Archgard 27-DVIM22N-2 Installation, Operation And Maintenance Manual

Gas fired vented room heater (direct vent) s/n 260051 and up

Advertisement

INSTALLATION, OPERATION, AND
WARNING: If the information in this manual is not followed
exactly, a fire or explosion may result causing property
damage, personal injury or loss of life.
Do not store or use gasoline or other flammable vapors or
liquids in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
Do not light any appliance
Do not touch any electrical switch: do not use any phone in
your building.
Immediately call your gas supplier from a neighbors phone.
Follow the gas suppliers instructions.
If you can not reach your gas supplier, call the fire
department.
Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE
English and French Installation Manuals available through your
local dealer or visit our website at: www.archgard.com
Les manuels d'installation en anglais et en français son
disponibles chez votre détaillant local ou en visitant notre site
web: www.archgard.com
ARCHGARD FIREPLACE PRODUCTS
7116 Beatty Drive
Mission, BC V2V 6B4 Canada
MAINTENANCE MANUAL
27-DVIM22N-2
GAS FIRED VENTED ROOM HEATER
(DIRECT VENT)
S/N 260051 AND UP
This appliance may be installed in an aftermarket permanently
located, manufactured home (USA only) or mobile home where
not prohibited by local codes.
This appliance is only for use with the type of gas indicated on
the rating plate. This appliance is not convertible for use with
other gases, unless a certified kit is used.
WARNING: If the information in these instructions is not
followed exactly, a fire or explosion may result, causing
property damage, personal injury or loss of life.
200-1227-01
June 29 2016
