Discover the flash device function
b This function is used to repeatedly control an output
channel during a period of operation and a period of
non-operation.
b Optional conditioning of the function by an input.
b This function can be applied permanently or restricted to
a particular time range programmable over one or more
days of the week.
b In the "PROGRAM" mode, select "NEW PRO/ADD"
then "FLASH DEVICE."
9
Discover the time counter and impulse meter functions
Time counter
b This function is used to count the cumulated activation
time of the associated input and to activate an output
channel once the adjustable threshold has been reached.
b Threshold adjustable from 0 to 99 999 hours.
b A different input is used to de-activate the output and
8
resets the counter (RESET).
b In the "PROGRAM" mode, select "NEW PRO/ADD"
then "TIME COUNT."
Impulsion counter
b This function is used to count the number of impulses
on the associated input and to activate an output channel
once the adjustable threshold has been reached.
b Threshold adjustable from 0 to 99 999 impulses.
b A different input is used to de-activate the output and
resets the meter (RESET).
b In the "PROGRAM" mode, select "NEW PRO/ADD"
then "IMPUL. METER"
"
Configuration Sheet
Channel 1
.................................................
Circuit controlled:
Function programmed:
v Weekl. prog.
v Close delay
v Yearl. prog.
v Open delay
v Impuls. prog.
v Timer
Time ranges
ON
OFF
Days
M T W T F S S
v v v v v v v
Function configuration (delay duration, impulse, timer, counting threshold...):...................................................................................................................
.................................................................................................................................................................................................................................................
Channel 2
Circuit controlled:
.................................................
Function programmed:
v Weekl. prog.
v Close delay
v Yearl. prog.
v Open delay
v Impuls. prog.
v Timer
Time ranges
ON
OFF
Days
M T W T F S S
v v v v v v v
Function configuration (delay duration, impulse, timer, counting threshold...):....................................................................................................................
.................................................................................................................................................................................................................................................
E1
E2
E3
v Flash device
E4
v Time count.
E5
v Impul. meter
E6
1
Time
Date
Time
M T W T F S S
v v v v v v v
E1
E2
E3
v Flash device
E4
v Time count.
E5
v Impul. meter
E6
1
Time
Date
Time
M T W T F S S
v v v v v v v
b b b b For example:
ON DURATION:
00min 01s
OFF DURATION:
00min 10s
DURING A
TIME
RANGE?
YES
FROM 20:00
TO: 05:00
MTWTF--
SELECT
CONDITIONAL
INPUT?
YES
b b b b For example:
Time counter
COUNTER:
INPUT 1
0100 HRS
RESET/INP 3
"ON" output channel when
input 1 has cumulated 100
hours activation:
the counter will be reset on
input 3.
Ctrl
Count.
Cond. ON override
v
v
v
v
v
v
v
v
v
v
v
v
v
v
v
v
v
v
2
3
Date
Time
M T W T F S S
v v v v v v v
Ctrl
Count.
Cond. ON override
v
v
v
v
v
v
v
v
v
v
v
v
v
v
v
v
v
v
2
3
Date
Time
M T W T F S S
v v v v v v v
Output channel
status
operation for 1 s
ON
OFF
non operation for 10 s
"ON" output channel for 1 s, "OFF" output channel for 20 s in
turn, from 20H00 to 05:00 from Monday to Friday or when the
selected input is closed.
Status of
input 1
T 1
T 2
T 3
ON
OFF
Output
channel
status
ON
T1+T2+T3+TX = 100 h
OFF
Status of
input 3
(≠ input1)
ON
OFF
RESET Connected item
v
v
.................................................
v
v
.................................................
v
v
.................................................
v
v
.................................................
v
v
.................................................
v
v
.................................................
4
Date
Time
Date
M T W T F S S
v v v v v v v
RESET Connected item
v
v
.................................................
v
v
.................................................
v
v
.................................................
v
v
.................................................
v
v
.................................................
v
v
.................................................
4
Date
Time
Date
M T W T F S S
v v v v v v v
time
T X
time
counting threshold
approach warning
time
counting
reset
time
5
Time
Date
M T W T F S S
v v v v v v v
5
Time
Date
M T W T F S S
v v v v v v v
