Chapter 2. Device setup

Parts

The color and shape of parts may differ from what is shown.
Panel key
Speaker
Panel key
Press and hold for three seconds to turn on the display.
To turn off the display using the panel key, press the panel key. Then, press and hold
the panel key until the display turns off.
You can also use the panel key to select a desired source. To select a source, press the
panel key. A popup menu appears. Press the panel key again to select Source. Then,
press and hold the panel key to cycle through the desired source.
• To use the panel key, make sure the sliding panel key is not protruding from the
bottom of the product.
• To use remote/eco sensor, make sure the sliding panel key is protruding from
the bottom of the product.
Remote sensor and spacer logo (optional)
Power
Remote sensor
Press a button on the remote control pointing at the remote sensor on the product to
perform the corresponding function.
• Using other display devices in the same space as the remote control of this product
can cause the other display devices to be inadvertently controlled.
Use the remote control within 23 ft(7 m) to 33 ft(10 m) from the sensor on the product
at an angle of 30° from the left and right.
The product's screen also works as a remote sensor.
When pointing the remote control at the screen, make sure:
• the remote control is pointing towards the center of the screen.
• to use the remote control 1.3 ft (40 cm) to 2.3 ft (70 cm) away from the screen.
WARNING
Store used batteries out of reach of children and recycle.
11
Spacer logo
Remote sensor
