize both Spatial Multiplexing and Diversity resulting in enhanced capacity, range and link availability. The number of antennas (i.e. radios) used is determined by user configuration and by automatic system decisions, explained below. B.2.1 Dual Antennas at the HBS and an HSU When using dual antennas at both sites (single bipolar antenna or two unipolar antennas) you can choose between Spatial Multiplexing Mode and Diversity Mode. Spatial Multiplexing Mode Under this mode, the system doubles the link capacity. At the same time, it keeps the same rate and modulation per radio as was used with single antenna, thus increasing capacity, range and availability. For example, at 80MHz CBW, using a dual antenna RADWIN 2000 D+ can transmit at modulation of 256QAM and FEC of 5/6 and get an air rate of 866.7 Mbps, compared to 433.3 Mbps with single antenna. To work in this mode, each antenna port must be connected to an antenna, the RSS level in both receivers should be balanced and a minimal separation between the antennas must be RADWIN 2000 D+ User Manual Release 3.6.00 B‐1...
Page 213 Single Antennas at Both Sites Chapter B maintained. (For example, by using dual polarization antennas a cross polarization separation is attained). Upon selecting Antenna Type as Dual, RADWIN 2000 D+ automatically selects this mode and doubles the air rates. RADWIN Manager indicates a case of unbalanced RSS between the two antennas in the center panel. Diversity Mode Diversity Mode uses two antennas to improve the quality and reliability of the link. Often, there is not a clear line‐of‐sight (LOS) between transmitter and receiver. Instead the signal is reflected along multiple paths before finally being received. Each such “bounce” can introduce phase shifts, time delays, attenuations, and even distortions that can destructively interfere with one another at the aperture of the receiving antenna. Antenna diversity is especially effective at mitigating these multi‐path situations. This is because multiple antennas afford a receiver several recordings of the same signal. Each antenna will be exposed to a different interference environment. Thus, if one antenna is undergoing a deep fade, it is likely that another has a sufficient signal. Collectively such a system can provide a robust link. Antenna diversity requires antenna separation which is possible by using a dual‐polarization antenna or by two spatially separated antennas. Use Diversity instead of Spatial Multiplexing in the following situations: • When the system cannot operate in Spatial Multiplexing Mode • When one of the receivers has high interference compared to the second receiver (i.e. the system is “unbalanced”) • When you achieve higher capacity in Diversity Mode than in Spatial Multiplexing Mode • When high robustness is of importance and the capacity of Diversity Mode is sufficient (up to 25 Mbps full duplex) B.2.2 Single Antennas at Both Sites By selecting a single antenna at both sites, the ODUs operate with a single radio that is connected to the ANT 1 connector. The second radio is automatically shut down. B.2.3 Single at One Site, Dual Antennas at the Other In this mode one of the sites uses the ODU with a single antenna while the other site uses the ODU with a dual antenna. The advantages in this mode in comparison to using a single antenna in both sites are doubled total Tx Power and additional polarization and/or space diversity (depending on the ...
Page 214 Considerations for Changing Antenna Parameters Chapter B The data rates used by RADWIN 2000 D+ are shown in Table B‐1 below (SGI = Small Guard Interval): Table B‐1: RADWIN 2000 D+ Air rates Channel Bandwidth Spatial Modulation Coding 20MHz 40MHz 80MHz Streams No SGI No SGI No SGI BPSK 13.5 29.3 32.5 QPSK 14.4 58.5 QPSK 19.5 21.7 40.5 87.8 97.5 16‐QAM 28.9 16‐QAM 43.3 175.5 64‐QAM 57.8 64‐QAM 58.5 121.5 263.3...
Page 215 The Tx Power (per radio) indicates the power of each radio inside the ODU and is used for Link Budget Calculations. The Tx Power (System) shows the total transmission power of the ODU and is used to calculate the EIRP according to regulations. • To see the relationship between Tx Power (radio) and Tx Power (sys‐  tem), note that milliWatt so that if you double the power in milliWatts (for two radios) then dBm will increase by   • The Max EIRP level will be automatically set according to the selected band and regulation. • The EIRP level is the sum of the System Tx Power and the Antenna Notes Gain minus the Cable Loss. • The Max EIRP level will be automatically set according to the selected band and regulation. • The EIRP level is the sum of the System Tx Power and the Antenna Gain minus the Cable Loss. The inequality (*) above is always satisfied by the system in accordance with the relevant regulation. The precise relationship between the items in inequality (*) is as follows: • Required Tx Power (per radio) will be adjusted down to the lesser of the value entered and maxAvailableTxPower • Tx Power (system) is maxAvailableTxPower + 3 (for 2 radios) • Max EIRP is maxRegEIRP. • EIRP is maxAvailableTx Power + Antenna Gain ‐ Cable Loss RADWIN 2000 D+ User Manual Release 3.6.00 B‐4...
Page 216 Appendix C: Regional Notice: French Canadian C.1 Procédures de sécurité C.1.1 Généralités Avant de manipuler du matériel connecté à des lignes électriques ou de télécommunications, il est conseillé de se défaire de bijoux ou de tout autre objet métallique qui pourrait entrer en contact avec les éléments sous tension. C.1.2 Mise à la terre Tous les produits RADWIN doivent être mis à la terre pendant l'usage courant. La mise à la terre est assurée en reliant la fiche d'alimentation à une prise de courant avec une protection de terre. En outre: • La cosse de masse sur l'IDU‐C doit être constamment connectée à la protection de terre, par un câble de diamètre de 18 AWG ou plus. Le matériel monté sur rack doit être installé seulement sur des racks ou armoires reliés à la terre • Une ODU doit mise à la terre par un câble de diamètre de 10 AWG ou plus • Il ne doit pas y avoir de fusibles ou d'interrupteurs sur la connection à la terre De plus: • Il faut toujours connecter la terre en premier et la déconnecter en dernier • Il ne faut jamais connecter les câbles de télécommunication à du matériel non à la terre • Il faut s'assurer que tous les autres câbles sont déconnectés avant de déconnecter la terre C.1.3 Protection contre la foudre L'utilisation de dispositifs de protection contre la foudre dépend des exigences réglementaires et de l'utilisateur final. Toutes les unités extérieures RADWIN sont conçues avec des circuits de limitation de surtension afin de minimiser les risques de dommages dus à la foudre. RADWIN conseille l'utilisation d'un dispositif de parafoudre supplémentaire afin de RADWIN 2000 D+ User Manual Release 3.6.00 C‐1...
Page 217 • Pince à sertir RJ‐45 (si un câble pré‐assemblé ODU/IDU n'est pas utilisé) • Perceuse (pour le montage sur mur seulement) • Câbles de terre IDU et ODU • Clef 13 mm (½) • Câble ODU ‐ IDU si non commandé (type extérieur, CAT‐5e, 4 paires torsadées, 24 AWG) • Colliers de serrage • Ordinateur portable avec Windows 2000 ou Windows XP. C.1.4 Précautions de sécurité pendant le montage de ODU Avant de connecter un câble à l'ODU, la borne protectrice de masse (visse) de l'ODU doit être connectée à un conducteur externe protecteur ou à un pylône relié à la terre. Il ne doit pas y avoir de fusibles ou d'interrupteurs sur la connection à la terre. Seulement un personnel qualifié utilisant l'équipement de sécurité approprié doit pouvoir monter sur le pylône d'antenne. De même, l'installation ou le démontage de ODU ou de pylônes doit être effectuée seulement par des professionnels ayant suivi une formation.  Pour monter l'ODU: 1. Vérifier que les supports de fixation de l'ODU sont correctement mis à la terre. 2. Monter l'unité ODU sur le pylône ou sur le mur; se référer à la Installation sur pylône et mur au dessous. 3. Connecter la câble de terre au point de châssis sur l'ODU. 4. Relier le câble ODU‐IDU au connecteur ODU RJ‐45. 5. Visser les presses‐étoupe de câbles pour assurer le scellement hermétique des unités ODU. 6. Attacher le câble au pylône ou aux supports en utilisant des colliers classés UV. 7. Répéter la procédure sur le site distant. Ne pas se placer en face d'une ODU sous tension. Prudence C.1.5 Connecter la terre à IDU‐C Connecter un câble de terre de 18 AWG à la borne de masse de l'appareil. L'appareil doit être constamment connecté à la terre. RADWIN 2000 D+ User Manual Release 3.6.00 C‐2...
Page 218: Figure C-1 Grande Clame
• Les appareils sont prévus pour être installés par un personnel de ser‐ vice. • Les appareils doivent être connectés à une prise de courant avec une protection de terre. • Le courant CC du IDU‐C doit être fourni par l'intermédiaire d'un dis‐ Prudence joncteur bipolaire et le diamètre du câble doit être de 14 mm avec un conduit de 16 mm. C.2 Installation sur pylône et mur L' ODU ou l'O‐PoE peuvent être montés sur un pylône ou un mur. C.2.1 Contenu du kit de montage ODU Le kit de montage ODU comprend les pièces suivantes: • une grande clame (voir Figure C‐1) • une petite clame (voir Figure C‐2) • un bras (voir Figure C‐3) • quatre visses hex tête M8x40 • deux visses hex tête M8x70 • quatre rondelles plates M8 • trois rondelles élastiques M8 • deux écrous M8. Figure C‐1: grande clame Figure C‐2: petite clame Figure C‐3: bras RADWIN 2000 D+ User Manual Release 3.6.00 C‐3...
Page 219 Montage sur un pylône Chapter C C.2.2 Montage sur un pylône RADWIN 2000 D+ User Manual Release 3.6.00 C‐4...
Page 220: Figure C-4 Montage Sur Un
Montage sur un mur Chapter C Figure C‐4: Montage sur un pylône C.2.3 Montage sur un mur RADWIN 2000 D+ User Manual Release 3.6.00 C‐5...
Page 221: Figure C-5 Montage Sur Un
Montage d'une antenne externe Chapter C Figure C‐5: Montage sur un mur C.2.4 Montage d'une antenne externe L'antenne externe optionnelle peut être montée sur un pylône. C.2.5 Contenu du kit de montage d'une antenne externe Le kit de montage d'une antenne externe comprend les pièces suivantes • Douze rondelles plates • Huit rondelles élastiques • Huit écrous hex • Quatre boulons • Un support en U RADWIN 2000 D+ User Manual Release 3.6.00 C‐6...
Page 222 Contenu du kit de montage d'une antenne externe Chapter C • Un support à pivotement • Deux courroies de fixation en métal  Pour installer une antenne externe sur un pylône: 1. Attacher le support en U à l'arrière de l'antenne en utilisant quatre rondelles plates, quatre rondelles élastiques et quatre écrous hex. 2. Attacher le support à pivotement au support en U en utilisant huit rondelles plates, quatre rondelles élastiques, quatre écrous hex et quatre boulons. 3. Passer les deux courroies de fixation par les fentes verticales dans le support à pivotement. 4. Attacher l'antenne au pylône en utilisant les deux courroies de fixation . Ajuster l'inclinaison nécessaire en utilisant l'échelle angulaire et serrer tous les boulons et écrous à la position requise. RADWIN 2000 D+ User Manual Release 3.6.00 C‐7...
Page 223 Part 7: Regulatory Notices Release 3.6.00...
Page 224 FCC ‐ Compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Changes or modifications to this equipment not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. It is the responsibility of the installer to ensure that when using the outdoor antenna kits in the United States (or where FCC rules apply), only those antennas certified with the product are used. The use of any antenna other than those certified with the product is expressly forbidden by FCC rules 47 Warning CFR part 15.204. It is the responsibility of the installer to ensure that when configuring the radio in the United States (or where FCC rules apply), the Tx power is set according to the values for which the product is certified. The use of Tx power values other than those, for which the product is certified, is Warning expressly forbidden by FCC rules 47 CFR part 15.204. Indoor Units comply with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) These devices may not cause harmful interference. RADWIN 2000 D+ User Manual Release 3.6.00...
Page 225 Outdoor units and antennas should be installed ONLY by experienced installation professionals who are familiar with local building and safety codes and, wherever applicable, are licensed by the appropriate government regulatory authorities. Failure to do so may void the product warranty and may expose the end user or the service provider to legal and financial liabilities. Resellers or distributors of this equipment are not liable Caution for injury, damage or violation of regulations associated with the installation of outdoor units or antennas. The installer should configure the output power level of antennas according to country regulations and antenna type. • Where Outdoor units are configurable by software to Tx power values other than those for which the product is certified, it is the responsi‐ bility of the Professional Installer to restrict the Tx power to the certi‐ fied limits. • This product was tested with special accessories ‐ indoor unit (IDU or Warning PoE), FTP CAT‐5e shielded cable with sealing gasket, 10 AWG ground‐ ing cable ‐ which must be used with the unit to insure compliance. (2) These devices must accept any interference received, including interference that may cause undesired operation. Canadian Emission Requirements for Indoor Units This Class B digital apparatus complies with Canadian ICES‐003. Cet appareil numẻrique de la classe B est conforme ả la norme NMB‐003 du Canada. China MII Operation of the equipment is only allowed under China MII 5.8GHz band regulation configuration with EIRP limited to 33 dBm (2 Watt). India WPC Operation of the equipment is only allowed under India WPC GSR‐38 for 5.8GHz band regulation configuration. Unregulated In countries where the radio is not regulated the equipment can be operated in any regulation configuration, best results will be obtained using Universal regulation configuration. Safety Practices Applicable requirements of National Electrical Code (NEC), NFPA 70; and the National Electrical Safety Code, ANSI/IEEE C2, must be considered during installation. RADWIN 2000 D+ User Manual Release 3.6.00...
Page 226 NOTES: 1. A Primary Protector is not required to protect the exposed wiring as long as the exposed wiring length is limited to less than or equal to 140 feet, and instructions are provided to avoid exposure of wiring to accidental contact with lightning and power conductors in accordance with NEC Sections 725‐54 (c) and 800‐30. In all other cases, an appropriate Listed Primary Protector must be provided. Refer to Articles 800 and 810 of the NEC for details. 2. For protection of ODU against direct lightning strikes, appropriate requirements of NFPA 780 should be considered in addition to NEC. 3. For Canada, appropriate requirements of the CEC 22.1 including Section 60 and additional requirements of CAN/CSA‐B72 must be considered as applicable. RADWIN 2000 D+ User Manual Release 3.6.00...
Page 227 RADWIN Worldwide Offices Corporate and EMEA Regional Headquarters Corporate and EMEA Headquarters North America Regional Headquarters 27 Habarzel Street 900 Corporate Drive Tel Aviv,6971039 Mahwah, NJ, 07430 Israel Tel: +972.3.766.2900 Tel: +1-877-RADWIN US Fax: +972.3.766.2902 (+1-877 723-9468) Tel: +1-201-252-4224 sales@radwin.com Email: Fax: +1-201-621-8911 salesna@radwin.com Email: Customer Support - North America: Hours: 9 am - 6 pm EST (Mon - Fri) supportusa@radwin.com...
Page 229 Item Version Build Date 3.6.00 NMS 9.6.20 9596 31/12/2014 SWU ‐ Inventory 3.5.05.00 3515.00 20/03/2014 MIB 9.6.10.00 9590 09/01/2014 9390_Web 16/12/2014 Release type 10/01/2015...

Radwin 2000 D+ User Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Radwin RADWIN 2000 D+

Summary of Contents for Radwin RADWIN 2000 D+

Table of Contents
