Page 1: Solar Panel
SOLAR PANEL INSTALLATION GUIDE September 2008... - Page 2 State or Provincial Workers’ Safety Board. The installation of Enersol Solar Panels may be performed on a low pitched shingle or metal roof. If an installation varies from these types Enersol should be advised and asked for special installation instructions.
-
Page 3: Installation
HIGHEST POINT INSTALLATION A southern exposure is best, followed by west or east. A northern exposure is not recommended. IMPORTANT: Angle panels 4 inches for every 40 feet to drain water back to feed/supply inlet. Use chalk lines to reference angle. FEED /SUPPLY LOWEST POINT RETURN TYPICAL SINGLE ROOF SYSTEM PLUMBING... - Page 4 TYPICAL FLAT ROOF MOUNT Attach headers to 2x6” lumber on each end. 2x6” lumber may then be attached to roof using liquid adhesive (Liquid Nails). Ensure that the rubber is not blocking any roof drainage. TYPICAL RACK MOUNT For safety reasons do not mount panels against a pool. Rack plywood should be mounted 45 or less.
- Page 5 ASSEMBLY INSTRUCTIONS Remove from box carefully and unroll panels. If panels become tangled, lay flat and untwist strips from one end to the other. CONNECT HEADERS O RING MUST USE ORANGE INSTALLATION TOOL Lubricate “O” ring. Push orange installation tool into header clip slot. Push header together.
- Page 6 JOIN ENDCAPS TO HEADERS LOCATOR TAB Remove o ring. Cut locator tab off. END CAP Apply transitional solvent cement liberally to both male and female surfaces. O RING Cement together. Cut a piece of 1 1/2” pipe to 3” long. END CAP ”...
-
Page 7: Install Overview
INSTALL OVERVIEW Follow manufacturers instructions for installation FILTER of automatic control panel, motorized valve and FILTER PUMP HEATER sensors, and automatic controls. SOLAR VALVE S W I M M I N G P O O L SUCTION RETURN (COOL WATER) (WARM WATER) PLUMBING 3-WAY CONTROL VALVE... -
Page 8: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING HEADER REPLACEMENT OR RUBBER REPLACEMENT Any header section or length of rubber can be replaced. To remove the rubber, push the rubber off with a flat screwdriver. Attach tubes to the headers by simply sliding them over the nipples. Warm the ends of the tubes in hot water momentarily.
