- Page 1 Pixel Bar 8 COB ORDERCODE 41266 Highlite International B.V. Vestastraat 2 6468 EX Kerkrade The Netherlands Phone: +31 45-5667700...
- Page 2 For more information: iwant@showtec.info You can get some of the best quality, best priced products on the market from Showtec. So next time, turn to Showtec for more great lighting equipment. Always get the best -- with Showtec ! Thank you!
-
Page 3: Table Of Contents
Showtec Showtec Pixel Bar 8 COB ™ Product Guide Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................4 Rigging .................................... 4 Return Procedure ................................5 Claims ....................................5 Description of the device ..............................6 Overview ..................................6 Backside ..................................6 Set Up and Operation ............................... -
Page 4: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: • Showtec Pixel Bar 8 COB with IEC powercable 1,35m • User manual LED Expected Lifespan LEDs gradually decline in brightness over time. - Page 5 Allow time to cool down, before replacing lamp. The user is responsible for correct positioning and operating of the Pixel Bar 8 COB . The manufacturer will not accept liability for damages caused by the misuse or incorrect installation of this device.
-
Page 6: Operating Determinations
Always let the installation be carried out by an authorized dealer ! Procedure: If the Pixel Bar 8 COB is lowered from the ceiling or high joists, professional trussing systems have to be used. Use a clamp to mount the Pixel Bar 8 COB , with the mounting-bracket, to the trussing system. -
Page 7: Return Procedure
Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. Call Highlite 0031-455667723 or mail aftersales@highlite.nl and request an RMA prior to shipping the fixture. -
Page 8: Description Of The Device
Description of the device Features The Showtec Pixel Bar 8 COB is a light effect with high output and great effects. designed for indoor use. • Very powerful batten which uses the latest technology COB RGB Leds. • Due to this new technology it is possible to achieve a very high light output with a wide beam angle, without getting a lot of uncomfortable glare. -
Page 9: Set Up And Operation
Before plugging the unit in, always make sure that the power supply matches the product specification voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa. Remove all packing materials from the Pixel Bar 8 COB . Check that all foam and plastic padding is removed. -
Page 10: Multiple Pixel Bars (Dmx Control)
Multiple Pixel Bars (DMX Control) 1. Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation. 2. Always use a safety cable (ordercode 70140 / 70141). Use a 3-p XLR cable to connect the Pixel Bars and other devices. Link the units as shown in (figure 4), Connect a DMX signal cable from the first unit's DMX "out"... -
Page 11: Fixture Linking
Fixture Linking You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to run synchronized shows on two or more fixtures set to a master/slave operating mode. The combined number of channels required by all the fixtures on a serial data link determines the number of fixtures the data link can support. -
Page 12: Control Panel
Control Panel Fig. 5 A. LCD Display D. UP button B. MODE Button E. DOWN button C. SETUP button DMX Control Mode The fixtures are individually addressed on a data-link and connected to the controller. The fixtures respond to the DMX signal from the controller. DMX Addressing The control panel on the front side of the Pixel Bar allows you to assign the DMX fixture address, which is the first channel from which the Pixel Bar will respond to the controller. -
Page 13: Menu Overview
Menu Overview 1. DMX Address 2. Slave 3. Static Colors 4. Built-in Programs 5. Auto Program 6. Sound-controlled... -
Page 14: Main Menu Options
Static Colors Built-in Programs Auto Sound-controlled The Pixel Bar 8 COB will only show its version number at start-up ! 1. DMX Mode With this menu you can set the DMX address. 1) Press the MODE button, until the display shows 2) You can choose 512 different DMX addresses. -
Page 15: Static Color Mode
3. Static Color Mode 1) Press the MODE button on the device, until the display shows 2) Use the UP/DOWN buttons to change the static colors (Red, Green, Blue). Press MODE to go 1 step back. You can combine RED, GREEN and BLUE to create an infinite range of colors (0-255). Set the value of the red LEDs (0-255). -
Page 16: Dmx Channels
DMX Channels 2 Channels Channel 1 Built-in Programs 8-15 Red + Green 16-23 Green 24-31 Green + Blue 32-39 Blue 40-47 Red + Blue 48-55 Red + Green + Blue 56-63 Program 1 64-71 Program 2 72-79 Program 3 80-87 Program 4 88-95 Program 5... -
Page 17: Channels
3 Channels Channel 1 – Red 0-255 Gradual adjustment Red from 0 – 100% Channel 2 – Green 0-255 Gradual adjustment Green from 0 – 100% Channel 3 – Blue 0-255 Gradual adjustment Blue from 0 – 100% 5 Channels Channel 1 –... -
Page 18: Channels
12 Channels Channel 1 – Red, Block 1-2 0-255 Gradual adjustment Red from 0 – 100% Channel 2 – Green, Block 1-2 0-255 Gradual adjustment Green from 0 – 100% Channel 3 – Blue, Block 1-2 0-255 Gradual adjustment Blue from 0 – 100% Channel 4 –... -
Page 19: Channels
24 Channels Channel 1 – Red, Block 1 0-255 Gradual adjustment Red from 0 – 100% Channel 2 – Green, Block 1 0-255 Gradual adjustment Green from 0 – 100% Channel 3 – Blue, Block 1 0-255 Gradual adjustment Blue from 0 – 100% Channel 4 –... - Page 20 Channel 17 – Green, Block 6 0-255 Gradual adjustment Green from 0 – 100% Channel 18 – Blue, Block 6 0-255 Gradual adjustment Blue from 0 – 100% Channel 19 – Red, Block 7 0-255 Gradual adjustment Red from 0 – 100% Channel 20 –...
-
Page 21: Maintenance
Maintenance The Showtec Pixel Bar requires almost no maintenance. However, you should keep the unit clean. Otherwise, the fixture’s light-output will be significantly reduced. Disconnect the mains power supply, and then wipe the cover with a damp cloth. Do not immerse in liquid. Wipe lens clean with glass cleaner and a soft cloth. - Page 22 Problem Probable cause(s) Remedy No power to the fixture • Check that power is switched on One or more and cables are plugged in. fixtures are Primary fuse blown. • Replace fuse. completely dead. Fixtures reset The controller is not connected. •...
-
Page 23: Product Specification
Product Specification Model: Showtec Pixel Bar 8 COB • Very powerful batten which uses the latest technology COB RGB Leds. • Due to this new technology it is possible to achieve a very high light output with a wide beam angle, without getting a lot of uncomfortable glare.
