Table Of Contents - Axia xNode Installation & User Manual

Table of Contents

Notices and Cautions . . . . . . . . . . . . . . . . . . . ii
We Support You . . . . . . . . . . . . . . . . . . . . . vi
A Note from Frank Foti . . . . . . . . . . . . . . . . . viii
Chapter One: Introducing the xNode . . . . . . . . . . 1
The Front Panel . . . . . . . . . . . . . . . . . . . . 2
Rear Panel . . . . . . . . . . . . . . . . . . . . . . . 3
Analog
AES/EBU
Microphone
GPIO
Mixed Signal
HTML Interface
Chapter Two: Configuration . . . . . . . . . . . . . . 6
Fast Setup
Assigning an IP address manually
Assigning an ID
iProbe configuration
Web interface configuration ("Simple setup")
Restoring Defaults
Chapter Three: The xNode in depth . . . . . . . . . . 11
Mounting
Optional Surface Mount kit
Optional Rack Mount kit
Home
Simple Setup
Web interface (Advanced options)
System
QOS (Audio xNodes)
PTP characterizations
Meters (Audio xNodes)
Mixer (Audio xNodes)
Destinations (Audio xNode)
Sources (Audio xNode)
Chapter Four: Analog xNode . . . . . . . . . . . . . . 24
Rear Panel . . . . . . . . . . . . . . . . . . . . . . . 24
Chapter Five: AES xNode . . . . . . . . . . . . . . . . 26
Rear Panel . . . . . . . . . . . . . . . . . . . . . . .
Chapter Six: Microphone xNode . . . . . . . . . . . . 28
Rear Panel . . . . . . . . . . . . . . . . . . . . . . .
Chapter Seven: GPIO xNode . . . . . . . . . . . . . . 31
Rear Panel . . . . . . . . . . . . . . . . . . . . . . .
Simple Setup
Other Web Interfaces
Home
System
3 Chapter Eight: Mixed Signal xNode . . . . . . . . . . 36
3 Rear Panel . . . . . . . . . . . . . . . . . . . . . . . 36
4 Simple Setup
4
4 Appendix A: GPIO Logic Table Samples . . . . . . . . 40
4 GPIO Operator's Microphone Logic
GPIO Control Room Guest Microphone Logic
GPIO Producer's Microphone Logic
6 GPIO Line Input Logic
8 GPIO Codec Logic
8 GPIO Telephone Hybrid Logic
9 GPIO Control Room Monitor Logic
9 GPIO Computer Playback Device Logic
10
Appendix B: xNode Specifications . . . . . . . . . . . . 48
Microphone Preamplifiers
11 Analog Line Inputs
11 Analog Line Outputs
12 Digital Audio Inputs and Outputs
14 Frequency Response
15 Latency
15 Dynamic Range
15 Equivalent Input Noise
17 Total Harmonic Distortion + Noise
17 Crosstalk Isolation, Stereo Separation and CMRR 49
18 Power Supply AC Input
19 Operating Temperatures
21 Dimensions and Weight
22
Appendix C: AES67 . . . . . . . . . . . . . . . . . . . 50
Network synchronization setup
AES67 Multicast connection setup
AES67 Unicast Setup
26
Appendix D: Telos Alliance Limited Warranty . . . . . 54
29
© 2016 Axia Audio - Rev 2.0
31
34
35
35
35
39
40
41
42
43
44
45
46
47
48
48
48
48
48
48
49
49
49
49
49
49
50
51
52
