Page 1: Quick Start Guide
Voyager 15 Quick start guide Saint Petersburg, 2016... - Page 2 Voyager 15. Quick start guide. Preparing to use the device Before starting to work with GPS-tracker, make the following steps: • Open the bottom lid. • Put your SIM Cards into SIM holder, Please make sure, that your SIM Card does not have a password.
- Page 3 Voyager 15. Quick start guide. • Open the top lid. • Put the Hard Drive inside. www.ritm.ru/en...
- Page 4 Voyager 15. Quick start guide. GPS-tracker connections • Put the GPS antenna into the GPS slot. • Put the GSM antenna into the GSM slot. • If it is needed, please connect your cameras into slots 1,2,3 and 4. • The Power slot has contacts for +12/+24V, GND, and contacts for each camera.
- Page 5 Voyager 15. Quick start guide. Download the software • Go to our website www.ritm.ru, in the right top corner you can choose the english language. • Go to “Downloads”, open the “Сommon software for the set-up of all of Ritm’s devices”, click on link and...
- Page 6 Voyager 15. Quick start guide. Configuration of GPS-tracker In order to configure your device you must connect either through LAN or via Wi-Fi. We will configure via Wi-Fi. When you will power up your device, after a few minutes you will see the fast flashing GLONASS/GPS and GSM/Wi-Fi LED light.
- Page 7 Voyager 15. Quick start guide. Open downloaded software, you will see a picture like this. You can choose the language in the right bottom corner. Choose connection type: (you need IP - direct connection to a device). Type IP address and Port as follows: IP - 192.168.42.1,...
- Page 8 You should go to Device Details, where you can find common information about your Voyager 15. Here you should copy the IMEI of your Voyager 15, and check the registration in the GSM network. If you have bad reception conditions of GSM, or SIM card doesn’t work, you will see, that SIM has “No registration in GSM network”.
- Page 9 Voyager 15. Quick start guide. You have to configure your GPRS connection, go to section “GPRS parameters” and fill it according to your own settings, you can learn the settings from your GSM provider. Make sure, there is no tick for “Specify APN configuration automatically”.
- Page 10 2. Type the number of your object and leave the password as default. 3. Type in the box “IP address of the main coordinate receipt server or its domain name” address dev1.eu.ritm.ru and in the box “Port of the main coordinate receipt server” port number 9426.
- Page 11 Voyager 15. Quick start guide. Now, to configure your video, you have to make your device connect to Wi-Fi. Open “WiFi parameters”, and connect to your Wi-Fi regular way, choose the name and type the password. Go to iVideon parameters and copy the MAC-address of your device.
- Page 12 Voyager 15. Quick start guide. Go to iVideon website, https://www.ivideon.com, Create an account and sign up. www.ritm.ru/en...
- Page 13 Voyager 15. Quick start guide. Now you can add your device to iVideon service. Click “Add a camera or DVR”, or Plus. At first page, choose the “iVideon-powered camera”. www.ritm.ru/en...
- Page 14 Voyager 15. Quick start guide. Type MAC-address of your device. Now you should see picture like that. In your device iVideon settings will be changed automatically. www.ritm.ru/en...
- Page 15 Go to “Service” and click “Format” to make your device work with space on your drive (HDD or SD Card). GeoRitm Now you are ready to go to www.eu.ritm.ru. You can choose language in the top right corner. Click on registration button. www.ritm.ru/en...
- Page 16 Voyager 15. Quick start guide. Fill in the registration form. After that you will get the e-mail for authorization, follow the link in that email and you will see this page. www.ritm.ru/en...
- Page 17 Voyager 15. Quick start guide. Click on the button “Open Monitoring interface”. You can select “Run Object Add Wizard automatically”, or open this wizard later. Now you should see the main page of GeoRitm interface. If you didn’t open the Add Object Wizard yet, you can click on a plus.
- Page 18 Voyager 15. Quick start guide. Add group and object. You will see this page. Click “Next”. Here you should put the IMEI, which you took from the settings of Voyager 15. Click “Next”. www.ritm.ru/en...
- Page 19 Voyager 15. Quick start guide. Click “Next” again. If you see the page, server now identified your Voyager 15. Click “Next”. Here you can give a name for your object and add it to the group. Every object should be in one of the groups. You have 2 default groups: Vehicles and Real Estate.
- Page 20 Voyager 15 on the map. Remember, that GPS should have good reception conditions. You can click on the image of your Voyager 15 on map and see the events, track, and general report or object’s card (you can open it from the left menu as well).
- Page 21 Voyager 15. Quick start guide. When you will open the Object Card, choose the “Video” and type your E-mail and password from www.ivideon.com. Click “Apply”, then click connect, you should see the list of cameras, and the picture of choosen camera.
- Page 22 Voyager 15. Quick start guide. You can choose the “Equipment” section and under the picture of Voyager 15 you will see the link “Setup a device”. It will open the same wizard settings of your Voyager 15, but you can now configure it without USB connection with your PC.
