5.1. Touch Sensitive screen
prietest TOUCH provides a Touch sensitive LCD panel and a KEYPAD for easy user
interface. The Menus are displayed; the text of the parameter forms the TOUCH ZONE.
Touch screen Layout
For Example: In Kinetic Mode.
Name : ,Mod: KIN
Pri. : 340 , Sec.: 0
ESC
Temp: 37C , KF : 1.000
Vol : 300ul , Unit: No –Unt
Lag : 0 , Read : 0
Blk : N, QC: N , Norm: N
STD: N, Factor: 0.000
Limit Set:
Above is the generic representation of a Test Screen. The Highlighted zones are TOUCH
ZONES, which are active. On touching the "Touch Zone" of a parameter, a sub menu/menu is
displayed or the requested action is carried out, and rest of the "Touch Zone" is deactivated.
For Example: - To activate the selection.
•
To enter the primary filter value, touch any point in the shaded area "Pri" on the LCD
screen. On proper selection the analyser responds with blinking of the parameter text and
also the TOUCH ZONE and a submenu is displayed.
•
To enter Test Name: Touching the "Name" touch zone provides a alphanumeric screen.
Enter the Test name by touching the Touch zone of that variable. The selected value blinks
and is displayed next to the parameter.
Selection Indicator
Selected onscreen item is shown in a shaded background. When the screen first displays, the
default selection is shown. Pressing a selection either highlights that item or activates it.
