Briggs & Stratton 135202 Service Manual

For Briggs & Stratton Discount Parts Call 606-678-9623 or 606-561-4983
SERVICE ENGINE
In most cases, the Original Type numbers shown may be replaced by a Service Type Number without making any changes. Necessary changes of engine parts
such as crankshafts, reduction parts, blower housings, etc., are noted. Other differences, such as mufflers, elbows, deflectors, etc., are not listed but are very
important for safety and engine performance. Be sure the exhaust system on the replacement engine duplicates the system originally selected by the equipment
manufacturer. Parts that are suitable for additional use should be transferred. Before making any conversion, check the data shown in the column labeled
"REMOVE, ADD and NOTE." See if the changes, which are shown, are actually necessary on the application in question. Often a standard service engine
will be a WORKABLE replacement without converting to such things as a special fuel tank or starter position.
If the crankshaft number does not appear in the "Original Engine" column, consult the Illustrated Parts List for the correct service replacement crankshaft number.
Engine Replacement Notes:
NOTE 6: Drill and Retap end of Crankshaft 7/16"-20 (1" Deep). Use 25/64" Tap Drill.
NOTE 15: For all Go-Karts use only a Model 136200 series engine as a replacement, regarless of the original Model.
NOTE 17: Gear Red. @ 3 o'clock.
NOTE 25: If the replacement engine supersedes to or is a Model 120000 series engine, refer to the illustrations located after the conversion data for this model series.
the overall dimensions that differ, are shown in the illustrations. If after making a visual inspection and it is determined the Model 120000 series engine
cannot be used because of equipment interference, the original engine should be repaired with individual parts.
NOTE 104: Transfer the Gear Reduction parts to the replacement engine.
NOTE 113: Gear Red. @ 6 o'clock.
Short Block Notes:
The SHORT BLOCK part number shown, is the assembly which can be used to rebuild the Original Type Number. If a letter appears after the short block number,
it indicates the short block must be modified. The change denoted by each letter is as follows:
NOTE R: Cut off 1-7/16" on Flywheel end of Crankshaft.
Original Engine
Type Model Crank Model
0001 135202 492088
0003 135202 495649
0004 135202 492088 126332
0005 135202 492088 126332
0006 135212 492088
0007 135212 495649 126312
0008 135232 495645 126332
0009 135232 495645 126332
0011 135297 492088
0012 135212 492088 126312
0013 135217 492088
0014 135212 497276
0015 135202 492088 126332
0016 135202 492088 126332
0017 135232 495645 126332
0018 135232 495645 126332
MODEL 135200 SERIES ENGINES REPLACED WITH
STANDARD SERVICE ENGINES
Make From Remove
Qty Part #
Type #
No Replacement Repair With Individual Parts.
No Replacement Repair With Individual Parts.
0036
0036
No Replacement Repair With Individual Parts.
0060
0036
0036
No Replacement Repair With Individual Parts.
0023
No Replacement Repair With Individual Parts.
No Replacement Repair With Individual Parts.
0036
0036
0036
0036
Page 1 of 13
www.mymowerparts.com
FILE IN SECT. 2B OF SERVICE ENGINE SALES MANUAL
SALES MANUAL
Add Change
Note to Type
Qty Part #
15
15
15
25
15
25
15
15
25
15
25
15
25
15
15
25
15
15
15
25
15
25
15
25
15
25
FORM MS-2896-7/04
REPLACES FORM MS-2896-8/02
135200 to 135299
135200 to 135299
Short Block
Trim RPM
Part # Notes
01 3600
All 4000
01 3200
All 3600
All 3600 694200
01 4000
01 4000
01 4000
01 3600
01 3750 694200
01 3600 694200
All 3600 694200
01 3600
01 3500
01 4000
01 3000
