Gas fired vented room heater (direct vent)
s/n 260051 and up (40 pages)
Summary of Contents for Archgard EURO 35
Page 1
OPTIMA 35 EURO 35 Gas Fireplace Insert Gas Fireplace Insert Room Heater For use with natural gas or propane SERS NSTALLATION f i r e - p a r t s . c o m PERATION & AINTENANCE WARNING: If the information in this manual is...
CONTENTS Introduction General Information Appliance Description Dimensions and Clearances Installation Instructions 8 - 14 Operation Instructions 15 - 17 Maintenance Trouble Shooting Instructions 19 - 20 Wiring Diagrams Servicing 22 - 24 Replacement Parts Warranty f i r e - p a r t s . c o m CAUTION Due to high temperatures, the appliance should be located out of traffic and away from furniture and draperies.
INTRODUCTION Congratulations for choosing an Archgard fireplace. The Euro 35 is one of the most advanced fireplace insert heaters available. It is solidly designed using the latest technology and manufactured to the highest quality. It is our aim to provide you an appliance with many trouble free years of reliable service.
- ANSI Z21.88a-1999/CSA 2.33a-M99, Vented Gas Fireplace Heaters, - CAN/CGA-2.17-M91, Gas-Fired Appliances for Use at High Altitudes Please contact Archgard Industries Ltd., if you have any questions regarding the certification of this appliance. INSTALLATION CODES This appliance must be installed by a qualified gas appliance installer.
Euro APPLIANCE DESCRIPTION TOP VIEW ON-OFF SWITCH SPILL SAFETY SWITCH f i r e - p a r t s . c o m SLIDING FLUE CONNECTOR FRONT VIEW TOP GRILL GLASS DOOR BRICK PANELS BOTTOM GRILL...
Euro DIMENSIONS AND CLEARANCES APPLIANCE DIMENSIONS With standard aluminum surround 25 5/8” (651 mm) 20 7/8” (530 mm) 16” (406 mm) 22 5/8” (575 mm) 41 1/2” (1054 mm) f i r e - p a r t s . c o m 11 3/8”...
Page 7
Euro DIMENSIONS AND CLEARANCES Cont... WARNING: Failure to position CLEARANCES TO COMBUSTIBLES the parts in accordance with these diagrams or failure to use SIDE VIEW only parts specifically approved with this appliance may result in property damage or personal in- Combustible mantle allow in shaded jury area.
4500 ft. (1400 m) + 35,000 BTU/hr (10,200 watts) less 4% per 1000 ft. (300 m) Please contact your local Archgard dealer or distributor for the appropriate orifice size (i.e. At 6500 ft we recommend a #36 DMS drill size).
Page 9
All gas connections must be checked for gas leaks. ELECTRICAL CONNECTIONS The Euro 35 comes complete with an electrical cord and plug already installed. If you require to run an electrical lead to the appliance instead, follow the instructions listed below.
Page 10
Euro INSTALLATION INSTRUCTIONS Cont... VENTING NOTE: Before lining a chimney, check the condition of the clay tile liner and/or mortar joints and, if necessary, have excessive soot and creosote deposits cleaned. The appliance is equipped with a vent safety shutoff system and a safety control system designed to protect against improper venting of combustion products.
Page 11
Euro INSTALLATION INSTRUCTIONS Cont... SWITCH WIRING SPILL SAFETY SWITCH ON-OFF SWITCH WIRING SPILL SWITCH WIRING WIRE CLIP GROMMET f i r e - p a r t s . c o m SLIDING FLUE ADAPTER SLIDING WARNING: FLUE Maximum clear- ADAPTER ance between front of unit and...
Page 12
Euro INSTALLATION INSTRUCTIONS Cont... SWITCH MOUNTING AND WIRING SPILL SWITCH: The spill switch is located in a critical location to shut of the appliance in the event the draft is in- sufficient. It is located above and in front of the draft hood. Do not tamper with it’s location. In the event of insufficient draft the heat from spilling flue gases shuts off the gas to the burner, after several minutes.
Page 13
COALS EMBERS BURNER FRONT LOG WARNING: Do not place logs in any other configuration than that shown. Under no circumstances are logs to be modified. Do not place foreign or more than the amount supplied by Archgard with the appliance.
Page 14
Euro INSTALLATION INSTRUCTIONS Cont... OPTIONAL BAY DOOR INSTALLATION 1 NOTE: Ensure that the fireplace is turned off and cool, disconnect the power to the unit. 2 Remove the upper grills by pulling the assembly forward. 3 Remove the lower grills by removing the four hex head mounting screws. 4 Remove the two hex head screws from the existing Control Panel Bracket, and pull the assembly out from under the firebox.
Euro OPERATION INSTRUCTIONS FOR YOUR SAFETY, READ BEFORE LIGHTING INITIAL OPERATION • Check that the appliance is properly vented and connected to the gas supply. • Check the logs and branches are properly placed. • Check all external parts, such as grills, door and faceplate are properly attached and fastened.
Page 16
Euro OPERATION INSTRUCTIONS Cont.. AUTOMATIC VALVE START-UP PROCEDURE Set the thermostat, if present, to the lowest level. Press slightly and turn the control knob clockwise to the OFF position and wait 5 minutes; thus allowing any gases to escape which may have accumulated in the combustion chamber. Note: LP gases do not vent upward.
Page 17
Euro OPERATION INSTRUCTIONS Cont.. MANUAL VALVE START-UP PROCEDURE Press slightly and turn the control knob clockwise to the OFF position and wait 5 minutes; thus allowing any gases to escape which may have accumulated in the combustion chamber. Note: LP gases do not vent upward. Then follow step 2 and 3 to establish pilot. Press slightly and turn control knob counterclockwise to PILOT position;...
Euro MAINTENANCE CAUTION : Do not conduct maintenance on the appliance while it is operating or while it is still hot. CLEANING THE APPLIANCE The exterior painted surfaces, glass and gold trims may be cleaned with a soft, non-abrasive cloth and water or a suitable, mild, non-abrasive cleaner.
Euro TROUBLE SHOOTING Please check to make sure the instructions are followed exactly before attempting trouble shooting of the appliance. WARNING: Trouble shooting and servicing of gas and electrical devices of the appliance should only be conducted by a qualified service technician. SYMPTOM ACTION Pilot will not light after...
Page 20
Euro TROUBLE SHOOTING Cont... SYMPTOM ACTION The main burner does not 3. Check to make sure the thermostat is set high enough to turn turn on with the pilot lit. on the appliance. Cont... 4. Check that the remote switch or the thermostat is turned on. 5.
Euro WIRING DIAGRAMS CONVECTION BLOWER SPEED CONTROL 110F (43ºC) N.O. THERMAL SNAP SWITCH LINE CONVECTION BLOWER 120 VAC NEUTRAL ELECTRICAL GROUND AUTOMATIC VALVE OPTIONAL SPARK ELECTRODE PILOT f i r e - p a r t s . c o m THERMOSTAT BURNER THERMOCOUPLE...
Page 22
SERVICING SERVICING UNDER WARRANTY Before servicing, read the terms and conditions of the Archgard warranty at the back of the manual. Contact the Archgard authorized dealer which you have purchase the appliance from and provide him with details of the problem and the installation information which the installer has fill out at the back of the manual.
Page 23
Euro SERVICING Cont... CHANGING MAIN BURNER ORIFICE • Remove the glass door, log branches and the front log. • Unscrew the 2 screws holding the left burner shields between the burner tubes and remove the shield. • Remove the adjustment wing nut and slide the air shutter away from the orifice cap. •...
Page 24
In the event your glass cracks or breaks, it must be replaced by the exact same size and mate- rial. It is made from high temperature ceramic material. See replacement parts list and contact your nearest Archgard dealer. • Remove door and carefully remove all traces of glass and gasket material.
Euro Replacement Parts for EURO 35 Item # Item Description Unit 200-0067 OWNER'S MANUAL, EURO 35 1 EA 300-0030 HINGE, BRASS #7629-BB SPRING TO CLOSE 2 EA 300-0034 LATCH, DOOR 1 11/16 X 1 3/16 2 EA 301-0021 ORIFICE--CAP #50...
This Limited Warranty is made by ARCHGARD INDUSTRIES LTD. hereinafter referred to as "Archgard". Archgard warrants to the original consumer that the gas burning fireplaces will be free from defects in materials and workmanship under normal use and service, for a lifetime.
