Kronen KW-81 A Instruction Manual

Vegetable washing-drying machine
Hide thumbs
Table of Contents

Advertisement

Quick Links

Vegetable washing-
drying machine
KW-81 A
Type:
Translation of the
Original Instruction Manual
English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KW-81 A and is the answer not in the manual?

Questions and answers

Related Manuals for Kronen KW-81 A

Summary of Contents for Kronen KW-81 A

  • Page 1 Vegetable washing- drying machine KW-81 A Type: Translation of the Original Instruction Manual English...
  • Page 2 Instruction Manual KW-81 A Instruction Manual KW-81 A Version: 1.4 Date of release: 24.07.2014...

  • Page 3: Table Of Contents

    Instruction Manual KW-81 A Contents General Information ..................... 4 Safety ........................... 8 Technical Characteristics ..................10 Installation and Function .................... 11 Transportation and Packaging ................16 Installation and Initial Operation ................17 Use and Operating ..................... 21 Malfunctions ....................... 30 Maintenance ......................

  • Page 4: General Information

    Instruction Manual KW-81 A 1. General Information Always keep the instruction manual and all the other documents near the vege- table slicer. Before using the machine the first time, make sure that you read the instruction manual first. Explanation of the symbols used in the documents Attention, you have to follow the instructions to avoid harm for you and the machine.
  • Page 5 Instruction Manual KW-81 A Defects and Claims 1. Claims based on material defects shall be subject to a limitation period of 2 years after surrender of the merchandise. The Seller does not assume any liability for material defects in pre-owned merchandise.
  • Page 6 5. The warranty services described above are subject to the condition that all required maintenance and care work is carried out by a customer service au- thorized by Kronen Küchengeräte GmbH and that any and all care and opera- tional instructions from Kronen Küchengeräte GmbH have been followed.
  • Page 7 Instruction Manual KW-81 A 6. Kronen Küchengeräte GmbH grants a function warranty of 6 months for each and every original Kronen Küchengeräte spare part, provided that it has been installed correctly. Kronen Küchengeräte GmbH shall provide an original part in the event of failure.

  • Page 8: Safety

    Instruction Manual KW-81 A Safety General Sources of Danger Wrongful use or limited knowledge of the safety instruc- tions could result in accidents and injuries on hands and fingers. That is why, we advise you to respect and follow the safety instructions.
  • Page 9 Instruction Manual KW-81 A Intended Use The vegetable washing-drying machine is a technical tool which exclusively should be used for its’ intended purpose. Sie ist ausschließlich dazu bestimmt um Lebensmittel zu Reinigen. Dazu kön- nen Sie aus verschiedenen Programmen auswählen.

  • Page 10: Technical Characteristics

    Instruction Manual KW-81 A Technical Characteristics Weight: gross 124 kg 118 kg Dimensions: 720 x 715 x 910 mm Connected load: Line voltage 230 V Mains frequency 50 Hz Electricity Vibrations: vibrations are possible but insignificant Requirements for intended place:...

  • Page 11: Installation And Function

    Instruction Manual KW-81 A Installation and Function With mounted revolving basket the vegetable washing machine cleans foods. These are to be inserted into the revolving basket and are cleaned with water. After that, it is possible with centrifuge the revolving basket to dry the food.
  • Page 12 Instruction Manual KW-81 A Parts and Description  Revolving basket (1): The revolving basket is filled with food to be washed.  Lid (2): The lid closes the washing chamber to the outside. It protects from accidental reaching inside and pouring out of water.
  • Page 13 Instruction Manual KW-81 A  Assembled Parts Revolving basket Water supply tap Extensible shower Main switch Tank drain button Cycle pushbutton Digital display (times and programs) Washing program selection + Washing program selection - Pushbutton programmer Adjustable feet Washing flow regulator...
  • Page 14 Instruction Manual KW-81 A Operating Elements Auf dem Bedienfeld befinden sich verschiedene Taster und Anzeigen.  Main switch (A): This button is used to turn on and off the machine.  Tank drain button (B): By pressing this button the washing chamber is emptied.
  • Page 15 Instruction Manual KW-81 A Safety Appliance The safety appliance consists of:  Starting the machine by pushing green button (5).  You can only start the vegetable washing-drying machine if the lid (2) is closed. If you open the lid (2) the vegetable washing-drying machine automatically turns off.

  • Page 16: Transportation And Packaging

    Instruction Manual KW-81 A Transportation and Packaging Always transport the vegetable washing-drying machine in the intended box. Always transport the machine upright and make sure vegetable washing-drying machine is secured. In case there is more than one vegetable washing-drying machine on the pallet do not put another pallet on top of it.

  • Page 17: Installation And Initial Operation

    Instruction Manual KW-81 A Installation and Initial Operation For the Installer The installation and initial operation must be made by a qualified expert or your local customer service. The working place has to fulfill certain requirements: Horizontal and flat Not slippery Water inlet 3/4"...
  • Page 18 Instruction Manual KW-81 A Electrical connection After you placed the slicer on the table plug in the machine in the intended out- let. The mains plug has to be viewed and easily accessible at any time by the operator. Before you do that, make sure that the required specifications on the label are fulfilled.
  • Page 19 Instruction Manual KW-81 A Parameters' programming modification Make sure that the main switch is on. Press at the same time button "E" ("-" und "+") and then give power to the machine by pressing button "A" to position ON. Always pressing buttons "E“ wait for 3 seconds till on the display "FACTORY PARAMETERS"...
  • Page 20 Instruction Manual KW-81 A For the user Before the first use make sure you cleaned the slicer. Follow the instructions in chapter “7 Use and Operating” passage cleaning. Check the following points with not filled revolving basket Check if you can turn on the machine when the lid is open.

  • Page 21: Use And Operating

    Instruction Manual KW-81 A Use and Operating “To-do-list” before operating the machine Make sure the slicer is clean especially in those areas that come in contact with the food For example: the inside of the lid (2), the washing chamber and the revolving basket (1).
  • Page 22 Instruction Manual KW-81 A Washing of vegetables in leaves Strip and choose carefully vegetables and put vegetables in leaves in- to the basket (1) with large meshes (max. 2,5 - 3 kg), place the basket and concerning locked cover, inside the machine and close the lid (2).
  • Page 23 Instruction Manual KW-81 A To change cycle push button "C" and select the new program using buttons "E" (+,-). Push again button "C". To reset the cycle which has already been started keep button "C" pushed for 3 seconds. At the end of the cycle the display shows "End of program" and the total time of a complete washing cycle.
  • Page 24 Instruction Manual KW-81 A Soft washing By selection programs "6" and "7" you can have a complete, soft washing cycle. During this phase the pump does not work and the vegetables get washed just by immersion and rotation into water.
  • Page 25 Instruction Manual KW-81 A Diagram for filling Table 2...
  • Page 26 Instruction Manual KW-81 A Programming To have access to the personalized washing and drying time programs you have to do the following: Choose the washing program which has to be modified by pushing the buttons "E" +/-. Keep the programming button "F" pushed for 3 seconds.
  • Page 27 Instruction Manual KW-81 A Cleaning Before you use the vegetable washing-drying machine the first time make sure you clean it thoroughly. Also, clean the machine multiple times during the day after use. Always use standard cleansers for cleaning the kitchen appliances.
  • Page 28 Instruction Manual KW-81 A Useful hints for stainless steel maintenance Stainless steel is so called because it is not affected by oxidation; this is due to a thin molecular layer of oxide on the surface which protects against further oxidation. There are, however, substances which can modify or destroy this...
  • Page 29 Instruction Manual KW-81 A Rust: Water supply pipes inevitably convey particles of rust dissolved in the water especially in new installation plants or when taps are opened after a period of inactivity. These iron deposits must not be allowed to remain on the stainless steel since they produce rust by contamination.

  • Page 30: Malfunctions

    Instruction Manual KW-81 A Malfunctions Safety instructions In case of unfamiliar noises or decreasing power turn of the machine immediately. In case of blockage turn of the vegetable washing-drying machine and unplug the machine from the water and power supply. After doing this you can try to remove the blocking material.
  • Page 31 Instruction Manual KW-81 A Error Correction Problems Causes Solutions  Main switch is switched  Put ON the main The machine doesn't catch. off. switch.  Insufficient pressure  Act on flow regulator. Insufficient Washing  Insufficient time  Increase wash time.

  • Page 32: Maintenance

    Instruction Manual KW-81 A Maintenance Safety Instructions Maintenance, if not specifically mentioned, is not to be done by the user. Maintenance is done by customer ser- vice only. Maintenance Schedule Once a week, the user needs to check all safety devices.
  • Page 33 Instruction Manual KW-81 A Support / Customer Service / Hotline Sales Department and customer service: Kronen Küchengeräte GmbH Gewerbestr. 3 D-77731 Willstätt Phone: +49 (0) 78 54/96 60-0 Fax: +49 (0) 78 54/96 60-50 info@kronen-germany.de Local Sales Department and customer service:...

  • Page 34: Appendix

    Manufacturer : KRONEN Küchengeräte GmbH D-77731 Willstätt Gewerbestraße 3 declares that the following product: Product name: Vegetable washing-drying machine KW-81 A Serial Number: ________________________ conform to the guideline mentioned on top - including the changes of the statement at this point of time.
  • Page 35 Instruction Manual KW-81 A Circuit plan...

  • Page 36: Index

    Instruction Manual KW-81 A Index Circuit plan ....................... 35 Connected load ....................10 Customer service ..................... 33 Declaration of Conformity ................. 34 Defects and Claims .................... 5 Disposal ......................7 Error Correction ....................31 Included in delivery ................... 11 Installation ......................17 Intended place ....................
