- Page 1 Air Conditioners & Heat Pumps 7,000-15,000 BTUH Cooling with Electric Heat EKTC07-2G EKTC07-1G EKTC09-1G EKTC09-2G EKTC12-1G EKTC12-2G EKTC15-2G EKTC15-1G Heat Pump with Electric Heat EKTH07-2G EKTH07-1G EKTH09-1G EKTH09-2G EKTH12-2G EKTH12-1G EKTH15-1G EKTH15-2G AITONS EQUIPMENT • Guelph, ON N1H 6H9 • 1-888-744-2911 • www.aitons.com...
-
Page 2: Table Of Contents
■ ......1 SAFET Y CONSIDERATIONS OWNER’S MANUAL AITONS EQUIPMENT Packaged Terminal A/C ■ ......1 GENERAL INFORMATION ■ ........2 UNIT FEATURES TABLE OF CONTENTS ......... 4 ■ ELECTRICAL DATA Safety Considerations ......................2 ■ ........5 INSTALLATION General Information ......................2 ■... -
Page 3: Safety Considerations
AITONS EQUIPMENT OWNER’S MANUAL Packaged Terminal A/C Safety Considerations Recognize safety information. This is the safety-alert symbol .When you see this symbol on the unit and in instructions or manuals, be alert to the potential for personal injury. Understand these signal words: DANGER, WARNING, and CAUTION. These words are used with the safety-alert symbol. -
Page 4: Unit Features
OWNER’S MANUAL AITONS EQUIPMENT Packaged Terminal A/C UNIT FEATURES This unit has many exciting features which are different than those found on standard PTAC models. The owner must be familiar with these features in order to fully understand the operation and capability of the unit. -
Page 5: Unit Nomenclature
AITONS EQUIPMENT OWNER’S MANUAL Packaged Terminal A/C Unit Features CONTINUED • • °F or °C—The unit can display in either °F or °C • Indoor Temperature Sensor Biasing —Optimize the room temperature sensor reading to your exact application (one for cooling and another for heating). - Page 6 OWNER’S MANUAL AITONS EQUIPMENT Packaged Terminal A/C ELETRICAL DATA WARNING ELECTRICAL SHOCK HAZARD Failure to follow this warning could result in personal injury or death and/or property damage. DO NOT alter cord or plug or use an extension cord. POWER CONNECTION OPTIONS Appropriate power cord accessory kit is determined by the voltage, and amperage of the branch circuit.
-
Page 7: Installation
AITONS EQUIPMENT OWNER’S MANUAL Packaged Terminal A/C INSTALLATION Proper installation is the responsibility of the installer. Product failure due to improper installation is not covered under the Warranty. See the warranty card enclosed with your unit for more details. CHASSIS INSTALLATION Units are shipped without a sleeve. - Page 8 OWNER’S MANUAL AITONS EQUIPMENT Packaged Terminal A/C RETROFIT SLEEVE PREPARATION IMPORTANT: Inspect wall sleeve thoroughly prior to installation. Manufacturer does not assume responsibility for costs or damages due to defects in sleeve or for improper installation. NOTE: See installation instructions included with wall sleeve WARNING for information on installation.
- Page 9 AITONS EQUIPMENT OWNER’S MANUAL Packaged Terminal A/C INSTALL UNIT INTO WALL SLEEVE 1. Carefully remove shipping tape from the front panel and vent door. See Fig. 5. 2. Remove shipping screw from the vent door, if present. See Fig. 6.
-
Page 10: How To Connect
OWNER’S MANUAL AITONS EQUIPMENT Packaged Terminal A/C HOW TO CONNECT IMPORTANT: Please read following electrical safety data carefully. WARNING ELECTRICAL SHOCK AND/OR UNIT OPERATION AND DAMAGE HAZARD Failure to follow this warning could result in personal injury or death and/or unit operation and damage. -
Page 11: System Configuration
AITONS EQUIPMENT OWNER’S MANUAL Packaged Terminal A/C SYSTEM CONFIGURATION VENTILATION CONTROL The ventilation control lever is located at left side of unit, behind front panel. NOTE: The vent door shipping hardware must be removed before using vent control lever. See Installation Instructions. - Page 12 OWNER’S MANUAL AITONS EQUIPMENT Packaged Terminal A/C DIP SWITCHES Auxiliary dip switch controls are located behind front panel, through an opening below the control panel. To access, re- move front panel. See Fig. 7. Dip switches are accessible without opening the control box.
- Page 13 AITONS EQUIPMENT OWNER’S MANUAL Packaged Terminal A/C KEYPAD CONFIGURATION shows the set point or room air temperature, and to set controls for sensor biasing. Changes do not take affect until power is cycled on the unit. Cycle power to unit. Press and hold the Fan Speed Button and the COOLER button for 5 continuous seconds, within 30 Press and release the Fan Speed button.
-
Page 14: Operation
OWNER’S MANUAL AITONS EQUIPMENT Packaged Terminal A/C OPERATION ABOUT THE CONTROLS ON YOUR UNIT NOTE: In case of a power failure, the unit will remember the last programmed settings and will restart to those settings. IMPORTANT and windows closed. Room humidity will decrease and moisture will evaporate as the unit operates. -
Page 15: Care And Cleaning
AITONS EQUIPMENT OWNER’S MANUAL Packaged Terminal A/C CARE AND CLEANING FRONT PANEL AND CASE Turn unit off and disconnect power supply. To clean, use water and a mild detergent. DO NOT use bleach or abrasives. Some commercial cleaners may damage the plastic parts. -
Page 16: Preventative Maintenance
OWNER’S MANUAL AITONS EQUIPMENT Packaged Terminal A/C PREVENTATIVE MAINTENANCE several times during each year. During regular unit inspection and maintenance, follow the guidelines below: • Clean both sides of outdoor coil. (Never use high pressure spray on coils.) • •... -
Page 17: Troubleshooting
AITONS EQUIPMENT OWNER’S MANUAL Packaged Terminal A/C TROUBLESHOOTING TROUBLESHOOTING POSSIBLE CAUSES SOLUTIONS UNIT DOES NOT START • Unit may have become unplugged • Check that plug is plugged securely in wall receptacle. • Fuse may have blown Note :Plug has a test/reset button on it. Make sure that the plug Circuit breaker may have tripped •... - Page 18 AITONS EQUIPMENT • Guelph, ON N1H 6H9 • 1-888-744-2911 • www.aitons.com 9/2013...
