GMI PS1 User Handbook Manual

Hide thumbs Also See for PS1:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Handbook Manual
USER HANDBOOK

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PS1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GMI PS1

Summary of Contents for GMI PS1

  • Page 1 USER HANDBOOK...
  • Page 2 GMI welcomes comments on all our publications. Your comments can be of great value in helping us to improve our customer publications. Please send any comments that you have to our Sales Department at GMI. Contact details are provided on the back cover of this handbook.

  • Page 3: Copyright

    GMI is prohibited. Reverse engineering is not permitted. LIABILITY Every care has been taken in the preparation of this document, but GMI do not accept any responsibility for errors or omissions and their consequences. Information in this document is subject to change without notice. This document does not constitute a specification or basis for a contract.

  • Page 4: Software

    USER HANDBOOK This Handbook is part of the PS1 product. Although every care is taken in the preparation of this Handbook it does not constitute a specification for the instrument. SOFTWARE Software supplied for use in a particular product, may only be used in that product and may not be copied without the written permission of GMI.

  • Page 5: Safety

    SUBSTITUTION OF COMPONENTS MAY IMPAIR INTRINSIC SAFETY. WARNING 3: TO PREVENT IGNITION OF FLAMMABLE OR COMBUSTIBLE ATMOSPHERES, DISCONNECT POWER BEFORE SERVICING. Any right of claim relating to product liability or consequential damage to any third party against GMI is removed if the warnings are not observed.

  • Page 6: Areas Of Use

    The instrument contains electrochemical sensors with a minimum life of two (2) years. The PS1 instrument should only be stored for a maximum of one (1) month from the date of manufacture (as indicated on instrument batch label).

  • Page 7: Warranty

    COPYRIGHT WARRANTY The PS1 has a 2 year warranty against faulty goods or workmanship for the lifetime of the instrument. Consumable and Mechanical parts are not included in this. These are covered under GMI standard warranty conditions. For further details, please contact GMI.
  • Page 8 USER HANDBOOK...

  • Page 9: Table Of Contents

    CONTENTS COPYRIGHT .....................................i LIABILITY ......................................i MODIFICATION NOTICES ................................i SOFTWARE .....................................ii DISPOSAL ADVICE ..................................ii SAFETY ......................................iii AREAS OF USE ....................................iv STORAGE, HANDLING AND TRANSIT ............................iv WARRANTY .....................................v 1. INTRODUCTION ........................1-1 1.1 INSTRUMENT PART NUMBER / GAS TYPE ........................ 1-2 1.2 INSTRUMENT FEATURES ............................
  • Page 10 USER HANDBOOK 2. OPERATION ......................... 2-1 2.1 SWITCHING THE INSTRUMENT ON ..........................2-2 2.2 NORMAL OPERATING DISPLAY ........................... 2-6 2.2.1. Life Remaining ..............................2-6 2.2.2. Battery Low / Exhausted ............................2-6 2.3 SWITCHING DISPLAY BACKLIGHT ON........................2-7 2.4 VIEWING MAXIMUM / MINIMUM VALUES ........................2-7 2.4.1.
  • Page 11 CONTENTS 4. OPERATOR MAINTENANCE ....................4-1 4.1 CLEANING ..................................4-1 5. CALIBRATION ........................5-1 5.1 CALIBRATION VALIDITY .............................. 5-2 5.2 BUMP TEST .................................. 5-3 5.2.1 Automatic Bump Test ............................5-3 5.2.2 Manual Bump Test ..............................5-4 6. ACCESSORIES ........................6-1 7.
  • Page 12 USER HANDBOOK...

  • Page 13: Introduction

    Small and lightweight, it is suitably certified to recognised International Standards. The PS1 is a personal safety device that warns when toxic gas or oxygen deficiency exceeds the alarm set- points. (Refer to Chapter 3 for factory set defaults).

  • Page 14: Instrument Part Number / Gas Type

    0 to 500 ppm Carbon Monoxide (CO) 62405 / 63524: 0 to 20 ppm Sulphur Dioxide (SO 1.2 INSTRUMENT FEATURES The main features of the PS1 range of instruments are: • Integral impact resistant housing. • Single button user operation.

  • Page 15: Instrument Identification

    INTRODUCTION 1.3 INSTRUMENT IDENTIFICATION There are four PS1 gas models available. The model is clearly indentified on the front housing of the instrument. The part number and corresponding gas type can be found in section 1.1 of this chapter. 1.4 INSTRUMENT DISPLAY The PS1 display details the current gas readings and life remaining.
  • Page 16 USER HANDBOOK...

  • Page 17: Operation

    2. OPERATION Before operation of the PS1, check that the instrument is clean and in good condition. Each time you use the PS1 instrument, perform the following operations: 1) Switch instrument ON in fresh air and check the life remaining.

  • Page 18: Switching The Instrument On

    USER HANDBOOK 2.1 SWITCHING THE INSTRUMENT ON Press and hold the RH button for one second to switch the instrument on. The instrument begins its warm-up routine. First, all display segments are briefly shown, the LED’s will flash, the buzzer beeps, and the vibrator will vibrate. An example of an initial screen display is shown in Fig 2.1.
  • Page 19 OPERATION The next screen displays the target gas. The target gas in the example shown, Fig. 2-3, is Hydrogen Sulphide. Fig. 2-3 Target Gas...
  • Page 20 USER HANDBOOK Next, the different alarm level values are shown. See Figures 2-4 to 2-7. Note 1: If any particular alarm is disabled, the screen will show ‘dis.’ (disabled). The ‘L’ and ‘NL’ symbols, at the bottom left hand and bottom right Fig.
  • Page 21 OPERATION Finally, the six digits of the instrument serial number are displayed: • First two digits - small font size, bottom of display • Last four digits - large font size, centre of display In the example shown in Fig. 2-8, the serial number is 120136. Fig.

  • Page 22: Normal Operating Display

    USER HANDBOOK 2.2 NORMAL OPERATING DISPLAY When warm-up is completed successfully, the normal operating display is shown, as in example Fig. 2-9, with the gas value and the remaining life of the instrument shown in the display. 2.2.1. Life Remaining Initially the display will show the life remaining, at the bottom of the screen.

  • Page 23: Switching Display Backlight On

    OPERATION 2.3 SWITCHING DISPLAY BACKLIGHT ON The display screen light can be manually switched on when surveying in poor lighting conditions. Press the RH button once to switch the screen light on. It remains on for three seconds after the last button press and then automatically switches off.

  • Page 24: Clearing The Max / Min Values

    USER HANDBOOK 2.4.1. Clearing the Max / Min Values To clear the maximum (or minimum) reading, simply press and hold the RH button while viewing the maximum (or minimum). The reading is reset to zero (or 20.9% for O2). 2.5 REMOTE SAMPLING Warning (Hand Aspirator): The hand aspirator can be used for indicative sampling, but it must be noted that when using a hand aspirator, a reading error in the region of +/- 20% is possible.

  • Page 25: Switching The Instrument Off

    OPERATION 2.6 SWITCHING THE INSTRUMENT OFF Press and hold both the LH and RH buttons simultaneously to switch the instrument OFF. The instrument screen will now start a countdown from three (3) to OFF as shown in Fig. 2-13. The buttons must be pressed until the display shows OFF, then release the buttons.

  • Page 26: Operator Messages / Fault Flags

    USER HANDBOOK 2.7 OPERATOR MESSAGES / FAULT FLAGS If the sensor or anything else fails, the audible (short beep) • and visual (red LED) alarm activate and the instrument display will show ‘EEEE’ as shown in Fig. 2-14. Switch the instrument OFF then ON again in fresh air. If the fault persists, return the instrument for service.

  • Page 27: Test

    OPERATION 2.8 TEST A self-test can easily be performed, by simply pressing and holding the LH button Briefly, all elements of the display will be shown. The buzzer will beep, the LED’s will flash and the instrument will vibrate. After this, the instrument will return to its normal operation screen. Note: A self-test can only be performed from the normal operation screen with a safe gas concentration.
  • Page 28 USER HANDBOOK 2-12...

  • Page 29: Alarms

    3. ALARMS When the PS1 instrument detects an alarm set-point has been reached, the audible and visual alarm will be activated to alert the user. The instrument will also vibrate in HiHi and LoLo (O only) alarm conditions. A Non-Latching alarm (default) will reset automatically once the reading returns within the pre-set alarm limits.

  • Page 30: Alarm Display

    USER HANDBOOK 3.1 ALARM DISPLAY If an alarm occurs, the type of alarm (e.g. HiHi H S) is indicated at the top of the screen with the current reading on the display, as shown in Fig. 3-1. To switch on the backlight during an alarm, simply press the RH button once.
  • Page 31 ALARMS HiHi LoLo STEL LTEL Part No. Type 63324 10 ppm 5 ppm 10 ppm 20 ppm 62403 20 ppm 10 ppm 63002 23.5% Disabled 19.5% 63424 30 ppm 200 ppm 30 ppm 200 ppm 62404 35 ppm 50 ppm 35 ppm 63524 Disabled...

  • Page 32: Acknowledge Alarm(S)

    USER HANDBOOK 3.2 ACKNOWLEDGE ALARM(S) To acknowledge, i.e. switch off, a latching alarm (configurable option), press and hold the RH button when the gas reading has returned within the pre-set alarm limits. 3.3 MUTE ALARM(S) To mute (i.e. silence) a non-latching alarm, press and hold the RH button when the alarm is sounding.

  • Page 33: Operator Maintenance

    Do not use abrasive materials or strong volatile chemical solutions as these could damage the impact resistant casing. The outer, impact resistant casing of the PS1 instrument may be cleaned using a non-abrasive moist cloth. Rub the cloth over the outer casing to remove any dirt and grime.
  • Page 34 USER HANDBOOK...

  • Page 35: Calibration

    Two methods of calibration are possible: • The fully automatic, PS1 Auto Bump / Calibration Station (Part No. 63450), provides controlled delivery of gas, allowing you to calibrate in a controlled manner and maintain a record of calibration results on a PC.

  • Page 36: Calibration Validity

    This is no guarantee, however, as the precise application of the product is unknown to GMI. Individual codes of practice may dictate shorter periods. Regular checking, by using bump-test procedure, establishes a pattern of reliability and enables the calibration check period to be modified in line with operational experience.

  • Page 37: Bump Test

    CALIBRATION 5.2 BUMP TEST An automatic or manual Bump Test can be performed on the PS1 instrument to test the instrument’s sensor response and alarms. 5.2.1 Automatic Bump Test The PS1 Auto Bump / Calibration Station (GMI Part No. 63450) provides a safe, simple and convenient method of automatically bump testing the instrument.

  • Page 38: Manual Bump Test

    The instrument can be manually bump tested by following the procedure below and using one of the following Field Calibration / Bump Test kits: For H2S, use kit - GMI Part No. 63104, For O2, use kit - GMI Part No. 63106, For CO, use kit - GMI Part No.

  • Page 39: Accessories

    6. ACCESSORIES A range of accessories is available for the following list of PS1 series instruments: Instrument Part No. Sensor Installed 62403 / 63324 0 to 100 ppm Hydrogen Sulphide (H 63002 0 to 25% Oxygen (O 62404 / 63424...
  • Page 40 Field Calibration / Bump Test Kit (gas cylinder, regulator, tubing c/w connector) 63107 Field Calibration / Bump Test Kit (gas cylinder, regulator, tubing c/w connector) 63120 Data Downloading Setup Pack (CD-ROM, interface adaptor, user instructions) For a comprehensive list of accessories and calibration gases, contact your local Distributor or alternatively, GMI.

  • Page 41: Additional Information

    7. ADDITIONAL INFORMATION Training Training courses are available on all GMI products. Contact GMI Marketing Department for further details: Tel: +44 (0) 141 812 3211 Fax: +44 (0) 141 812 7820 e-mail: sales@gmiuk.com World Wide Web Visit GMI web site at...
  • Page 42 USER HANDBOOK...

  • Page 43: Typical Operating Parameters

    A. TYPICAL OPERATING PARAMETERS Typical operating parameters are as follows: Instrument Part No. Gas Type Range Resolution T90 Response Time 62403 / 63324 0 to 100 ppm 1 ppm < 30 secs 63002 0 to 25% 0.1% < 30 secs 62404 / 63424 0 to 500 ppm 1 ppm...
  • Page 44 USER HANDBOOK Humidity: 0 – 98% R.H. non-condensing. Construction / Protection Rating: Moulded polycarbonate / ABS case protected to IP67. Display: LCD with backlighting (Backlighting on demand). Data Sampling System: Sampling rate - 1 minute interval. Stores (1440) logs over a period of 24 hours operation / then re-writes from longest stored log.

  • Page 45: Index

    INDEX BACKLIGHT ON 2-7 Battery Low / Exhausted 2-6 ACCESSORIES 6-1 BUMP TEST 5-3 ACKNOWLEDGE ALARM(S) 3-4 ADDITIONAL INFORMATION 7-1 ADVICE, DISPOSAL ii CALIBRATION 5-1 Alarm, Audible A-2 CALIBRATION VALIDITY 5-2 ALARM DISPLAY 3-2 CLEANING 4-1 ALARMS 3-1 Construction A-2 ALARM(S), ACKNOWLEDGE 3-4 CONSTRUCTION 1-3 ALARM(S), MUTE 3-4...
  • Page 46 USER HANDBOOK DISPLAY, ALARM 3-2 DISPLAY BACKLIGHT 2-7 IDENTIFICATION, INSTRUMENT 1-3 DISPLAY, INSTRUMENT 1-3 INFORMATION, ADDITIONAL 7-1 DISPLAY, OPERATING 2-6 INSTRUMENT DISPLAY 1-3 DISPLAY, SWITCHING BACKLIGHT ON 2-7 INSTRUMENT FEATURES 1-2 DISPOSAL ADVICE ii INSTRUMENT IDENTIFICATION 1-3 INSTRUMENT PART NUMBER / GAS TYPE 1-2 INTRODUCTION 1-1 FAULT FLAGS 2-10 FEATURES, INSTRUMENT 1-2...
  • Page 47 INDEX MAXIMUM / MINIMUM VALUES 2-7 MESSAGES, OPERATOR 2-10 PARAMETERS, OPERATING A-1 MINIMUM VALUES 2-7 PART NUMBER 1-2 MODIFICATION NOTICES i Power Source A-2 MUTE ALARM(S) 3-4 Protection Rating A-2 NORMAL OPERATING DISPLAY 2-6 Rating, Protection A-2 NOTICES, MODIFICATION i Remaining, Life 2-6 NUMBER, PART 1-2 REMOTE SAMPLING 2-8...
  • Page 48 USER HANDBOOK SWITCHING DISPLAY BACKLIGHT ON 2-7 SWITCHING THE INSTRUMENT OFF 2-9 WARRANTY v SWITCHING THE INSTRUMENT ON 2-2 Weight (incl. battery) A-1 System, Sampling A-2 World Wide Web 7-1 TEST 2-11 TEST, BUMP 5-3 TRANSIT iv TYPE, GAS 1-2 TYPICAL OPERATING PARAMETERS A-1 VALIDITY, CALIBRATION 5-2 VIEWING MAXIMUM / MINIMUM VALUES 2-7...
  • Page 50 Head Office Service & Calibration Centre Service & Sales - USA Inchinnan Business Park 25 Cochran Close 4055 Technology Forest Blvd. Renfrew Crownhill The Woodlands Scotland Milton Keynes TX 77381 PA4 9RG MK8 0AJ Tel: +44 (0)141 812 3211 Tel: +44 (0)1908 568 867 Tel: +1 (713) 559 9290 Fax: +44 (0)141 812 7820 Fax: +44 (0)1908 261 056...
