LRI1668
Product Guide
ActiLume G2 Indus Sensor
H513 N
The Philips ActiLume G2 Indus Sensor H513 N is a small, lightweight multisensor
designed for integration into luminaires.
The ActiLume G2 Indus Sensor H513 N can be used in combination with the ActiLume
DALI gen2 (LLC1663), ActiLume Wireless DALI gen2 (LLC1685) and ActilLume Wireless
1-10V gen2 (LLC1682) controller. The sensor is specifically designed to be used in
places with high ceilings such as warehouses; retail shops etc. but can also be applied
in office or corridor like applications with high ceilings. The multisensor has a passive
infra-red (PIR) receiver for movement detection, an infra-red (IR) receiver for receiving
information (commands, settings and/or selection) from, for example, the IRT9090
infra-red remote, a daylight receiver to provide Daylight Dependent Regulation (DDR)
and a bi-color LED for indication of sensor powered and motion detection.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ActiLume G2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Philips ActiLume G2

  • Page 1 The Philips ActiLume G2 Indus Sensor H513 N is a small, lightweight multisensor designed for integration into luminaires. The ActiLume G2 Indus Sensor H513 N can be used in combination with the ActiLume DALI gen2 (LLC1663), ActiLume Wireless DALI gen2 (LLC1685) and ActilLume Wireless 1-10V gen2 (LLC1682) controller.
  • Page 2 Features and benefits • As manufacturer of lamps, electronic control gear • The Philips ActiLume G2 Indus Sensor H513 N is and lighting control equipment, Philips ensures a luminaire based detector designed for energy that, from the earliest development stage, optimum savings up to 45%.
  • Page 3 ActiLume gen2 family. Color of the product is white (similar to RAL9016). LCA8007 mounting clip for Valid at +20°C ActiLume G2 Indus Sensor H513 Movement detection pattern diagram Mounting clip for the ActiLume G2 Indus Sensor H513 when...
  • Page 4 Specifications LRI1668 Environmental Viewing angle Operational Light sensor ≈ 50° circular Temperature -20° C … +55° C (daylight spectrum) Humidity 20% … 80% no condensation Movement sensor ≈ 55° circular* (passive infra-red) Storage Infra-red sensor ≈ 30° circular Temperature -25° C … +85° C (RC5 remote code) Humidity 10% …...
  • Page 5 8718291 727927 8718291 727934 727927 00 ActiLume Mntg Clip H513 25 W © 2015 Koninklijke Philips N.V. All rights reserved. Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips N.V. (Royal Philips) or their respective owners.
