- Page 1 Installation Guide 52700 Guide d’installation Einbauanleitung Guida all’installazione Installatiegids Installationsmanual Guía de instalación...
- Page 2 CAUTION – BURN HAZARD Motor case could get hot during extended operation. Prolonged contact with skin may cause a burn. Model Voltage Open Switch Inlet Circuit Flow Max PSI Strainer Breaker Draw (bar) (LPM) 52700- xx92 (26.5) (5.5) 52700- xx94 (26.5) (5.5)
-
Page 3: Installation
Mounting: Horizontal Vertical Do Not Submerge Mounting Mounting in Bilge Water Installation: 1: Remove shipping plugs from the pump ports. 2: Connect hose to snap fittings provided (A) and strainer (B). Use 3/4” (19 mm) braided reinforced hose and a worm clamp for hose connection to all fittings. - Page 4 Nº de Voltaje Amperaje Caudal Interruptor Filtro de Interruptor modelo máx abierto PSI máx entrada Maestro de (bar) Corriente (LPM) Eléctrica 52700- 12 V SÍ SÍ xx92 (26,5) (5,5) 52700- 24 V SÍ xx94 (26,5) (5,5)
-
Page 5: Instalación
Montaje: Montaje Montaje No sumergir en horizontal vertical agua de sentina Instalación: 1: Retire los tapones de transporte de las conexiones de la bomba. 2: Conecte la manguera a las conexiones a presión provistas (A) y al filtro (B). Use una manguera con trenzado de refuerzo de 19 mm (3/4”) y una abrazadera tipo sinfín... -
Page 6: Dimensional Drawing
Length of Conductor from Source of Current to Device and Back to Source – Feet EXPLODED VIEW Key Description 52700 - 0092 52700 - 0094 Key Description 52700 - 0092 52700 - 0094 Pressure Switch 18753 - 5019 18753 - 5019 5... - Page 7 35 AMP Main Breaker PN#91006464A Helm Console Panel Switch Main 7 Inches Max Battery Switch 35 AMP Main Breaker Butt Splice Red (+) Ring Terminals 5/16" Eye Black (–) Com Bus – 12V DC Battery Interruttore del pannello Interruttore della Console disgiuntore di al timone diramazione...
- Page 8 Die nachstehend beschriebenen Produkte unterliegen einer einjährigen Gewährleistung. Die Gewährleistungsbedingungen können bei Jabsco angefordert werden. I prodotti qui descritti sono coperti dalla garanzia Jabsco limitata di un anno, disponibile per la visione su richiesta. De hierin beschreven producten worden aangeboden met de beperkte Jabsco garantie van één jaar.
