oConnor 2575D Operator's Manual page 10

Camera mounting plate
Camera plate
clamp release lever
Camera plate
clamp lever
Handle clamp
Handle
Tilt fluid drag
adjustment knob
Handle extension
Figure 2 2575D Fluid Pan & Tilt Head - left-hand-side
Camera fixing screws
2575D Fluid Pan & Tilt Head
Slide plate marker
Slide plate scale
Handle/accessory
mounting rosette
Counterbalance
numerical display
Tilt fluid
drag display
Folding
counterbalance
adjustment crank
Mitchell key marker
Mitchell key
Tie down
9
