Displaying on the TV screen
via MHL connection
Connect the terminal with an HDMI
compatible TV to display videos or images
on the TV screen.
• To connect the terminal with an HDMI compatible
TV, an HDMI cable compatible with HDMI jack (Type
A) (commercial item) and HDMI cable SC03/SC04
(optional) are required. Also the terminal can be
connected with an MHL compatible TV using an
MHL cable (commercially item).
• The terminal does not connect with all HDMI
devices.
1
Connect an HDMI cable to HDMI
conversion cable
• For instructions on how to connect the HDMI
conversion cable, refer to the instruction
manual for the HDMI conversion cable.
2
Connect HDMI cable to HDMI jack of
the TV
• For instructions on how to connect to the
HDMI jack and switch input ports, refer to
the instruction manual for your TV system.
3
Connect HDMI conversion cable to
the external connection jack of the
terminal
• If HDMI conversion cable is unplugged
while viewing on the TV, the TV goes into
the connection standby mode for a certain
period of time.
