- Page 1 Instruction Manual Ice Dispenser Models DB-130H DB-200H hoshizakiamerica.com Issued: 4-18-2016...
- Page 2 Should the reader have any questions or concerns which have not been satisfactorily addressed, please call, send an e-mail message, or write to the Hoshizaki Technical Support Department for assistance. Phone: 1-800-233-1940; (770) 487-2331 Fax: 1-800-843-1056;...
-
Page 3: Table Of Contents
Important Safety Information ....................4 I. Specifications ........................6 A. Electrical Data ....................... 6 B. Dimensions/Connections ....................7 1. DB-130H ........................7 2. DB-200H ........................8 II. Installation and Operating Instructions ................9 A. Location ........................9 B. Checks Before Installation ................... 10 C. -
Page 4: Important Safety Information
Important Safety Information Throughout this manual, notices appear to highlight attention to situations that can result in death, serious injury, and damage to the appliance or property. WARNING Indicates a hazardous situation that can result in death or serious injury. NOTICE Indicates a situation that can result in damage to the appliance or property. - Page 5 WARNING, continued • Do not use combustible spray or place volatile or flammable substances near the appliance. Explosion, fire or damage to the appliance can result. • Keep the area around the appliance clean. Dirt, dust, or insects in the appliance can cause harm to individuals or damage to the appliance.
-
Page 6: Specifications
The nameplate provides electrical data. The nameplate is located on the rear panel. For certification marks, see the nameplate. We reserve the right to make changes in specifications and design without prior notice. Model Number DB-130H DB-200H AC Supply Voltage 115/60/1 115/60/1 Amperes 1.4 AMPS 1.4 AMPS... -
Page 7: Dimensions/Connections
B. Dimensions/Connections 1. DB-130H Units: mm (in.) DB-130H 1346 (53) 73 (2-7/8) 589 (23-1/4) 684 (26-7/8) 48 (1-7/8) 457 (18) 558 (22) 155 (6-1/8) 13 (1/2) 395 (15-1/2) 61 (2-3/8) Rear 1260 (49-5/8) Side Power Supply Drain Outlet 3/4" FPT... -
Page 8: Db-200H
2. DB-200H Units: mm (in.) DB-200H 1346 (53) 73 (2-7/8) 589 (23-1/4) 684 (26-7/8) 48 (1-7/8) 666 (26-1/4) 762 (30) 152 (6) 13 (1/2) 395 (15-1/2) 61 (2-3/8) 1260 (49-5/8) Side Rear Power Supply Drain Outlet 3/4" FPT Fig. 2... -
Page 9: Installation And Operating Instructions
Ensure that the icemaker's clearance requirements are met. Note that the ice dispenser is serviced from the left side of the DB-130H and from the right side of the DB-200H. • The location should provide a firm and level foundation for the equipment. -
Page 10: Checks Before Installation
B. Checks Before Installation NOTICE The DB-130H ice dispenser is designed for use with 22" and the DB-200H ice dispenser for use with 22" or 30" Hoshizaki modular crescent cube icemakers. The use of this ice dispenser in combination with any other icemaker cannot be recommended. -
Page 11: Setup
3) Adjust the dispenser legs to level the ice dispenser in both the left-to-right and front-to-rear directions. 4) If required, install an adapter kit or top kit. Contact your local Hoshizaki distributor for recommendations. NOTICE! Use care to avoid damage to ice dispenser unit components when attaching kits. -
Page 12: Electrical Connection
• Electrical connection must be made in accordance with the instructions on the "WARNING" tag, provided with the pig tail leads in the junction box of the DB-130H/DB-200H. See Fig. 7. NOTE: An electrical permit and the services DB-130H... -
Page 13: Drain Connection
F. Drain Connection WARNING Drain connections must be installed in accordance with applicable national, state, and local regulations. Ice Dispenser Drain Outlet Minimum Ice Dispenser Drain Line Size 3/4" Female Pipe Thread (FPT) 3/4" Nominal ID Hard Pipe or Equivalent •... -
Page 14: Final Checklist
G. Final Checklist WARNING CHOKING HAZARD: Ensure that all components, fasteners, and thumbscrews are securely in place after installation. Verify that nothing has fallen into the ice dispenser bin. 1) Is the appliance level? 2) Is the appliance in a site where the ambient temperature is within 45°F to 100°F (7°C to 38°C) all year around? 3) Is there at least 6"... -
Page 15: Startup
H. Startup WARNING All parts are factory-adjusted. Improper adjustments will adversely affect safety, performance, component life, and warranty coverage. 1) After installing the icemaker per the instructions provided with the icemaker, start up the icemaker and allow at least three batches of ice production. 2) Place a container under the spout, then press the ice dispense button. -
Page 16: Maintenance
III. Maintenance The appliance must be maintained in accordance with the instruction manual and labels provided. Consult with your local Hoshizaki Certified Service Representative about maintenance service. WARNING • Only qualified service technicians should service the appliance. • Turn off the power supply before servicing. -
Page 17: Cleaning And Sanitizing Instructions
Be sure that the icemaker is secured and cannot fall. 6) Dilute 5 oz. (150 ml) of Hoshizaki "Scale Away" with 1.0 gal. (3.8 l) of warm water. This is a minimum amount. Make more solution if necessary. IMPORTANT! For safety and maximum effectiveness, use the solution immediately after dilution. - Page 18 2. Sanitizing Procedure 1) Dilute 0.5 oz. (15 ml) of a 5.25% sodium hypochlorite solution (chlorine bleach) with 1.0 gal. (3.8 l) of warm water. This is a minimum amount. Make more solution if necessary. IMPORTANT! For safety and maximum effectiveness, use the solution immediately after dilution.
-
Page 19: Preparing The Ice Dispenser For Periods Of Non-Use
IV. Preparing the Ice Dispenser for Periods of Non-Use During extended periods of non-use, extended absences, or in sub-freezing temperatures, follow the instructions below. When the appliance is not used for two or three days under normal conditions, it is sufficient to move the icemaker and ice dispenser power switch's to the "OFF"... - Page 20 618 Hwy. 74 South, Peachtree City, GA 30269 USA (P) 770.487.2331 (F) 770.487.3360 hoshizakiamerica.com 1A4155-010...
