- Page 1 AXIS Camera Station S20 Appliance Series AXIS Camera Station S2008 Appliance AXIS Camera Station S2016 Appliance AXIS Camera Station S2024 Appliance Installation Guide...
- Page 2 Restrictions of Hazardous Substances (RoHS) Directive Every care has been taken in the preparation of this 2011/65/EU. See . document. Please inform your local Axis office of any A copy of the original declaration of conformity may be inaccuracies or omissions. Axis Communications AB cannot obtained from Axis Communications AB.
- Page 3 • find answers to resolved problems in the FAQ database. Search by product, category, or phrase • report problems to Axis support staff by logging in to your private support area • chat with Axis support staff •...
-
Page 5: Hazard Levels
AXIS Camera Station S20 Appliance Series Safety Information Read through this Installation Guide carefully before installing the product. Keep the Installation Guide for future reference. Hazard Levels DANGER Indicates a hazardous situation which, if not avoided, will result in death or serious injury. -
Page 6: Safety Instructions
• When transporting the Axis product, use the original packaging or equivalent to prevent damage to the product. The Axis product uses a 3.0 V CR2032 lithium battery as the power supply for its internal real-time clock (RTC). Under normal conditions this battery will last for a minimum of five years. - Page 7 WARNING • Risk of explosion if the battery is incorrectly replaced. • Replace only with an identical battery or a battery which is recommended by Axis. • Dispose of used batteries according to local regulations or the battery manufacturer's instructions.
-
Page 8: Installation Steps
AXIS Camera Station S20 Appliance Series Installation Guide This Installation Guide provides instructions for installing AXIS S2008, AXIS S2016 and AXIS S2024. For other aspects of using the product, go to www.axis.com Installation Steps 1. Make sure the package contents, tools and other materials necessary for the installation are in order. -
Page 9: Hardware Overview
AXIS Camera Station S20 Appliance Series Hardware Overview Front and Back Panel AXIS S2008 USB 2.0 connector x2 System power LED Disk activity LED Status LEDs, PoE port 1–8 U1 switch uplink, RJ45 connector SFP 1 switch uplink, SFP connector... - Page 10 AXIS Camera Station S20 Appliance Series Front and Back Panel AXIS S2016 USB 2.0 connector x2 System power LED Disk activity LED Status LEDs, PoE port 1–16 U1 switch uplink, RJ45 connector SFP 1 switch uplink, SFP connector U2 server network, RJ45 connector...
- Page 11 AXIS Camera Station S20 Appliance Series Front and Back Panel AXIS S2024 USB 2.0 connector x2 System power LED Disk activity LED Status LEDs, PoE port 1–24 U1 switch uplink, RJ45 connector SFP 1 switch uplink, SFP connector U2 server network, RJ45 connector...
-
Page 12: Unpack And Install The Appliance
Unpack and Install the appliance Unpack your system and identify each item, see Package Contents on page 8 . AXIS S2008 – Assemble the brackets and install the Axis appliance on a wall or on a flat surface following the safety instructions. -
Page 13: Set Up Software
Network Configuration AXIS Camera Station can record and play back video from cameras and video encoders that are connected to a LAN (Local Area Network) or to a WAN (Wide Area Network). Depending on the installation, follow the instructions under Network & Security Configuration in AXIS Camera Station User Manual available at www.axis.com... -
Page 14: Specification
3.5 kg ( 7.7 lbs) 10 kg (22 lb) Environmental Temperature AXIS S2008 / AXIS S2016 / AXIS 2024 Operating 0 °C to 40 °C (32 °F to 104 °F) Storage –40 °C to 65 °C (–40 °F to 149°F) -
Page 15: Further Information
For the latest version of this document, see www.axis.com • To check if there is updated firmware available for your product, see www.axis.com/support • For useful online trainings and webinars, see www.axis.com/academy Warranty Information For information about Axis’ product warranty and thereto related information, see www.axis.com/warranty/... - Page 16 Installation Guide Ver. M3.2 AXIS Camera Station S20 Appliance Series Date: July 2016 © Axis Communications AB, 2016 Part No. 1632557...
