INSTRUCTION MANUAL
IMPORTANT INFORMATION: Please read these instructions carefully
GB
and make sure you understand them before using this unit. Retain these
instructions for future reference.
MANUEL D'INSTRUCTIONS
RENSEIGNEMENTS IMPORTANTS: Avant d'utiliser cet appareil,
FR
veuillez lire atentivement les instructions et assurez--vous de les avoir
comprises. Conservez les instructions pour référence ultérieure.
BETRIEBSANWEISUNG
WICHTIGE INFORMATION: Lesen Sie diese Hinweise zur Handha-
DE
bung des Geräts aufmerksam durch. Verwenden Sie es erst, wenn
Sie sicher sind, daß Sie alle Anweisungen verstanden haben und
gut aufbewahren.
MANUAL DE INSTRUCCIONES
INFORMACIÓN IMPORTANTE: Lea atentamente las instrucciones y
ES
asegúrese de entenderlas antes de utilizar esta aparato. Conserve las
instrucciones para la referencia en el futuro.
545167620 Rev. 1 9/20/07 BRW
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Partner P33XT
Summary of Contents for Partner P33XT
- Page 1 INSTRUCTION MANUAL IMPORTANT INFORMATION: Please read these instructions carefully and make sure you understand them before using this unit. Retain these instructions for future reference. MANUEL D’INSTRUCTIONS RENSEIGNEMENTS IMPORTANTS: Avant d’utiliser cet appareil, veuillez lire atentivement les instructions et assurez--vous de les avoir comprises.
- Page 2 IDENTIFICATION (WHAT IS WHAT?) Chain Front Hand Guard Adjustment Tool (Bar Tool) Muffler Chain Bar Oil Fill Cap Bar Guard Cylinder Cover Throttle Lockout Rear Handle Throttle Choke/ Chain Chain Trigger Fast Idle Brake Catcher Lever IDENTIFICATION OF SYMBOLS WARNING! This chain saw can be dangerous! Care- less or improper use can cause...
- Page 3 IDENTIFICATION OF SYMBOLS Starting Reminder Move ON/STOP switch to the ON position. Slowly press primer bulb 6 times. Pull choke/fast idle lever out to the full extent (to the FULL CHOKE posi- tion). SAFETY RULES WARNING Always disconnect spark plug wire and place wire where it can- not contact spark plug to prevent accidental starting when setting up, transporting, ad- justing or making repairs except carburetor...
- Page 4 S Do not put pressure on the saw at the end of the cut. Applying pressure can cause you to lose control when the cut is completed. S Stop the engine before setting the saw down. S Do not operate a chain saw that is dam- aged, improperly adjusted, or not com- pletely and securely assembled.
- Page 5 S Turn the engine off and let saw cool in a non-combustible area, not on dry leaves, straw, paper, etc. Slowly remove fuel cap and refuel unit. S Store the unit and fuel in an area where fuel vapors cannot reach sparks or open flames from water heaters, electric motors or switches, furnaces, etc.
- Page 6 S Keep a good, firm grip on the saw with both hands when the engine is running and don’t let go. A firm grip will help you reduce kickback and maintain control of the saw. Keep the fingers of your left hand encir- cling and your left thumb under the front handlebar.
- Page 7 (If not already attached) WARNING : Recheck each assem- bly step if the saw is received assembled. Al- ways wear gloves when handling the chain. The chain is sharp and can cut you even when it is not moving! 1. Loosen and remove the chain brake nuts and the chain brake from the saw.
- Page 8 Adjusting Screw Guide Bar Chain Brake Nuts Adjusting Screw - - 1/4 Turn S Lift up the tip of the bar and securely tight- en the chain brake nuts with the bar tool. S Recheck chain tension. OPERATING YOUR UNIT BEFORE STARTING ENGINE WARNING : Be sure to read the fuel...
- Page 9 warm engine after running out of fuel) NOTE : In the following steps, when the cho- ke/fast idle lever is pulled out to the full ex- tent, the correct throttle setting for starting is set automatically. ON/STOP SWITCH (SIDE VIEW) STOP 1.
- Page 10 CUTTING METHODS IMPORTANT POINTS S Check chain tension before first use and after 1 minute of operation. See CHAIN TENSION in the ASSEMBLY section. S Cut wood only. Do not cut metal, plastics, masonry, non-wood building materials, etc. S The bumper spike may be used as a pivot when making a cut.
- Page 11 S Be alert to signs that the tree is ready to fall: cracking sounds, widening of the fell- ing cut, or movement in the upper branches. S As tree starts to fall, stop saw, put it down, and get away quickly on your planned re- treat path.
- Page 12 WARNING : Be alert for and guard against kickback. Do not allow the moving chain to contact any other branched or objects at the nose of the guide bar when limbing or pruning. Allowing such contact can result in serious injury. WARNING : Never climb into a tree to limb or prune.
- Page 13 BAR MAINTENANCE If your saw cuts to one side, has to be forced through the cut, or been run with an improper amount of bar lubrication it may be necessary to service your bar. A worn bar will damage your chain and make cutting difficult.
- Page 14 Outdoor Products +39- -0341- -203211, declare that the chain saw models Partner P33XT, P351XT, P4-18XT and P4-20XT CSI---AV from serial numbers 2007- -151(N or D) 00001 and onwards (the year is clearly stated on the rating plate, followed by the serial number), comply with the requirements of the COUNCIL’S DIRECTIVES:...
- Page 15 TECHNICAL DATA SHEET P33XT Engine P351XT P4-18XT 4-20XT Cylinder volume, Stroke, mm Idle speed, rpm 3000 3000 3000 Recommended max. speed, unloaded, 13000 13000 13000 Power, kW Ignition system Manufacturer Phelon Type of ignition system Spark plug Champion Electrode gap, mm...
