Summary of Contents for SOUNDMASTER SCD-5500
- Page 1 INSTRUCTION MANUAL PORTABLE CD PLAYER WITH STEREO RADIO CASSETTE RECORDER Model: SCD-5500 Please read carefully these instructions before using this unit.
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING: TO PREVENT FIRE OR SHOCK HAZARD DO NOT USE THIS PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PRESENT BLADE EXPOSURE. TO PREVENT FIRE OR SHOCK HAZARD. DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. -
Page 3: Names Of Controls
NAMES OF CONTROLS CASSETTE COMPARTMENT CD PLAY/PAUSE BUTTON POWER INDICATOR CD SKIP/SEARCH BACKWARD BUTTON SPEAKERS CD RANDOM BUTTON CD STOP BUTTON VOLUME CONTROL FOLDING HANDLE 10. CD DISPLAY 11. FM STEREO INDICATOR 12. TUNING CONTROL 13. CD SKIP/SEARCH NEXT (FORWARD) BUTTON 14. -
Page 4: Important For Laser Products
INTRODUCTION Thank you for purchasing this product. Please read through these operating instructions, so you will know how to operate your equipment properly. After you finished reading the instructions manual, put it away in a safe place for future reference. CAUTION: Do not block the ventilation openings or holes. -
Page 5: Basic Function
BASIC FUNCTION SWITCHING ON THE UNIT Set the FUNCTION switch to CD or RADIO. TO ADJUST VOLUME Rotate the VOLUME CONTROL clockwise or anticlockwise to increase or decrease volume. HEADPHONES For private listening, plug the headphones/earphones (not included) into PHONES jack (3.5 mm diameter). -
Page 6: Using The Cd
AUTOMATIC STOP FEATURE When the cassette deck is operating in play or record mode and the end of the tape is reached, the unit automatically shuts itself off and returns all buttons to the off position. RECORDING FROM THE RADIO 1. -
Page 7: Selecting A Desired Track/Passage
SELECTING A DESIRED TRACK/PASSAGE To select a desired track Press SKIP/SEARCH FORWARD (NEXT)/BACKWARD button repeatedly in stop mode or during playing until the desired track appears on the display. Press PLAY/PAUSE button to start play. To search for a particular passage during playback (track scanning at high speed) Press and hold SKIP/SEARCH BACKWARD/FORWARD button to scan the current playing track at high speed until desired point (passage), then release the button. -
Page 8: General Information
GENERAL INFORMATION MAINTENANCE Types of Cassette Use only good quality cassettes for making recordings. The use of C120 cassettes is NOT recommended in this machine. Protecting Recording Normally, anything recorded on the tape is automatically erased when new recording is made. -
Page 9: Specifications
SPECIFICATIONS GENERAL Power Requirement AC 230 V ~ 50Hz DC 9V U M-1 x 6 PC S Power consumption AC 15 Watts Weight Approx. 2.2 kg Dimensions Approx. 300mm (W) x 235mm (D) x 155mm (H) Operation temperature C – +35 RECEIVER SECTION Receiving Bands AM/FM...
