Discover the summer/winter time changeover function
b This function lets you select your summer/winter time automatic changeover.
b By default, your ITM uses European parameters:
v Europe:
- summer (last weekend in March +1 hour)
- winter (last weekend in October - 1 hour)
b For other parameters specific to your geographic zone, enter the month and the
corresponding week.
b In the "PROGRAM" mode, choose "SUM/WIN TIM" then "EUROPE" or "OTHER",
to be defined.
b In the manual mode, you can directly adjust the product to make the summer/winter time
changeover.
Use the memory cartridge (cat. no. 15280 optional)
11
b The cartridge can be used on all ITMs.
b It lets you duplicate the program of your ITM (back-up
copy) or incorporate this program into another ITM.
b You can duplicate the ITM's program on the cartridge (1)
or the cartridge on the ITM (2).
b In the "PROGRAM" mode, select "DUPLICATE".
"
Configuration Sheet
Channel 3
.................................................
Circuit controlled:
Function programmed:
v Weekl. prog. v Close delay
v Yearl. prog. v Open delay
v Impuls. prog. v Timer
Time ranges
ON
OFF
Days M T W T F S S
v v v v v v v
Function configuration (delay duration, impulse, timer, counting threshold...):....................................................................................................................
.................................................................................................................................................................................................................................................
Channel 4
Circuit controlled: .................................................
Function programmed:
v Weekl. prog. v Close delay
v Yearl. prog. v Open delay
v Impuls. prog. v Timer
Time ranges
ON
OFF
Days M T W T F S S
v v v v v v v
Function configuration (delay duration, impulse, timer, counting threshold...):...................................................................................................................
.................................................................................................................................................................................................................................................
