ADJ Chameleon QBar Pro User Instructions page 12

Chameleon QBar Pro
Channel Value
1
0 - 255
2
0 - 255
3
0 - 255
4
0 - 255
5
0 - 255 PLEASE SEE THE CHART ON PAGE 26
6
0 - 255
7
0 - 31
32 - 63
64 - 95
96 - 127
128 - 159 PULSE STROBING SLOW - FAST
160 - 191
192 - 223
224 - 255
8
1 - 15
16 - 23
24 - 31
32 - 39
40 - 47
48 - 55
56 - 63
64 - 71
72 - 79
80 - 87
88 - 95
96 - 103
ADJ Products, LLC - www.adj.com - Chameleon QBar Pro User Manual Page 22
10 Channel Mode
Function
RED
0% - 100%
GREEN
0% - 100%
BLUE
0% - 100%
AMBER
0% - 100%
COLOR MACROS
MASTER DIMMER
0% - 100%
STROBING
OFF
LED ON
STROBING SLOW - FAST
LED ON
LED ON
RANDOM STROBING
LED ON
PROGRAMS
OFF
PROGRAM 1
PROGRAM 2
PROGRAM 3
PROGRAM 4
PROGRAM 5
PROGRAM 6
PROGRAM 7
PROGRAM 8
PROGRAM 9
PROGRAM 10
PROGRAM 11
Chameleon QBar Pro
Channel Value
8
104 - 111
112 - 119
120 - 127
128 - 135
136 - 143
144 - 151
152 - 159
160 - 167
168 - 175
176 - 207
208 - 255
9 PROGRAM SPEED/SOUND SENSITIVE
0 - 255
0 - 255 LEAST SENSITIVE - MOST SENSITIVE
10
0 - 20
21 - 40
41 - 60
61 - 80
81 - 100
101 - 255
When Channel 8 is being used, Channels 1-4 will not work.
When Channel 8 is between the values of 1-207, Channel 9 will control the pro-
gram speed.
When Channel 8 is between the values of 208-255, Channel 9 will control the
sound sensitivity.
ADJ Products, LLC - www.adj.com - Chameleon QBar Pro User Manual Page 23
10 Channel Mode
Function
PROGRAMS
PROGRAM 12
PROGRAM 13
PROGRAM 14
PROGRAM 15
PROGRAM 16
PROGRAM 17
PROGRAM 18
PROGRAM 19
PROGRAM 20
AUTO RUN
SOUND ACTIVE
SLOW - FAST
DIMMER MODE
STANDARD
STAGE
TV
ARCHITECTURAL
THEATRE
DEFAULT DIMMER SETTING
