8.2. Input, Output, Routing Connection Rules

Power amplifier output to the corresponding speakers, we define the six
sound field locations: left-front, right-front, left-rear, right-rear, center and subwoofer.
Specific output signal corresponds to the input of the routing rules defined as
follows: (general rules: the left input signal is sent to the left speaker sound field, the
right input signal is sent to the right speaker sound field, front input signal is sent to
the front speaker sound field, front input signal is sent to the front speaker sound
field, rear input signal is sent to the back speaker sound field.
(1) AUX, High-level, Bluetooth:
______________________________________________________________
Signal Input
AUX Left input (stereo input mode)
----------------------------------------------------------
AUX Left-front
(4 channel or 5.1 channel input mode)
----------------------------------------------------------
High-level left-front input
----------------------------------------------------------
Bluetooth left input
AUX right input (stereo input mode)
----------------------------------------------------------
AUX right-front input
(4 channel or 5.1 channel input mode)
----------------------------------------------------------
High-level right-front input
----------------------------------------------------------
Bluetooth left input
AUX left input (stereo input mode)
----------------------------------------------------------
AUX left-rear input (4 channel or 5.1 channel
Input mode)
----------------------------------------------------------
High-level right-rear input
----------------------------------------------------------
Bluetooth right input
AUX right input (stereo input mode)
----------------------------------------------------------
AUX right-rear input (4 channel or 5.1 channel
Input mode)
----------------------------------------------------------
High-level right-rear input
----------------------------------------------------------
Bluetooth right input
Send to output location
Left-front speaker sound field
and left subwoofer sound field
Right-front speaker sound field
and right subwoofer sound field
Left-rear speaker sound field
Right-rear speaker sound field
